A barrel does not care how a part was made. It cares whether the bore axis, the breech face and the bolt lugs sit where the drawing says they sit. In practical terms, that is the whole job: hold the relationship between features, not just the size of each one.

Take a bolt. Lug contact area, lug-to-recess fit and headspace are three separate dimensions that only work together. If the lug recess is cut 0.02 mm deep, the bolt sits back, headspace opens, and the shooter sees erratic ignition long before anything looks wrong on a gauge.

The same logic runs through a trigger group. Pin hole spacing, sear engagement face and the angle of the disconnector slot decide pull weight and reset. Those three features interact, so improving one in isolation usually makes the others worse.

This is why a print full of tight single dimensions can still yield a mediocre assembly. What matters is the stack. One datum, one setup where possible, and a tolerance budget that leaves room for the features that actually steer the bullet.

The bore is the reference for everything. Chamber depth, throat lead and muzzle crown all take their position from it, so the first operation is usually to establish the bore axis in the fixture, then cut the outside profile from that axis. Turn it the other way and the wall thickness wanders.

Muzzle crown is a small feature with outsized effect. A crown cut off-square by 0.05 mm can throw a group open at distance while the bore itself is perfect. Cut it in the same setup as the muzzle thread, or re-indicate before the second op.

Bolt lug contact is a fit problem, not a size problem. You want lugs bearing on their full faces, which means the recess and the lug surfaces have to be machined to a matched pair. We mark the parts and keep them together through finishing.

Steel choice drives the cutting strategy. 4140 and 4340 at 28–32 HRC machine cleanly with coated carbide at moderate speeds. 17-4PH in the H900 condition is harder on tooling and rewards a lighter depth of cut with more passes.

Stainless barrels in 416 or 416R cut freely but gummy. Keep the feed up, do not dwell, and clear chips before they weld to the flank. A dwell in 416 is how you get a torn finish that looks like a tooling fault.

Five-axis work earns its cost on features that cannot be reached in one orientation. A receiver with angled ports, a chassis with compound reliefs, a bolt handle blended into a body: these need the tool to tilt, not just move.

The real gain is fewer setups. Every re-clamp adds stack-up error. A part cut in two orientations instead of five keeps more of the geometric relationship the designer drew, and the inspection report gets shorter for a good reason.

Three-axis still wins on flat plates, rails and simple round work. If the feature is reachable from one direction and the tolerances are moderate, paying for five-axis time is waste. We quote the simpler process when the drawing allows it.

For long parts, our 4,000 × 400 × 150 mm travels cover receiver blanks and rail sections that will not fit a compact VMC. Small trigger and sight components run on the 500 × 500 × 450 mm and 500 × 310 × 200 mm machines, where a Ø400 mm rotary table handles indexed work.

Roughing and finishing belong in different passes. Take 60–70% of the stock in roughing, leave 0.3–0.5 mm for the finish pass, then spring-pass the critical faces. Cutting straight to size in one pass is how you chase chatter and blame the machine.

Machining is only half of the tolerance story. Heat treat moves parts. A 4140 bolt body that measures perfectly before hardening can grow or warp enough to lose lug contact after it. Plan the sequence so critical fits are finished after the last thermal cycle.

Stress relief before finishing is cheap insurance on long, thin parts. Rails, chassis sections and barrel blanks all move when material is removed unevenly. A normalizing or stress-relief step between roughing and finishing keeps the final dimensions where you put them.

Surface finish matters on sliding and sealing faces. We hold Ra 0.8–1.6 μm on most functional surfaces and Ra 0.2–0.8 μm on bore and sealing features where friction and gas sealing are critical. As-machined Ra 1.6–3.2 μm is fine for non-critical exterior work.

Coatings change dimensions. Hardcoat anodizing builds roughly half in and half out, so a 25 μm coating can close a clearance you designed at 30 μm. Tell us the finish before we set the final cut.

Black oxide and electroless nickel are thin and predictable. Powder coating is not; it is a cosmetic or environmental finish, not a precision one. Keep it off any surface that has to fit.

A tolerance claim is only as good as the measurement behind it. We inspect 100% of parts before shipment: incoming material check, in-process monitoring on critical features, and a final inspection pass with reports available on request.

For bore and lug work, that means CMM or air gauge data on the features that matter, not just a caliper check on the outside. The outside diameter is rarely the dimension that causes a malfunction.

First article inspection is the point where a design problem is cheapest to fix. If the first part is out of spec, we call it before running the batch rather than shipping parts that will not assemble.

Our historical late-delivery probability sits below 2%. That number comes from scheduling, not from rushing the last operation, which is where most tolerance failures are born.
