A CNC machine reads a toolpath from a program and drives a spinning cutter along that path. The cutter removes material in chips. Everything else is support: the frame resists deflection, the spindle supplies torque, the controller holds position, and coolant carries heat away. A CNC machinery workshop in Los Angeles is judged on how well those five things stay in balance across a run.

The physical limit is stiffness. Push a cutter too hard and the tool bends, the part moves, or the spindle drops RPM. Each of those shows up as chatter, a poor finish, or a dimension that drifts halfway through the batch. The controller cannot correct a machine that is flexing.

Chip formation is the useful signal. Aluminum 6061 cuts clean at high surface speed and long chips. Titanium TC4 (Ti-6Al-4V) work-hardens at the cut zone, so a light pass that rubs instead of shears will ruin the next pass. Inconel is worse. The same program that works on 6061 will destroy a cutter in Inconel within minutes.

Heat is the other limit. A cutter running dry builds temperature until edge wear accelerates. Flood coolant, through-spindle coolant, or air blast each solve a different case. Deep pockets and small-diameter tools need through-spindle delivery; open face milling runs fine with flood.

• 1
  Rigidity firstShort tool overhang, heavy fixture, stable base.
• 2
  Heat secondMatch coolant method to pocket depth and material.
• 3
  Position lastThe controller is only as good as the structure under it.

A 3-axis machine moves the part in X, Y, and Z while the tool spins. It is the workhorse for plates, brackets, housings, and any part whose features face one direction. A 4-axis mill adds rotation around one axis, so a shaft with flats, slots, and holes can be cut without re-chucking. A 5-axis center moves the tool or table on two additional rotary axes at the same time.

The gain is not only complexity. Every re-chucking adds a datum error. If a part carries four setups, the stack of position errors grows with each one. Cutting the same features in a single 5-axis setup removes that stack. On a housing with angled ports and a sealing face, that difference often decides whether the assembly seals.

Five-axis also shortens tools. Instead of a long cutter reaching into a deep pocket, the machine tilts and uses a short, stiff tool. Short tools chatter less, hold size better, and last longer. Deep cavities in mold work and impeller blades are the classic cases.

The trade-off is programming time and fixturing cost. A 5-axis setup needs a verified post-processor, a clean model, and a fixture that clears the rotary motion. For a flat bracket with six holes, that effort does not pay back. For a titanium aerospace fitting, it does.

• 1
  3-axisPrismatic parts, one dominant feature direction.
• 2
  4-axisShafts, cylinders, parts needing index positions.
• 3
  5-axisCompound angles, deep pockets, tight datum control.
• 4
  Mill-turnTurned body plus milled features in one cycle.

A drawing tolerance is a demand. The achieved tolerance is a result of machine geometry, tool wear, fixturing, and temperature. On stable geometry with short tool reach, a shop can hold ±0.005 mm (±0.0002 in). On a 300 mm thin-wall part, that same shop may only hold ±0.05 mm, and the honest answer is to say so before the run.

Surface finish follows the same logic. A fine finish of Ra 0.2–0.8 μm usually means a separate finishing pass with a small stepover. An as-machined finish of Ra 1.6–3.2 μm comes straight off a roughing or semi-finishing pass. Specifying a fine finish on a non-functional face adds cycle time for no benefit.

Material behavior sets the floor. Aluminum moves with heat and cuts fast. Stainless 316 work-hardens and needs a rigid setup with a sharp edge. Titanium and Inconel demand low surface speed, high coolant pressure, and patience. The same feature that takes 20 minutes in 6061 can take two hours in Inconel.

Feature geometry is the quiet constraint. A pocket depth more than four times its width needs a long tool, which bends. A wall under 0.8 mm thick will deflect under cutting force even if the toolpath is correct. A hole smaller than Ø1 mm needs a micro tool that breaks easily. These are design choices, not shop failures.

• 1
  ±0.005 mmAchievable on short reaches and stable geometry.
• 2
  Ra 0.2–0.8 μmRequires a dedicated finishing pass.
• 3
  Ra 1.6–3.2 μmStandard as-machined result.

Most dimensional error on a machined part comes from setup, not from the cutter. Each time a part moves to a new fixture, a new datum is established. If the fixture is not repeatable, the error stacks. Two setups with ±0.01 mm location each can produce ±0.02 mm on the finished part before any cutting error is added.

Soft jaws machined in place solve most of this for prismatic parts. For castings and forgings, a dedicated fixture that locates on the as-cast surface keeps the machined features aligned to the real part, not to a nominal model. That matters on engine blocks, pump housings, and any part where wall thickness varies.

Thin-wall parts need support, not force. Vacuum chucks, wax fixturing, and sacrificial tabs hold the part without clamping stress. If a thin ring is clamped on the outside and bored on the inside, it will spring back when released. The measured dimension after release will not match the dimension under clamp.

For parts up to 4,000 mm, the workholding plan often decides whether the job is feasible at all. A long weldment may need multiple repositioning steps with re-indication between them. That is normal, but it must be planned before the quote, not discovered on the floor.

• 1
  Fewer setupsLess datum stack, better position control.
• 2
  Soft jaws in placeRepeatable location for prismatic parts.
• 3
  Support thin wallsVacuum, wax, or tabs instead of clamps.

A finished part is a claim. An inspection report is evidence. The useful sequence is raw material check, in-process monitoring, and final inspection. Material certificates catch a wrong alloy before it is cut. In-process checks catch tool wear before a whole batch drifts. Final inspection confirms the shipped parts.

CMM inspection measures position, form, and orientation against the model. For tight-tolerance features, that is the only reliable method. Calipers and micrometers are useful on the floor, but they cannot measure true position or concentricity across a complex datum scheme.

For medical and aerospace work, the documentation matters as much as the metal. ISO 13485:2016 and IATF 16949:2016 are the relevant systems for those sectors. ISO 9001:2015 covers general quality management. ISO 27001:2022 covers information security, which matters when a customer sends proprietary CAD files.

Ask for the report before the run, not after. If a shop cannot state which features it will measure and how, the tolerance on the print is a hope, not a plan. A 100% inspection before shipment is a process claim; the report is what proves it.

• 1
  Material certConfirms alloy before cutting starts.
• 2
  In-process checkCatches wear and drift mid-batch.
• 3
  Final CMMConfirms position and form on shipped parts.

Aluminum is the default for prototypes and housings. Grades 6061 and 6061-T6 machine cleanly and hold tolerance well. Grade 7075 is stronger but less forgiving; it cuts with a sharper edge and more coolant. Grade 2024 has good fatigue properties but poor corrosion resistance without coating. Die-cast ADC12 behaves differently again and often needs a finishing pass to seal porosity.

Stainless 303 is the free-machining grade and the easiest of the family. Grade 304 and 316 are tougher and work-harden, so a light rubbing pass will harden the surface and dull the next tool. Grade 17-4PH (SUS630) machines in the annealed state and then ages to high strength; the heat treat step must be planned into the sequence.

Steel grades 1018 and 1045 cover most general work. Alloy steels 4130, 4140, and 4340 are common in aerospace and motorsport, where strength and fatigue life matter. They cut at lower surface speed than aluminum and often need a roughing pass, a stress-relief step, and a finishing pass.

Titanium and Inconel sit at the hard end. TC4 (Ti-6Al-4V) needs low surface speed, high coolant pressure, and sharp edges. Inconel is worse on tool life. Neither belongs on a machine with a worn spindle or a weak fixture. Plastics such as POM, PEEK, and PC cut easily but move with heat, so light passes and sharp tools matter more than spindle power.

• 1
  Easy6061, 303 stainless, 1018 steel, POM.
• 2
  Moderate7075, 304, 4140, 17-4PH.
• 3
  HardTC4, Inconel, 4340, hard tool steel.
