A grinding wheel does not cut with a sharp edge. It cuts with thousands of tiny hard grains bonded into a wheel. Each grain acts as a very small negative-rake tool, and the material leaves as chips far smaller than a milling chip. That is the whole reason the process holds size so well: the depth of cut per pass is measured in micrometers, so the machine can correct a dimension without overshooting it.

The wheel is dressed before it runs. Dressing opens the pores, restores concentricity, and sets the effective cutting face. A wheel that is loaded with swarf or glazed will rub instead of cut, and the symptoms show up as heat, burn, and chatter marks on the surface. Dressing intervals of 20–50 parts are common on production runs, tighter on hard alloys.

Heat is the main constraint. Nearly all the energy at the contact zone turns into heat, and that heat concentrates in a layer only a few micrometers deep. Flood coolant carries most of it away, but the wheel speed, feed, and depth per pass have to stay inside a window. Cross that window and the surface tempers, cracks, or rehardens.

Because the wheel is a self-sharpening tool, the process is repeatable. Once the dressing cycle and the coolant are set, part 10 and part 500 measure the same. That repeatability, not raw speed, is what shops buy when they specify a grinding operation.

Size is the strong point. On a well-supported cylindrical or surface grinder, ±0.005 mm is a normal working tolerance, and ±0.002 mm is possible on short, rigid parts with in-process gauging. Flatness and parallelism follow: a lapped or ground face can hold 2–5 μm over 100 mm when the fixture is stable.

Surface finish is the second strength. A dressed wheel with a fine grit and a light spark-out pass reaches Ra 0.2–0.8 μm without polishing. For comparison, a good milled face sits around Ra 1.6–3.2 μm. If the drawing calls for a sealing face, a bearing seat, or a sliding surface, grinding usually gets there in one setup.

Geometry is the limit. Grinding wheels are rigid and round, so they reach outside diameters, bores, flat faces, and simple forms very well. Deep pockets, sharp internal corners, undercuts, and thin flexible walls are painful. The wheel simply cannot enter the space, or it deflects the part instead of cutting it.

Material matters too. Hardened tool steel, 440C, 17-4PH, and ceramics grind cleanly because the abrasive is harder than the work. Soft gummy metals like 6061 aluminium and pure copper load the wheel and smear. They can be ground, but only with an open wheel structure, coarse grit, and heavy coolant.

The usual job for grinding is finishing a part that is already near-net. Milling or turning brings the feature to within 0.05–0.1 mm, heat treatment runs if the drawing calls for it, and grinding takes the last few hundredths off. That order matters. Grinding after hardening avoids the distortion that quench and temper would otherwise introduce into a finished dimension.

A second job is repairing worn or mismatched parts. A shaft that has picked up a burr or worn 0.02 mm undersize can be ground back to size if there is enough stock. Same for a bore. This is often cheaper than making a new part, provided the hardness and the remaining case depth allow it.

A third job is holding two features to each other. Grinding a bore and its mating shaft in the same setup, or on the same machine with the same wheel, removes the stack-up that comes from two separate operations. Coaxiality of 0.005 mm between a bore and an outside diameter is routine this way.

What it is not good at is bulk removal. Taking 5 mm off a block by grinding would burn hours and several wheels. Rough it with a mill or a lathe, then grind. If a shop quotes grinding for a roughing operation, ask why.

Grinding is a corrective process, so the measurement loop matters as much as the wheel. In-process gauging on an OD grinder feeds size back to the control and stops the cycle at the target. On a surface or internal grinder, the operator gauges between passes and offsets the wheel. Either way, the last pass is a spark-out with no infeed, which cleans up deflection and leaves a consistent finish.

Surface integrity is checked separately from size. A burn shows up as a temper colour or a discoloured patch. Micro-cracks from an overheated pass show up under a magnifier or in a nital etch. Both mean the wheel was too hard, the coolant was starved, or the depth per pass was too aggressive. A part that is dimensionally perfect but burned will fail in service.

Roundness and runout need their own instruments. A micrometer reads size at one point; a roundness tester or a V-block with an indicator reads form. For bearing seats and hydraulic bores, the form callout is usually the one that matters, and it is the one that gets missed when a shop only checks diameter.

Documentation should follow the part. At GreatLight, every order gets raw material check, in-process monitoring, and a final inspection before shipment, with reports available on request. That covers size, finish, and visual condition, which is what most engineering teams need for incoming inspection.
