Application of the servomotor system in CNC machine tools

A CNC machine tool is a frame, a spindle, and a set of axes that have to arrive at a commanded position at a commanded speed. The servomotor system is what carries out those commands. The control reads the G-code, works out the trajectory, and sends a position demand to each axis drive. The drive converts that demand into current for the motor, and the motor moves the slide or the rotary table.

Feedback closes the loop. An encoder on the motor shaft, or a linear scale on the slide, reports the real position back to the drive thousands of times per second. The drive compares demand with actual and corrects the error before the next cycle. That comparison is why a servo axis can hold ±0.005 mm on a good machine instead of drifting with load.

The spindle is a special case. On most machining centers it runs in speed or torque control rather than position control, but it still uses a servo drive for orientation, rigid tapping, and spindle positioning during tool change. So the same motor family covers both feed axes and the spindle, just with different control modes.

• 1
  Feed axesPosition control on X, Y, Z, and any rotary axis.
• 2
  SpindleSpeed and torque control, plus orientation and rigid tapping.
• 3
  FeedbackEncoder on the motor, linear scale on the slide when the tolerance is tight.

Not every axis needs the same motor. A small three-axis mill cutting aluminum can run on AC synchronous servos with a modest torque rating. A five-axis machining center swinging a trunnion table needs a motor with enough torque to fight gravity and inertia at the same time, plus a brake for when the drive is powered down. Pick the wrong motor and the axis will either lag on direction changes or overheat on long cuts.

Linear motors are a different answer. They remove the ball screw and couple the load directly, so there is no screw whip and no backlash to compensate. Acceleration is higher and positioning is cleaner at high feed rates. The trade-off is heat in the magnet track and a higher cost per axis. For large dies and long parts, a linear motor on the long axis can be worth it.

The drive matters as much as the motor. A modern digital drive stores the tuning parameters, monitors current and temperature, and can report faults to the control before a cut is ruined. When a machine is retrofitted, the drive is often the part that dates fastest, not the motor itself.

• 1
  AC synchronous servoStandard choice for feed axes on mills and lathes.
• 2
  Direct-drive rotaryUsed on trunnions and index tables where backlash must be zero.
• 3
  Linear motorHigh acceleration on long axes; no screw, no backlash.

A servo axis that is badly tuned will still move to position, but it will overshoot or ring on the way. You see that as chatter marks on a wall, a corner that is not sharp, or a bore that measures differently at the top and the bottom. The machine may pass a static check and still cut a bad part, because the error only appears while the axis is accelerating.

Tuning is a balance. Stiffen the loop too much and the axis buzzes and heats up. Loosen it and the axis lags behind the commanded path on curves and direction changes. On a five-axis job the rotary axes make it harder, because the tool tip error comes from the combination of linear and rotary motion, not from one axis alone.

For tight work we check the axis behavior with test cuts before a run starts. A quick circle-diamond-square test shows whether the servos can hold the path at the feed rate the job needs. If the part is a one-off prototype, that check is cheap insurance. If it is a 10,000-part run, it protects the whole batch.

• 1
  OvershootShows as ringing or a mark just past a corner.
• 2
  LagShows as a rounded corner or a bowed wall on a curve.
• 3
  HeatA sign the loop is too stiff for the duty cycle.

Servo control earns its cost when the part has to hold a tolerance across many features, or when the cycle repeats thousands of times without drift. Bores, bearing seats, sealing faces, and mating holes are the classic cases. If a feature has to match a counterpart on another part, servo positioning is what makes that repeatable.

There are jobs where the servo system is not the limiting factor. A simple flat plate with loose tolerances does not need a five-axis servo machine; a three-axis cut will do it for less. Very deep features in a hard material can be limited by tool deflection and spindle power, not by axis accuracy. In those cases paying for a tighter servo loop buys nothing on the part.

Material and geometry decide a lot. Thin walls in aluminum will move under cutting force no matter how well the servo is tuned, so the setup and the tool path have to carry that problem. Hard alloys like Inconel or Ti-6Al-4V slow the feed rate, and slow feeds are actually easier on the servo loop. The hard part there is tool life, not axis control.

If you are unsure which side of the line a part falls on, send the drawing. We will say whether the tolerance needs a servo-driven five-axis cut or whether a three-axis job will hold it.

• 1
  Good fitRepeated tight features, mating parts, high-volume runs.
• 2
  Poor fitLoose flat parts where a three-axis cut is enough.
• 3
  Not the limitDeep pockets in hard alloys; tooling and power dominate.
