The workpiece sits in a chuck or between centers and spins about a level axis. The tool moves in X and Z, usually with a turret carrying 8 to 12 stations. Because the spindle axis is parallel to the floor, chips fall away from the cutting zone instead of piling on the part. That single detail is why a lathe can run unattended longer than a vertical machine on the same job.

Gravity also works on the part. A shaft 1,500 mm long and Ø80 mm sags under its own weight if you support it badly. On a lathe you counter that with a steady rest or a tailstock. Skip both and the middle of the shaft cuts oversize, often by 0.05 mm or more.

The bed carries the load. Cast iron beds are heavy and damp vibration, which matters when you take a 4 mm depth of cut in 4140 steel. Slant-bed designs at 30° to 45° push chips clear faster than a flat bed, so they suit high-volume aluminum and stainless work. Flat beds are easier to align and cheaper to rebuild.

Spindle speed sets your surface finish ceiling. A 3,000 rpm spindle on a Ø20 mm aluminum part gives roughly 188 m/min, which is comfortable for carbide. The same spindle on Ø300 mm steel is slow, so large-diameter work usually needs a bigger swing machine, not a faster spindle.

The spindle is the accuracy reference. Radial and axial runout of 0.003 mm or better at the taper keeps your turned diameter consistent. Once runout drifts past 0.01 mm, you will see taper on long cuts and chatter marks that no feed change will fix. Spindle bearings are usually angular contact pairs, preloaded and greased for life.

Guideways decide how the machine behaves over years, not hours. Linear rails are fast and need little maintenance, so they suit light cuts and quick positioning. Box ways have more contact area and absorb interrupted cuts better, which helps when you turn castings with hard spots.

The turret is a repeatability problem hiding in plain sight. Every index adds a small positioning error, typically 0.005 mm to 0.02 mm. If your drawing has a ±0.005 mm bore and a ±0.005 mm face in the same setup, plan which feature comes from which station and check the turret index before the run.

Thermal growth is the quiet one. A spindle running at 6,000 rpm for two hours can shift Z by 0.02 mm as the headstock warms. Warm-up cycles and in-process probing exist for exactly this reason.

A three-jaw chuck is fast and self-centering, but it repeats to about 0.02 mm to 0.05 mm. That is fine for most turned diameters. For a bore that must run concentric to 0.005 mm, bore soft jaws on the machine at the clamping pressure you will use in production. The jaws then match the part, not the catalog.

Between centers is the most accurate way to hold a shaft. A face driver or a dog drives the part while the tailstock supports the free end, so runout depends on the center holes, not the chuck. Center holes must be ground and clean. A burr in a center hole shows up as a 0.03 mm runout at the far end of a 1,000 mm shaft.

Collets suit bar work under Ø65 mm and repeat better than a three-jaw chuck, often within 0.01 mm. They also grip thin-wall tubing without crushing it, provided you match the collet to the actual bar diameter rather than the nominal size.

Long slender parts need a steady rest. Without one, a Ø25 mm shaft at 800 mm long will deflect and cut a barrel shape. With a steady rest at mid-span, the same part holds diameter within 0.02 mm.

Off-axis holes and pockets are the hard limit. A standard two-axis lathe cannot drill a hole perpendicular to the axis. You either move to a mill, add a live tool to the turret, or use a mill-turn center. Each step costs setup time and money, so count the off-axis features before you commit.

Live tooling solves many of these cases. A turret with driven stations can mill flats and drill cross holes without a second setup. The catch is that live tool power is small, often 2 kW to 5 kW, so a Ø16 mm end mill in steel will stall. Live tools suit light milling, not heavy pockets.

Thin-wall parts fight back. A Ø100 mm tube with a 2 mm wall will deflect under chuck pressure. You can drop to soft jaws at low pressure, use a pie jaw, or machine the wall in two passes with a light finish cut. All three work, none are free.

Hardened material above 45 HRC usually needs CBN or ceramic inserts and a rigid setup. If the part is already heat treated, check whether turning is cheaper than grinding before you assume the lathe can do it.

Start with the datum. Most turned parts use the spindle axis as the primary datum and a machined face as the secondary. Write that on the drawing and the inspection plan follows. If the drawing calls out a bore as datum A but the bore is reamed from the turret, you have just made turret index error part of your datum.

Then count setups. Every additional setup adds a re-chuck error, usually 0.02 mm to 0.05 mm, and adds labor. A part with a turned body and four radial holes might cost less as one mill-turn cycle than as two lathe setups plus a mill operation.

Pick your stock. Bar stock for parts under Ø65 mm, castings or forgings for larger parts where material removal would waste time. Saw cut bar to length plus 2 mm for facing. For a Ø200 mm part, a forged blank close to shape can cut cycle time by half.

Set the parameters by material. Aluminum 6061 runs at 200 m/min to 400 m/min with carbide and no coolant in many cases. Stainless 316 wants 120 m/min to 180 m/min with flood coolant. Titanium TC4 drops to 40 m/min to 60 m/min with high pressure coolant and sharp edges. Steel 4140 sits around 150 m/min to 250 m/min depending on hardness.

Plan inspection before the run. First-article checks on the critical diameters and a CMM report for the geometric callouts. In-process probing pays for itself on any run over a few hundred parts.
