Aluminum cuts fast. High thermal conductivity pulls heat out of the shear zone instead of letting it pile up at the edge, so a sharp cutter runs at surface speeds that would destroy a tool in steel. That is why engineers specify aluminum for housings, brackets, manifolds and heat sinks.

The same property creates the first real problem. Heat leaves the chip and the workpiece quickly, so the chip stays ductile and sticky. Material welds to the cutting edge, a failure mode called built-up edge. Once that lump forms, it shears off and takes tool coating with it, and the surface turns rough.

Soft tempers make it worse. In 6061-T6 the hardness is enough to break the chip; in 5052 or annealed 6061 the cutter tends to smear. Deep pockets with thin walls deflect under cutting force, and the finishing pass then removes the deflection marks rather than the intended stock.

Rigid workholding, sharp uncoated or ZrN-coated tooling, and generous coolant flow handle most of it. On deep cavities, high-pressure through-spindle coolant clears chips that would otherwise be recut and rub the wall. Chip evacuation, not spindle speed, usually sets the practical feed rate.

Most machined aluminum falls into three groups. General-purpose 6061 covers brackets, plates, fixtures and enclosures. High-strength 7075 and 2024 cover loaded structural parts. Corrosion-resistant 5052 and 5083 cover formed and welded assemblies, and 6082 sits close to 6061 with slightly better strength.

6061-T6 is the default for a reason. It machines cleanly, welds, anodizes to a uniform color, and holds ±0.005 mm on stable features. If a part has no unusual load path, start here and only move when a test or a drawing forces you to.

7075-T6 reaches roughly twice the yield strength of 6061-T6, which matters for thin ribs and high-cycle loaded brackets. The trade-off is machinability and corrosion behavior: uncoated 7075 is less forgiving in wet or marine service, and it anodizes to a darker, less uniform tone.

2024-T351 is common in aerospace skins and fittings where fatigue life dominates. It cuts well but has poor corrosion resistance without cladding or coating, and it is a poor choice for welded frames. For die-cast housings the ADC12 family is a different process entirely, and machining is usually limited to critical faces and bores.

Three-axis work keeps the tool axis vertical and the part still. Faces, pockets, slots and holes that can be reached from a small number of directions are cheaper and faster on a 3-axis machine, and there is no repositioning error to manage. Most plate work never needs anything else.

Five-axis work rotates the tool or the part, so a single setup reaches features on several faces. The real gain is not speed; it is the number of setups. Every extra setup adds a work coordinate, a re-clamp, and a stack of positional error. A part with holes on four faces and a compound angle often becomes one operation.

Simultaneous 5-axis also lets a short, stiff cutter follow a contoured surface instead of reaching it with a long tool. Shorter tools chatter less, so scallop height and wall finish improve without slowing the program down. That is why impeller blades, turbine housings and organic brackets look the way they do.

Four-axis work sits between the two. A rotary table turns the part about one axis while the spindle works in three. Shafts, cylindrical housings and parts with radial hole patterns fit this pattern well. GreatLight runs Ø400 mm rotary tables for that class of work.

Tolerance and surface finish are not independent. A Ra 0.8–1.6 μm finish on a 6061 wall usually comes straight off a sharp finishing cutter. Push to Ra 0.2–0.8 μm and the part may need a separate finishing pass, a smaller stepover, or a secondary operation, all of which add time.

Thermal drift matters more than most drawings admit. Aluminum expands roughly twice as fast as steel per degree. A 200 mm feature measured at 25 °C and checked at 20 °C shifts by about 0.012 mm, which is larger than a ±0.005 mm tolerance. Let the part stabilize before final inspection.

Thin walls deflect. A 1 mm wall in a 40 mm deep pocket will move under normal cutting force, and clamping it harder makes it worse, not better. Reducing radial depth of cut, adding support, or roughing then stress-relieving before finishing keeps the wall where the model says it should be.

Anodizing changes dimensions too. Hardcoat grows the surface by roughly half the coating thickness per side, so a coated bore can close by 0.02–0.04 mm on a typical build. Note the coating on the drawing and let the machinist hold the pre-plate size.

Inspection starts before cutting. Incoming aluminum stock is checked against the certificate for alloy and temper, because a mislabeled 6061 bar that is actually a softer temper will machine badly and fail a hardness check later.

In-process checks catch drift while there is still stock to correct it. Critical bores, datums and wall thicknesses are measured after roughing and again after finishing. Final inspection covers the drawing dimensions, and reports are available on request with the shipment.

For production runs, the first article is the anchor. Once the process is frozen, the same program, tooling and fixture repeat the result, and historical data at GreatLight shows a qualification rate of 99.99% across inspected lots.

Traceability closes the loop. Material certificates, inspection records and revision numbers are kept together, so a part can be traced back to the bar and the program that made it. That matters for medical, automotive and aerospace customers who audit their supply chain.
