A tolerance callout on a drawing is a target, not a result. The finished dimension comes from a chain: machine geometry, spindle and axis motion, tool wear, workholding deflection, coolant and chip load, and the thermal state of the whole setup. Each link adds a small error. Nothing cancels out on its own.

Take a simple aluminum bracket held in a vise. The machine may position to ±0.002 mm, but the vise jaws are not perfectly parallel, the part lifts slightly on the first heavy cut, and the material relaxes after roughing. Those effects can eat the whole budget before the finishing pass starts.

This is why we treat custom CNC machining as a system problem, not a machine problem. A ±0.005 mm result on a real part means the fixture, the tool path, the stock allowance and the inspection method were all chosen to support that number. Buying a better spindle alone does not get you there.

The practical question is not 'what can your machine hold'. It is 'what can this specific part hold, on this material, at this quantity, with a measurement you trust'.

• 1
  Machine contributionLinear positioning, squareness and spindle runout. On a 4,000 mm travel machine this grows with distance.
• 2
  Workholding contributionClamping force deforms thin sections. A soft jaw or a support block often beats a stronger vise.
• 3
  Thermal contributionSpindle growth and room temperature move a dimension over a long run.

Bores, flat faces and external profiles hold tolerance well. The tool approaches from one direction, the cutting force is steady, and a micrometer or a CMM can reach the surface. A Ø20 mm bore in 6061-T6 at ±0.005 mm is routine work on a mill-turn center.

Thin walls are the opposite case. A wall 0.8 mm thick and 30 mm tall will move under cutting pressure and again when the clamp is released. The print may say ±0.005 mm, but the part relaxes. We usually ask for a thicker wall, a lighter finishing pass, or a change in where the wall sits relative to the datums.

Deep pockets and long slots bring tool deflection into play. A 6 mm end mill with 40 mm of reach bends under load. The bottom of the pocket ends up smaller than the top. Reducing the depth of cut and using a stub tool with a relieved shank keeps the wall straighter.

Sharp internal corners are another common request that costs money. A cutter leaves a radius equal to its own. Adding a 0.5 mm corner radius instead of a dead sharp corner lets us use a stiffer tool and hold the surrounding dimensions more easily.

• 1
  Good candidatesBores, faces, spigots, gearbox housings, manifold flanges.
• 2
  Hard candidatesTall thin ribs, deep narrow slots, large unsupported overhangs.
• 3
  Cheap fixAdd a corner radius, thicken the wall, or move the datum to a machined face.

A three-axis machine needs one setup per face. Each new setup re-clamps the part and re-establishes a datum, and every one of those steps adds alignment error. For a part with features on four sides, the error can double or triple before the first chip is cut.

A simultaneous five-axis center machines compound angles in one setup. On a custom CNC machining job with angled ports, undercuts or a contoured face, this removes several re-clamping steps and keeps the datums intact. We run 16 simultaneous five-axis machining centers for exactly this reason.

Mill-turn centers add a second gain. Turning and milling happen without moving the part between machines, so a shaft with cross-drilled holes and milled flats keeps one zero point. We have 16 mill-turn centers, and they are the default for round parts that also carry milled features.

The trade is programming time. A five-axis toolpath takes longer to prove out than a three-axis one, and the fixture may need a tombstone or a trunnion. For a simple plate with one face of holes, three-axis is still the faster and cheaper route.

• 1
  Three-axisBest for flat plates and single-face work. 27 machines in house.
• 2
  Four-axisAdds rotation around one axis. Good for cylinders with side features.
• 3
  Five-axis / mill-turnFewer setups, tighter position between features, higher programming cost.

Aluminum 6061-T6 and 7075 cut cleanly and hold ±0.005 mm on stable features. They also move with temperature. A part measured right off the machine at 30 °C can read differently in a 20 °C inspection room. For long parts, we let the part equalize before final inspection.

Stainless 304 work-hardens. A light finishing pass on a surface that already work-hardened will push the tool instead of cutting it, and the dimension drifts. We keep the finishing depth of cut above the hardened layer and use sharp, coated tooling.

Titanium Ti-6Al-4V and Inconel generate heat at the cutting edge and deflect under load. Tool life is short and the thermal error is larger. Tolerances are held, but cycle time rises and the process needs more coolant pressure and lower speeds.

Plastics behave in the opposite way. POM and PEEK expand with heat and spring back after the cutter passes. A bore machined to size can measure undersize an hour later. For tight plastic parts we leave stock, let the part rest, then take a light final cut.

• 1
  Aluminum6061, 7075, 2024, 6082. Stable and fast to cut.
• 2
  Stainless and steel304, 316L, 17-4PH, 4140. Watch work hardening and heat.
• 3
  Titanium and InconelHold tolerance but at higher cycle time and tool cost.

A caliper reads to 0.02 mm on a good day, and it reads over a knife edge. If the drawing calls ±0.005 mm and the only check is a caliper, the number on the report is not real. The measurement method has to be finer than the tolerance.

For tight features we use a CMM or a micrometer with a known setting ring, and we measure at the same temperature as the acceptance criteria. Reports are available on request, and we keep raw material checks, in-process monitoring and final inspection records for each run.

Datum choice matters more than most drawings admit. If the print dimensions a hole from an unmachined cast surface, the tolerance applies to a surface that was never controlled. Moving the datum to a machined face usually removes a whole error source.

On a 99.99% qualification rate across our production, the failures we do see are almost always a datum or measurement mismatch, not a machine that could not hold the cut.

• 1
  Match the tool to the toleranceCaliper for ±0.1 mm. Micrometer or CMM for ±0.005 mm.
• 2
  Control temperatureLet parts equalize before final measurement on tight work.
• 3
  Dimension from a machined datumNever from a raw cast or saw-cut surface.
