A Guide to Buying Used CNC Machine Tools
A used machine can save capital, but the risk sits in the details: spindle condition, way wear, control age, and spare part supply. This guide is for engineers and shop owners who need a repeatable way to check a machine before money changes hands.
What This Guide Covers
A used machine is a maintenance project with a production schedule attached. Price the machine and the repair list together.
Define the Work Before You Define the Machine
Start with a part, not a listing. Write down the largest envelope you actually machine, the tightest tolerance you quote, and the material mix. A shop that cuts 6061 brackets at ±0.05 mm has very different requirements from one holding ±0.005 mm on 17-4PH stainless.
Then match the machine travel to that envelope. A 4,000 × 400 × 150 mm bed is wasted floor space if your parts fit in 500 × 500 × 450 mm. On the other side, a compact machine that barely fits the part leaves no room for fixtures, probe heads, or tool clearance. Buy 20 to 30 percent more travel than the biggest job.
Spindle taper and tooling interface decide what you can cut. CAT40 and BT40 cover most general milling. HSK-A63 holds better at high rpm and suits 5-axis work where reach matters. If the used machine comes with a tooling package, price that package separately. Tool holders, pull studs, and shrink-fit units add up fast.
Power and air matter as much as the control. Check the connected load against your service entrance, and confirm the compressed air volume the machine needs. A 30 kW spindle on a 40 amp feed will trip breakers under load. These numbers live in the manual, so ask for it before you travel to see the machine.
- 1Envelope firstMatch travel to the largest part plus fixture, not to a wish list.
- 2Tolerance drives class±0.005 mm work rules out worn box ways and tired ball screws.
- 3Tooling is part of the priceHolders and workholding often cost as much as the machine.
Inspection: What to Measure and What to Ignore
A paint job tells you nothing. Measure the machine instead, and measure it under power. Bring a dial indicator, a granite square, a test bar, and a spindle analyzer if you have one. Plan on three to four hours for a serious inspection.
Check spindle runout at the taper with an indicator on a test bar. Taper contact should read above 80 percent on bluing. Then check axial and radial play by hand and with a bar. A spindle that runs warm within ten minutes or makes a rumble at 8,000 rpm needs a rebuild. Budget that cost before you negotiate.
Geometry is next. Level the machine, then sweep the table for flatness and check squareness between X, Y, and Z. Ball bar testing shows circularity and backlash in one pass. If a ball bar is not available, cut a test part: a circle, a square pocket, and a stepped face. Measure the results on a CMM or with a height gauge.
Control condition is harder to judge. Scroll through the parameters, alarm history, and servo load screens. Ask when the backup battery was last replaced. Loose or missing parameters turn a working machine into a paperweight, and rebuilding them can take days.
Hours on the meter help, but they are easy to reset or ignore. Look at the wear instead: way surfaces, ball screw backlash, and the state of the spindle belt or coupling. A machine with 40,000 hours and fresh ways can beat one with 8,000 hours and a scored spindle.
- 1Runout at the taperIndicator on a test bar; bluing contact above 80 percent.
- 2Ball bar or test cutCircularity and backlash in one measurement.
- 3Alarm historyRepeated servo or spindle faults point to drive problems.
Inspection Checklist and Pass Criteria
Use this on site. Record numbers, not impressions.
| Check | Method | Pass criteria |
|---|---|---|
| Spindle taper runout | Indicator on test bar | Under 0.005 mm at 100 mm |
| Taper contact | Bluing on test bar | Above 80 percent contact |
| Table flatness | Indicator on granite square | Within maker spec for class |
| Squareness X to Y | Dial indicator sweep | Under 0.01 mm over 300 mm |
| Backlash | Ball bar or indicator | Under 0.005 mm per axis |
| Spindle noise | Run to max rpm, 10 min | No rumble, no excess heat |
| Control parameters | Read backup and history | Backup exists, no lost axes |
| Way condition | Visual and feeler check | No scoring, no visible step |
Service History, Spares, and the Real Cost of Ownership
Ask for the maintenance log and the original invoice. A machine with a documented spindle rebuild and fresh ball screws is worth more than a clean-looking unit with no records. If the seller cannot produce a log, price the machine as if every wear item needs attention.
Control support decides the useful life. Fanuc and Siemens keep parts available for a long time, and independent repair shops know them. Older or niche controls can strand you on a single board. Call the control maker with the serial number before you commit. Ask how long the drive and I/O boards will be supported.
Spare parts are the second question. Check the lead time for a spindle, a servo drive, and a way wiper. If a critical part takes twelve weeks, that is twelve weeks of idle capacity. Factor it into the decision, not into a hope.
Total cost of ownership includes rigging, power, foundation work, alignment, and operator training. A machine that sells for a low price can cost more in the first year than a newer unit that runs from day one. Write both numbers down side by side.
When the numbers do not work, contract machining is the other path. GreatLight runs 127 high-precision CNC machines, including 16 simultaneous 5-axis centers, and holds ±0.005 mm with 100 percent inspection before shipment. For low or mixed volume, that removes the maintenance burden and the capital risk.
- 1Documented historyInvoices for spindle and ball screw work raise the value.
- 2Control support windowConfirm board and drive availability with the maker.
- 3Critical sparesLong lead times mean idle capacity, not just cost.
When to Buy New or Contract Out Instead
Used makes sense when the work is stable, the tolerance is moderate, and you have maintenance capability in house. A job shop cutting the same family of parts for years can run a well-kept 3-axis mill for a long time. The machine pays back because the process does not change.
Buy new when the tolerance is tight, the material is difficult, or the schedule leaves no room for breakdowns. Titanium and Inconel punish weak spindles and worn ways. Medical and aerospace work usually needs traceable calibration and current inspection records, which are hard to establish on an undocumented machine.
Contract out when volume is low, the design is still moving, or the part needs five-axis work you cannot justify buying. A 5-axis center is a large commitment, and its value depends on continuous load. Spreading that load across several programs changes the math.
A practical rule: if annual machine hours fall below 2,000, the fixed cost of ownership is hard to recover. Rent the capacity from a machine shop instead. If the machine runs two shifts, ownership starts to pay, and used equipment becomes a reasonable entry point.
- 1Buy usedStable work, moderate tolerance, in-house maintenance.
- 2Buy newTight tolerance, hard materials, no downtime budget.
- 3Contract outLow hours, moving design, or five-axis needs.
Common Questions
How many spindle hours are too many on a used machine?
There is no fixed number. Hour meters get reset or replaced, so treat them as a hint, not a fact. A spindle with 20,000 hours and a recent rebuild can run for years.
Look at the evidence instead: taper contact, runout at the test bar, noise at maximum rpm, and heat after ten minutes. Those four checks tell you more than the counter.
Can I verify a control's remaining support life before buying?
Yes. Get the control model and serial number, then contact the maker or an authorized repair house. Ask specifically about drive boards, I/O modules, and the servo amplifier.
Also ask whether parameter backups are available and whether the software version can still be updated. A control that is two generations old may still be supported, but the parts may be refurbished rather than new.
What should I check on the linear ways and ball screws?
Run an indicator along the way surface to look for a visible step or scoring. On box ways, check the Turcite or liner condition for separation and wear.
For ball screws, measure backlash at several points along the travel, not just near the center. Backlash that grows toward the ends suggests uneven wear or a bent screw.
Is a used machine worth it if I only need a few hundred parts a year?
Usually not. Below roughly 2,000 spindle hours a year, the fixed costs of power, maintenance, tooling, and floor space outweigh the savings.
Contract machining gives you the same cutting capability without the ownership burden, and you can scale volume up or down without selling equipment later.
What documents should come with the machine?
Ask for the original invoice, maintenance log, parameter backup, electrical schematics, and the operator and maintenance manuals. A calibration or geometry report from a recent service visit is a bonus.
Missing schematics are a real cost. Rebuilding them takes an electrician several days and delays any repair that follows.
How does used equipment compare with a contract shop on lead time?
A running machine in your own shop can turn parts the same day. A contract shop adds shipping and scheduling, but removes breakdown risk and maintenance time.
At GreatLight, production can start within 24 hours of an approved order, and parts ship in 3 to 5 days with 100 percent inspection before shipment.
