10 valuable experiences in CNC machining
Ten lessons we keep re-learning on the shop floor, written for design engineers and buyers who need parts to come off the machine right the first time. Each one covers when it applies, when it does not, and what to change in the drawing or the process.

Why we wrote these down
None of this is theory. Each point comes from a job that went wrong, or from a job that went unusually well.
Tolerance is a cost decision, not a default
The fastest way to double the price of a part is to block-tolerance the whole drawing at ±0.01 mm. Most features do not need it. A mounting face, a clearance hole, a non-sealing boss — these live comfortably at ±0.1 mm. Put the tight callout only on the diameter that rides in a bearing, the bore that holds a dowel, the face that sets stack height.
When we quote ±0.005 mm on a critical bore, we are not just cutting slower. We are adding a roughing pass, a semi-finish pass, a temperature settle, a finish pass, and an on-machine probe check. That is four extra operations on one feature. Tighten two features instead of twenty and the part stays affordable.
The second lesson sits next to the first. Datum choice decides whether a tight tolerance is even achievable. If the drawing dimensions a bore from a cast surface that varies by 0.5 mm, no machine can hold the result. Dimension from a machined face, or tell us the assembly stack-up and let us pick the datum.
- 1Tight where it mattersBearing bores, dowel holes, sealing faces, mating spigots.
- 2Loose everywhere elseClearance holes, covers, non-critical pockets, cosmetic edges.
- 3Datum from machined surfacesCast or forged skin moves; a cut face does not.
Setup count drives both cost and error
Every time a part is unclamped, it moves a little. Reclamping adds a small positional error and a real chunk of labor. A part that needs five setups on a three-axis machine will cost more and hold less than the same part run in two setups on a five-axis center. That is the main reason we keep 16 simultaneous 5-axis machining centers on the floor.
Design for fewer setups. Put features on accessible faces. Allow a dovetail or a fixture boss that we can grip and then cut away. If one face of the part is purely functional and never seen, consider letting us use it as the clamping face and machine it last.
The fourth lesson is about thin walls. A 0.5 mm wall in aluminum looks fine in CAD and turns into a chatter problem on the machine. Tool pressure pushes the wall away, the cutter rubs instead of cuts, and the surface finish goes rough. Below about 1 mm in aluminum, or 1.5 mm in stainless, expect us to ask for a change.
- 1Fewer setups, tighter partsPosition error accumulates each time the part is reclamped.
- 2Five-axis is not a luxuryIt removes setups and reaches features a three-axis cannot.
- 3Wall thickness floorAround 1 mm aluminum, 1.5 mm stainless, less for short spans.
Practical limits by material and feature
Starting points we use when reviewing a drawing. Actual limits depend on geometry and tool reach.
| Material | Min. wall (short span) | Typical finish as machined | Notes |
|---|---|---|---|
| Aluminum 6061-T6 | 0.8–1.0 mm | Ra 0.8–1.6 μm | Easy to cut, gummy at high speed |
| Stainless 304 / 316L | 1.2–1.5 mm | Ra 0.8–1.6 μm | Work hardens; light finishing passes |
| Steel 4140 / 4340 | 1.5 mm | Ra 1.6–3.2 μm | Pre-hardened grades cut slower |
| Titanium Ti-6Al-4V | 1.5–2.0 mm | Ra 0.8–1.6 μm | Heat stays in the tool; coolant matters |
| POM / PEEK | 1.0 mm | Ra 0.8–1.6 μm | Clamp lightly or the part deforms |
| Brass C36000 | 0.6 mm | Ra 0.2–0.8 μm | Best finish of the common metals |
Tool reach and depth-to-diameter decide the process
A pocket 40 mm deep with a 6 mm corner radius is a different job from a pocket 8 mm deep with the same corner. Deep pockets need long, thin tools. Long tools deflect, so the machinist has to slow down, take lighter passes, and often peck at the bottom. Past roughly four times the tool diameter in depth, cost climbs quickly.
If a deep pocket is unavoidable, open the corners. A 6 mm radius that becomes a 10 mm radius lets us use a stiffer tool and often cuts cycle time by a third. The same logic applies to slots and ribs. The corner radius you specify sets the largest tool that can reach the floor.
Lesson six concerns threads and small holes. Thread milling gives a cleaner thread and lets us adjust fit without changing tools, but it is slower than a tap in soft material. For holes under Ø3 mm, tell us the depth and whether a drill can exit. A blind Ø1.5 mm hole at 10 mm deep is a broken-tool risk, and we will quote it accordingly.
- 1Depth-to-diameterPast 4:1, expect long tools, light passes, higher cost.
- 2Corner radius ruleBigger radius means a bigger, stiffer cutter.
- 3Small holesUnder Ø3 mm, send depth and exit condition with the RFQ.
Material choice and heat treat timing
Engineers often pick 7075 aluminum for strength, then hardcoat anodize it for wear. Hardcoat on 7075 is fine, but the coating builds thickness, and a ±0.01 mm bore can close up after coating. If the bore must stay tight, either mask it or finish it after coating. Anodize grows roughly half in and half out of the surface, so plan the allowance.
Stainless 303 machines freely because of its sulfur content; 304 and 316 cut tougher and cost more time. For a part that sees no corrosion, 303 is often the better call. For a medical or food-contact part, 316L is usually required. The material list matters more than the drawing tolerance in many quotes.
Heat treat timing is lesson eight. If a part is hardened after machining, it will move. Distortion is not uniform and the finishing operations have to happen after the furnace, on hard material. That usually means grinding or hard milling, not a standard end mill. Tell us the final hardness and we will sequence roughing, heat treat, and finishing.
- 1Coating allowanceHardcoat anodize changes bore size; mask or finish after.
- 2Free-machining grades303 stainless and C360 brass cut faster than their tougher cousins.
- 3Hardness after machiningPlan a post-heat-treat finishing step and budget for it.
Inspection plan and first-article review
A drawing without an inspection plan invites argument at delivery. Decide up front which dimensions are critical, which are reference, and whether you need a first article inspection report with actual values. We inspect 100% of parts before shipment, with raw material checks, in-process monitoring, and a final inspection. Reports are available on request.
If a feature cannot be measured with a caliper, say so and ask how we will verify it. A true position callout on a pattern of holes needs a CMM. A surface finish callout needs a profilometer. Knowing the method before the run starts prevents a part that is correct but undocumented.
Lesson ten is the first article. On a new part, review the first piece before we run the batch. Ten minutes on a first article saves a week on a rerun. Send photos, mark up the drawing, or ask for a video walkthrough of the critical features. It is the cheapest step in the whole project.
- 1Mark critical dimensionsA ballooned drawing speeds inspection and removes guesswork.
- 2Match method to calloutCMM for position, profilometer for Ra, gauge for diameters.
- 3Approve the first pieceReview before the batch runs, not after.
Questions engineers ask after the first quote
How tight a tolerance can you actually hold?
We hold ±0.005 mm (±0.0002 in) on critical features when the geometry allows it. That figure depends on material, feature size, and how many setups the part needs.
We will tell you at quote stage which features can hold that and which cannot. It is better to hear it before the run than after.
What surface finish is realistic without extra processing?
As machined, most aluminum and stainless parts come off at Ra 0.8–1.6 μm. A finer Ra 0.2–0.8 μm finish is achievable with additional finishing passes and the right tooling.
If you need a specific Ra, put it on the drawing. A blanket callout across the whole part usually adds cost without improving function.
Can you machine a single prototype and then the production run?
Yes. There is no minimum order quantity. We run from one prototype to 10,000+ part runs, and the same fixture and program carry over.
That matters because the prototype and the production part come off the same process, so the geometry does not shift between stages.
How do you handle confidential drawings?
Uploads are secure and confidential. We can sign an NDA on request before you send files.
If your program requires it, tell us at first contact and we will route the documents accordingly.
What lead time should we plan for?
Quotation and a free DFM analysis come back within 12 hours. Production can start within 24 hours of approval, and parts typically ship in 3–5 days.
Those numbers assume the drawing is released and the material is in stock. On long or unusual material, we will say so in the quote.
Which certifications cover automotive and medical work?
We hold ISO 9001:2015, IATF 16949:2016, ISO 13485:2016, and ISO 27001:2022. The automotive and medical standards are the ones buyers usually ask to see.
Certificates are available on request, and inspection reports can ship with the parts.
