A press brake forms sheet by pushing a punch into a die while the sheet rests on two shoulders. What the control actually commands is ram depth, and depth is only an indirect way of setting angle. The material springs back when the load releases, so the ram must overtravel past the target angle. That gap between commanded depth and finished angle is where most bend errors live, and it is the reason modern controls measure rather than assume.

Three variables dominate the result. Grain direction changes yield strength along the bend line, so the same depth gives a different angle on a 90° rotated blank. Thickness variation of ±0.05 mm on a 1.5 mm sheet shifts the neutral axis enough to move the angle. Tool wear rounds the punch tip and widens the effective die opening. A bend cell that ignores any of these will drift over a shift, even with a perfect program.

The control cannot see material properties. It assumes a value for yield strength and works from there. When a new heat of 304 stainless arrives with a different temper than the last one, the first few parts tell you the assumption was wrong. Adaptive systems close that loop by measuring the angle after the bend and adjusting the next stroke. Older machines need an operator to nudge the depth correction manually.

Bend radius is a second constraint. Air bending gives a radius roughly tied to the die opening, commonly around 0.16 times V-width for mild steel. Coining forces the punch radius into the sheet but needs roughly five to eight times the tonnage. Bottoming sits between the two. Picking the wrong method for the radius callout is a common cause of cracking on 7075 aluminium or 17-4PH stainless.

Springback is the elastic recovery of the sheet after the punch lifts. It scales with the ratio of yield strength to elastic modulus, so high-strength steel and titanium recover far more than mild steel. A 90° target on 4130 might need the ram to reach 87° or less, depending on thickness and die setup. The compensation is not a constant; it changes with every material lot.

Closed-loop angle control solves this by measuring. A laser or camera reads the flank of the bend right after the ram stops, before the punch fully releases. The control compares the reading to the target and adjusts the depth on the next stroke. On a good cell, the first part may be off by a degree, the second by a fraction, and the third settles inside ±0.25° across a run.

The limit is where the measurement happens. Optical angle sensors need a clear line of sight to the bend flank, so tall flanges or nested parts can block them. Contact probes are slower but work in tight setups. Some shops run both: optical for high-volume flat work, contact for awkward geometry or reflective finishes like bright anodized aluminium.

Springback also affects flange length. When the sheet recovers, the flange shortens slightly along the bend line. On a 100 mm flange the change is small, often under 0.2 mm. On a short flange near the minimum, the same recovery can push the part out of tolerance. This is why minimum flange length is set by the die, not by the drawing.

A robotic bending cell pairs a press brake with one or two arms that handle the sheet between strokes. The arm grips the blank, positions it against the backgauge, waits for the bend, flips the part, and moves to the next station. For parts with four or more bends and runs above a few hundred pieces, the cell removes the handling time that dominates manual bending.

Offline programming is what makes the cell practical. The engineer builds the bend sequence in software, simulates the arm path, and checks for collisions before the job hits the floor. Programming a six-bend bracket offline might take an hour. Doing it at the machine, with test blanks and manual teaching, can eat half a shift. The simulation also flags bends that cannot be formed in the planned order.

Sequencing is where most cell projects stumble. A flange formed early can block the punch path for a later bend, or the gripper can collide with a finished flange. Simulation catches these before setup. It also balances the two arms: one loading while the other unloads keeps the brake busy, which is the whole point of the investment.

Not every job suits a cell. Short runs of 20 pieces, or parts with a single bend, are faster on a manual brake. The cell pays back on repeat work with stable geometry. At GreatLight we run sheet metal fabrication alongside our 127 CNC machines, so bend-heavy parts and machined parts can be quoted together and checked for fit before either process starts.

Bending has a material limit. Ductility sets how tight a radius can go before the outer fiber cracks. 6061-T6 aluminium is a common problem: it bends acceptably at a generous radius but tears at tight ones unless you anneal it first or switch to 5052 or 6061-O. 7075 is worse and is usually machined rather than formed. Titanium Grade 5 needs warm forming or a large radius for the same reason.

Thickness sets another limit. A press brake handles sheet well up to roughly 6 mm, and thicker plate moves to other processes. Heavy plate bending needs large tonnage and long tooling, and the radius grows with thickness. Once a part needs a radius smaller than the material allows, or a pocket, boss, or thread on the same face, machining is the practical route.

Hole-to-bend distance matters too. A hole placed closer than about 2.5 times the sheet thickness to the bend line will distort as the material stretches. The usual fixes are to move the hole, add a relief slot, or punch after forming. Designers who ignore this rule get oval holes and rejected parts, and the fix is often a new blank rather than a process tweak.

For parts that need both, hybrid routing works. Bend the basic shell, then machine the critical features. At GreatLight we hold ±0.005 mm on machined features while the formed shell keeps its bend tolerances. This split lets a bracket carry a tight bore without forcing the whole part onto a mill. It is a routine approach for aerospace and robotics enclosures.
