A machined part is judged by numbers, not by how it looks. The 10 quality indicators in machining cover size, form, surface, material state, and documentation. Each one answers a different question: does it fit, does it seal, does it last, and can you prove it later?

The list is not a ranking. A die-cast housing and a bone screw use different subsets. What matters is knowing which indicator the function depends on. That single decision drives tool selection, cycle time, inspection time, and price.

We machine from one prototype to 10,000+ part runs, so we see both ends. A prototype can hold ±0.005 mm on a critical bore and leave everything else loose. A production run needs the same call written into the control plan.

• 1
  Function firstDecide which feature carries the load, seal, or fit. Tighten only that one.
• 2
  Cost follows toleranceEvery step tighter than ±0.05 mm adds inspection and slower passes.
• 3
  Proof travels with the partReports turn a measured value into a traceable one.

1. Dimensional tolerance. This is the allowed deviation from a stated size. On our 5-axis centers we hold ±0.005 mm (±0.0002 in) when the drawing calls for it. Tighter than that usually means grinding or lapping, not milling. The mistake is applying one tight tolerance to a whole print instead of the mating feature.

2. Geometric tolerance. GD&T controls form and position: flatness, parallelism, perpendicularity, true position. A bore can be the right diameter and still sit 0.05 mm off center. Datum choice decides the result, so the drawing must name datums the machine can actually reach.

3. Surface roughness. Ra is the average deviation of the profile from its mean line. As-machined aluminum sits around Ra 1.6–3.2 μm. Fine finishing reaches Ra 0.2–0.8 μm. A sealing face or sliding surface needs the finer number. A bracket does not.

• 1
  Watch the datumUndefined datums push the decision to the operator, and results vary.
• 2
  Ra is not Ra everywhereSpecify the surface, not the whole part.
• 3
  Position beats sizeFor bolt patterns, true position controls assembly.

6. Material grade and condition. 6061-T6 and 6061-O machine very differently. Heat treat condition changes hardness, chip formation, and the final strength. If the print says 6061, we ask which temper. The answer changes feeds and speeds.

7. Hardness. For steel parts, hardness often matters more than size. 4140 pre-hard at 28–32 HRC cuts cleanly. The same alloy at 50 HRC needs carbide and light passes. Hardness also predicts wear on a sliding surface.

8. Surface treatment and coating thickness. Anodizing, electroless nickel, and powder coating all add material. A 25 μm hardcoat on a Ø10 mm pin changes the fit. Call out whether the tolerance applies before or after coating.

9. Burr and edge condition. A sharp edge cracks plating and cuts hands. Deburring and chamfer size belong on the drawing, not in a note. Bead blasting, tumbling, and brushing each leave a different edge.

10. Inspection documentation. This is the indicator that lets a buyer verify the other nine. Material certs, in-process records, and a final report turn a good part into a defensible one. We inspect 100% before shipment and provide reports on request.

Tightening a tolerance never makes a part better on its own. It makes it slower and more expensive to prove. If a feature sits under a washer, ±0.1 mm is enough. If it locates a bearing, the same number is not.

Some indicators conflict. A mirror finish on a soft aluminum face can hide scratches that a satin finish would tolerate. A hard anodized surface resists wear but chips at a sharp edge, so edge radius and coating have to be chosen together.

Size also sets the limit. A 4,000 mm part cannot hold the same tolerance as a Ø20 mm pin, because thermal drift over that length is larger than the tolerance itself. Good prints accept that.
