A crankshaft converts reciprocating piston force into rotation. That single job creates a part with offset masses, long slender proportions and several surfaces that must share one centerline. CNC crankshaft processing is the sequence of turning, milling, drilling and finishing operations that hold those surfaces in relation to each other.

The work usually splits into three groups. Main journals and pin journals carry the bearing loads. Webs and counterweights carry the mass. The two ends carry the timing drive, oil pump drive, flywheel flange or damper seat. Each group has its own tolerance and finish targets, and treating them as one blanket specification is where cost runs away.

On a production engine the blank arrives as a forging or a casting. On low-volume and motorsport work it often arrives as a billet. The starting form changes the plan more than any other single input: a forging already has the throws near net shape, while a billet means the throws have to be generated from solid material.

Typical shaft lengths we see run from small single-cylinder parts up to 900 mm, with the largest work envelope at 4,000 mm. Journal diameters commonly land between Ø30 mm and Ø90 mm, and pin diameters a little smaller.

• 1
  TurningMain and pin journals, diameters and shoulders.
• 2
  MillingKeyways, trigger wheel seats, flats, lightening pockets.
• 3
  DrillingOil galleries, cross-drillings, dowel and bolt holes.
• 4
  FinishingFillet rolling, superfinishing, nitriding, balance trim.

Start with the throws. If the crank is machined as a single piece with the webs attached, the pin journals sit off the main axis, so a lathe cannot reach them without an eccentric setup or a mill-turn cycle. Mill-turn centers handle this well: the part is gripped once, the main journals turn on the C axis, and the pins are interpolated. For a 12-cylinder configuration with many throws, that saves repeated re-chucking and the stack-up that comes with it.

Journals are the tolerance carriers. Roundness, taper and diameter control all feed directly into oil film thickness. We hold ±0.005 mm on diameters and bores in the finishing pass, with Ra 0.2–0.8 μm available on journal surfaces after superfinishing or fine grinding. As-machined surfaces at Ra 1.6–3.2 μm are fine for non-bearing features, and pushing them smoother only adds cost.

Fillet radii are where life is decided. A sharp corner at the web-to-journal transition concentrates stress and starts a crack. Radius size is limited by the bearing shell clearance, so the design is a compromise. Where the radius is tight, fillet rolling cold-works the surface and leaves compressive stress. Where the radius is generous, a ground radius with a controlled surface finish is usually enough.

Oil galleries are a drill-path problem. Cross-drillings that break into a main journal have to exit at the right angular position, not just the right depth. Deep holes on a long shaft need steady support and peck cycles, and a gallery that intersects a fillet is a design issue, not a machining one. Flag it before the setup is built.

Balance is a process, not a final step. Counterweights are rough machined, the part is finish machined, then mass is trimmed near the webs. Doing the trim on the same machine that cut the journals keeps the centerline reference intact. If balancing is moved to a separate vendor after everything is finished, corrections often mean removing material you already spent time finishing.

• 1
  Offset throwsNeed mill-turn or 5-axis; watch for re-chuck stack-up.
• 2
  Fillet transitionRoll it or grind it; never leave a sharp corner.
• 3
  Cross-drillingsCheck exit angle and wall thickness after intersection.
• 4
  CounterweightsTrim mass late, on the same centerline reference.

Forged 4340 is the usual answer for high-load crankshafts. It takes a nitriding or induction-hardened case well and holds core toughness after heat treatment. In our material list it sits alongside 4130, 4140 and 1018, so we can quote a prototype and a low-volume run from the same drawing without switching supply chains.

1045 and 4140 are common on lower-stress and diesel-adjacent work. They machine more predictably than 4340 and hold a good journal finish without extra passes. Billet 6061 aluminum cranks show up in karting and small single-cylinder engines where the loads are modest and weight matters more than fatigue life. Aluminum journals need a harder bearing strategy, and the fillet rules do not relax.

Heat treatment changes the plan, not just the properties. A nitrided part is finished before the case is applied, because the case is thin and hard. An induction-hardened journal is usually ground after hardening. If the drawing calls for hardening after finish machining, expect a grinding allowance and a final size pass.

Stainless grades such as 17-4PH (SUS630) appear in marine and specialty builds where corrosion resistance matters. They are slower to machine and cost more per part, but they remove a coating step. Titanium TC4 (Ti-6Al-4V) is occasionally specified for weight-critical single-cylinder work; it needs rigid setups, sharp tooling and flood coolant, and the cycle time roughly doubles against 4340 for the same geometry.

• 1
  4340High-load cranks, nitride or induction case.
• 2
  4140 / 1045Predictable turning, good journal finish.
• 3
  6061Light-load single-cylinder billet cranks.
• 4
  17-4PH, TC4Corrosion or weight driven, slower cycles.
