CNC machining removes metal by rotating a cutting tool against a workpiece that is clamped in place. A CAD model becomes toolpaths, toolpaths become G-code, and the controller moves axes to a commanded position. The part is whatever is left after the tool has passed through. Accuracy depends on how faithfully the machine reaches each position and how little the cutting forces push it away from that position.

Every cut generates heat and force. Aluminium 6061 with sharp carbide and good coolant runs cool. Stainless 316L work-hardens at the surface, so a light pass with a dull tool hardens the layer you are about to cut again. That is why feeds and speeds are not transferable between materials, and why a shop that runs mostly aluminium may struggle with your titanium bracket on the first attempt.

The command position and the actual position differ by a few micrometres even on a good machine. Thermal growth over a long run can add more. So the real question is not "what tolerance can you hold" but "what tolerance can you hold across this batch, on this material, with this fixture, after four hours of cutting."

A 3-axis mill moves X, Y and Z while the part stays still. It is the fastest and cheapest way to make a plate with holes, pockets and a flat back. If every feature is reachable from the top, stop there. Adding axes only adds setup cost and programming time.

A 4-axis machine adds a rotary table, usually turning about X. Think of a shaft with cross-drilled holes at several angles, or a long part where you need access to four sides without re-clamping. The Ø400 mm rotary table we run handles most of these jobs in one setup.

A 5-axis center adds a second rotary axis so the tool can approach the part from almost any direction. The payoff is real on impellers, medical housings with undercuts, and any part where three separate 3-axis setups would stack three separate position errors. On simple prismatic work, 5-axis is slower to program and no more accurate than a well-fixtured 3-axis cut.

The decision rule we use: if the drawing forces more than two setups, or if a hole axis is more than about 30° off the primary face, move it to a machine with more axes.

Aluminium 6061-T6 is the default for prototypes and fixtures. It machines fast, holds ±0.005 mm on a rigid setup, and takes anodizing well. 7075 is stronger but more prone to distortion when you remove a lot of stock from one side; rough it, let it rest, then finish.

Stainless 303 is the free-machining grade and turns cleanly. 304 and 316L are tougher: they work-harden, they hold heat at the cutting edge, and they need slower surface speeds and heavier feeds to stay under the hardened layer. 17-4PH adds a heat-treat step that can move dimensions, so leave stock and finish after aging.

Titanium Ti-6Al-4V and Inconel are in a different class. Thermal conductivity is low, so heat stays in the tool. Tool life drops, cycle times climb, and thin walls deflect. If your part is a thin titanium rib, expect to plan around spring passes and light finishing cuts rather than one heavy pass.

Plastics are not automatically easier. POM and PEEK hold tight tolerances but move with temperature; ABS and PC can melt and smear if the chip is not evacuated. Climb milling and sharp, polished flutes matter more than spindle speed.

Tolerance and surface finish are linked. A Ra 0.2–0.8 μm finish usually needs a finishing pass with a small stepover, which takes time. A Ra 1.6–3.2 μm as-machined finish comes off the tool in one pass and costs much less. Specify the finish only where it does a job, such as a sealing face or a bearing bore.

The cost of tightening a tolerance is not linear. Going from ±0.05 mm to ±0.01 mm is routine. Going from ±0.01 mm to ±0.005 mm means temperature-controlled inspection, more in-process checks, and sometimes a different machine. On a 4,000 mm part, thermal expansion alone can eat that budget, so we measure at a controlled temperature and report the result.

Datums matter as much as numbers. If your drawing calls out a tight position tolerance but the datum feature is a rough cast surface, the machinist has nothing reliable to measure from. Define datums on machined faces, and keep the tolerance chain short.

A useful habit: mark only the features that truly need tight control. Everything else can carry a general tolerance note. That single change often cuts cycle time without touching function.

It starts with a DFM review. We check wall thickness, tool reach, thread depth and whether the tolerances can be measured. A drawing that asks for a 0.5 mm internal corner with a 12 mm deep pocket cannot be cut with a 0.5 mm tool at that depth, so the corner radius has to grow or the pocket has to be relieved.

Then fixturing. Soft jaws, vacuum plates and custom clamps all aim at the same thing: hold the part rigidly without deforming it. Thin-walled parts are the hard case. Clamp too hard and the part springs back after unclamping; clamp too light and it chatters. We often rough, stress-relieve and then finish with light clamping pressure.

Cutting comes next, with in-process checks at defined points. On a tight-tolerance job, the operator measures after roughing and again after finishing. If the part is drifting, we correct the offset before the last pass rather than scrapping the batch.

Final inspection is 100% before shipment. Raw material certificates, in-process records and final dimensional reports are available on request. That paperwork is what turns a machined part into a documented one.
