Are G Codes the Same on All CNC Machines?
Short answer: the core G codes are the same, the execution is not. This page explains where Fanuc, Siemens, Haas and Mitsubishi controllers diverge, how post-processors change the output, and what to check before you send a program to a shop. Written for design engineers and sourcing engineers who review CAM output.

What this page covers
A practical read on G-code portability, written from the machine side of the shop floor.
What a G code actually is
A G code is an address word that tells the controller what motion or machine function to perform. G00 is rapid positioning, G01 is linear feed, G02 and G03 are circular interpolation, G54 selects a work coordinate system. The list is published in ISO 6983, and every controller builder claims to follow it.
That is where the agreement ends. ISO 6983 defines the word format, not the full behavior of the machine. The same G01 block on a Fanuc 0i and a Siemens 840D will both move in a straight line, but the feedrate interpretation, the look-ahead behavior and the way the block is cancelled can differ.
Think of it as a shared vocabulary with different grammar. An engineer who writes G code by hand for one machine and expects it to run unchanged on another will eventually scrap a part. A CAM programmer who relies on a post-processor is usually safer, because the post absorbs the differences.
- 1Common coreG00, G01, G02, G03, G17–G19, G20/G21, G40–G42 behave the same on nearly all controllers.
- 2Where it splitsCanned cycles, tool compensation edge cases, coordinate system extensions and 5-axis commands.
- 3Who owns the riskWhoever releases the program. Confirm the controller model before quoting a cycle time.
Where G codes stop being the same across machines
The biggest gap is in canned cycles. G81, G83 and G84 exist nearly everywhere, but the retract behavior, the way a Q value is interpreted for peck drilling, and whether the cycle cancels on G80 or on the next G00 differ between builders. A deep-hole cycle tuned for one controller can drill a different depth on another.
Work coordinate systems are the second gap. Standard G54 through G59 gives six offsets. Fanuc and Haas add G54.1 P1 through P48 as extended offsets. Siemens uses a different model entirely, with G54 as a settable frame combined with TRAORI and CYCLE800 for rotary work. A program that calls G54.1 P12 will stop on a controller that only knows G54.
Then there are the proprietary extensions. High-speed look-ahead modes, for example, are switched on with G05 on some Fanuc builds, G08 on others, and a machine-specific M code on a third. Renishaw probing macros, tool life management and pallet change logic are all vendor territory. None of this is in ISO 6983.
- 1Canned cyclesG81–G89 retract and cancel behavior varies. Test on one hole first.
- 2Extended offsetsG54.1 Pn is a Fanuc-family feature, not a universal one.
- 3Look-aheadG05, G08 or an M code, depending on the builder and the option package.
- 4Rotary and 5-axisRTCP, TRAORI, TCPM and M128 all do a similar job with different syntax.
Why the post-processor matters more than the G code
A CAM system outputs neutral toolpath data. The post-processor turns that into the dialect the target machine understands. Change the machine, and the post has to change with it. This is the step where most compatibility problems are created or prevented.
A well-built post encodes the machine kinematics, the controller's cycle format, the safe retract plane, the tool change sequence and the unit system. A generic post that ships with CAM software rarely matches a specific machine. If the post is wrong, the code still looks valid, which is what makes the failure expensive.
For 5-axis work the post also has to handle the difference between table-table, head-table and head-head configurations. The same toolpath posted for a trunnion machine will not run on a gantry-style 5-axis center without a rewrite. At GreatLight we run 16 simultaneous 5-axis machining centers alongside 12 four-axis mills and 27 three-axis machines, so we keep separate posts per machine group rather than one shared post.
- 1One post per machine groupTwin-spindle and mill-turn machines need their own posts.
- 2Verify on the machineDry run with the tool offset active, then cut a test feature.
- 3Keep the post under revision controlA post edit that is not logged will bite the next programmer.
Same function, different controller syntax
A short comparison of the commands engineers ask about most. Confirm against the specific machine manual before releasing a program.
| Function | Fanuc / Haas style | Siemens 840D style | What to watch |
|---|---|---|---|
| Rapid and linear | G00 / G01 | G0 / G1 | Leading zeros are optional on most controls |
| Circular interpolation | G02 / G03 with I, J, K or R | G2 / G3 with CR or I, J | R format arc ambiguity over 180° |
| Work offsets | G54–G59, G54.1 Pn | G54 frame plus CYCLE800 | Extended offsets are not universal |
| Peck drilling | G83 with Q and R | CYCLE83 with more parameters | Q interpretation and retract plane differ |
| Rigid tapping | G84 with F as pitch | CYCLE84 with pitch and depth | Feed-per-rev vs feed-per-min on some controls |
| High-speed mode | G05 or G08, option dependent | COMPON, COMPCURV | Often a paid option, not always enabled |
| 5-axis TCP | G43.4 / G43.5 | TRAORI | Machine kinematics must match the post |
| Units | G20 inch / G21 metric | G70 / G71 | A wrong unit word scraps the part |
What compatibility means for precision parts
On a simple 2.5D part with straight walls and drilled holes, controller differences rarely show up in the finished dimensions. Positional accuracy is dominated by the machine, the fixture and the tool, not by the G code dialect. That is why a well-posted program moves between three-axis machines with little drama.
Tight tolerances change the picture. When we hold ±0.005 mm (±0.0002 in) on a feature, the look-ahead settings and the acceleration limits in the controller start to matter. A program posted for a machine with different servo tuning can leave witness marks on a corner or overshoot a small arc. The geometry is correct; the motion is not.
Surface finish is the other telltale. A cycle that produces Ra 0.8–1.6 μm on one controller can come out closer to Ra 1.6–3.2 μm on another if the feedrate smoothing is set differently. For medical implants, aerospace brackets and robot joints, that difference is enough to send a batch to rework.
- 1Simple geometryLow risk. Post once, verify once, run.
- 2Tight toleranceRe-check look-ahead and servo settings per machine.
- 3Fine finishCompare the first part against the drawing before running the batch.
- 4Complex 5-axisAlways confirm the post against the machine's kinematic model.
How to check compatibility before cutting metal
Start with the controller make, model and option list. Not just Fanuc, but Fanuc 31i-B5 with the high-speed option. Options change what the same G code will do. Ask the shop for that information before you release a program, not after the first part comes off the table.
Next, ask which post-processor was used and whether the shop has run that exact post on that exact machine before. A shop that keeps a post library and a revision log is a different risk profile from one that edits code at the console.
Finally, cut a test feature before the full run. One pocket, one tapped hole, one contoured corner. Measure it, then release the rest. The cost of a test cut is minutes. The cost of a scrapped titanium batch is not. GreatLight runs a raw material check, in-process monitoring and a 100% inspection before shipment, and inspection reports are available on request.
- 1Ask for the controller and optionsModel number, not just the brand.
- 2Ask for the post-processor sourceCAM system and post revision.
- 3Run a first-article checkMeasure before releasing the batch.
- 4Keep the program with the part recordSo a repeat order uses the same proven code.
Common questions from engineers
Are G codes the same on all CNC machines?
The core motion codes are standardized through ISO 6983 and behave the same on nearly every controller. G00, G01, G02, G03, G17 to G19 and G40 to G42 are safe to assume.
Everything outside that core is builder-specific: canned cycles, extended work offsets, high-speed modes, probing macros and 5-axis commands. Two machines can both read a G83 block and still drill it differently.
Can I take a program from one machine and run it on another?
On simple 2.5D work between machines of the same controller family, often yes, with a dry run first. Between different builders, assume no until proven.
The failure mode is quiet. The program runs, the part comes out, and the dimension is off by a few hundredths of a millimeter because a retract plane or a smoothing setting changed.
What is a post-processor and why does it matter here?
It converts neutral CAM toolpath data into the dialect of one specific machine. It encodes kinematics, cycle formats, safe planes and tool change logic.
A correct post makes the G code question mostly disappear. An incorrect post produces code that looks valid and runs wrong, which is harder to catch.
Do Fanuc, Siemens and Haas use the same G code?
They share the core and diverge on the rest. Siemens uses G0 and G1 without leading zeros and handles frames through CYCLE800, while Fanuc and Haas use G54 to G59 plus G54.1 Pn for extended offsets.
High-speed look-ahead is switched on differently on each, and it is often an option that has to be enabled in the controller before the code will do anything.
Does G code compatibility affect the tolerance you can hold?
Indirectly, yes. The G code determines the motion, and the motion determines whether the machine can hold the tolerance.
For a feature at ±0.005 mm, the look-ahead and servo settings matter as much as the toolpath. We verify on a first article before releasing a batch, and we hold a 99.99% qualification rate across production runs.
How do you handle this for a repeat order?
The proven program stays with the part record, tied to the machine group it was verified on. If the job moves to a different machine, it is re-posted and re-verified.
That is also why we quote and run free DFM analysis within 12 hours: it is cheaper to catch a programming mismatch before the first chip than after.
