  Five-axis or three-axis: which one fits the part

Three-axis machining moves the cutter in X, Y and Z. The workpiece stays put. Any face that is not reachable from the top of the part needs a second setup, a second fixture and a second datum. That is where most tolerance error comes from, not from the machine itself.

Five-axis machining adds two rotary axes, so the tool can approach the part from almost any direction while the part is still clamped. A turbine blade root, a medical implant with undercuts, or a mold core with deep ribs can be cut in one continuous setup. The geometry does not change. The number of times the part is released and re-clamped does.

That difference matters most on parts with tight true position between features on different faces. If a bolt circle on the top face must sit within 0.02 mm of a bore on the side face, three setups stack three datums and three fixture errors. One five-axis setup stacks one.

CNC machining Cambridge projects often involve low-volume, high-mix work: a hundred brackets for a lab rig, twenty manifold blocks for a fuel-cell test stand, a handful of titanium housings for a prototype. Five-axis work is not about speed on those jobs. It is about holding the drawing without a fixture library.

The trade-off is programming time. A five-axis toolpath takes longer to prove out than three-axis code, and a bad rotary move can crash the spindle into the table. For simple prismatic parts with one accessible face, three-axis is still cheaper and faster.

Every time you unclamp a part, you re-establish a datum. The part may shift by a few microns in the vise, or by more if the material relaxed after roughing. On a three-axis job with four operations, that is four chances to lose position.

Five-axis machining does not remove tolerance error. It removes the error you introduce by moving the part. Machine geometry error, thermal drift and tool deflection still exist. A ±0.005 mm callout is realistic for a single-setup five-axis part with a stable material and light finishing passes.

Thin walls are the classic failure point. A 0.8 mm aluminum wall will deflect under cutting force no matter how many axes you have. The fix is usually a support strategy: leave stock, machine one side, flip, then finish both sides in a light pass.

Thermal growth matters on long parts. Aluminum expands about 23 μm per meter per degree Celsius. A 500 mm part that warms 5 °C during roughing grows roughly 0.06 mm. Let it cool before the finishing pass, or the final dimension will be wrong.

Surface finish follows the same logic. Cutting a face in one continuous pass gives a consistent Ra. Cutting the same face in three setups leaves visible steps at the joint lines. For sealing surfaces, that is a leak path, not a cosmetic issue.

Aluminum 6061-T6 is the default for most Cambridge prototype work. It machines fast, holds ±0.005 mm on a rigid setup, and takes anodizing well. 7075 gives higher strength but is more prone to distortion after heavy roughing, so leave more stock and take lighter finishing cuts.

Stainless 304 work-hardens. If the tool rubs instead of cutting, the surface gets harder and the next pass cuts worse. Use sharp tooling, keep the feed per tooth up, and never dwell in the cut. 17-4PH in the H900 condition is more predictable and is common for medical and aerospace parts.

Titanium Ti-6Al-4V cuts at roughly one-third the speed of aluminum and generates a lot of heat at the edge. Use high-pressure coolant, keep the radial engagement low, and expect longer cycle times. Inconel is harder still. Both are doable on five-axis centers but the cost is real.

Plastics behave differently. POM and PEEK hold good tolerances if you control the heat. ABS and PMMA are softer and tend to burr, so a finishing pass with a sharp single-flute cutter and air blast works better than flood coolant. Carbon fibre eats tool edges, so budget for tool changes.

If a material is hard to source in the exact temper or thickness you specified, say so on the drawing. Substituting 6061 for 6082 changes the yield strength and may change the fit.

Most quotes that come back high are not expensive because of machine time. They are expensive because the part needs a custom fixture, a special cutter, or three extra setups to reach a feature that could have been moved.

Start with tool access. A 2 mm slot needs a cutter smaller than 2 mm, which means low rigidity and slow feed. If the slot can be 3 mm wide, the cycle time drops and the finish improves. Deep pockets have the same problem: depth-to-diameter above 4:1 needs a long-reach tool that will chatter.

Check your corner radii against the tool library. An internal corner with R0.5 in a 20 mm deep pocket forces a tiny, fragile cutter. R2 does the same job with a standard end mill.

Look at datum strategy. If the drawing datums are on faces that are hard to clamp, the shop has to invent a fixture. Moving a datum to a flat, accessible face often removes a whole operation.

Finally, mark which tolerances are functional. If only two holes need ±0.005 mm and the rest can be ±0.1 mm, say so. Unmarked tight tolerances get applied everywhere, and the price follows.
