CNC Machining Instant Quotation: How the Number Is Built

• 1
  What an Instant Quote Actually Measures
• 2
  Geometry: Removed Volume Sets the Floor
• 3
  Material: Why 7075 Costs More Than 6061
• 4
  Tolerance and Finish: Where Quotes Go Wrong
• 5
  Setup Count and Machine Choice: 3-Axis vs 5-Axis
• 6
  When an Instant Quote Is Not Enough
• 7
  Step by Step: From Upload to a Trustworthy Number
• 8
  How Each Input Moves Price and Lead Time

An instant quote is a cost model running on the file you uploaded. It reads the solid model, estimates how much material must be removed, guesses how many times the part must be re-fixtured, and multiplies that by a shop rate. The result looks like a price. It is really a prediction about machining time.

That prediction is reliable when the part is simple. A rectangular aluminium bracket with two holes and one pocket will be quoted within a few percent of the real cost. The same model struggles with a thin-walled housing that needs five orientations and a custom soft jaw. Geometry that is hard to hold is hard to price.

So the first question to ask is not whether the number is low. It is whether the part is the kind of part the model understands. Machining time scales with removed volume, tool changes and fixturing, not with the number of features you drew.

For reference, GreatLight runs 127 high-precision CNC machines across 3 wholly-owned plants in Dongguan and Singapore, with 16 simultaneous 5-axis machining centers. Quotation and free DFM analysis come back within 12 hours, and production can start within 24 hours.

• 1
  Removed volumeStock minus finished part. The dominant term in machining time.
• 2
  Setup countEach new orientation adds fixturing, re-datum and first-article checks.
• 3
  Tolerance bandTighter bands force slower passes, more gauging and more scrap risk.

Roughing removes most of the material. A part cut from 50 × 50 × 25 mm stock down to a 40 × 40 × 10 mm plate leaves a lot of chips, and that roughing pass takes the longest single block of time in the program. Start from near-net stock and the quote drops before any other change.

Pocket depth matters as much as pocket area. A pocket 4× deeper than its cutter diameter needs a long tool, reduced feed and slower entry. A pocket 8× deeper may need a separate long-reach tool and a second operation. Both raise the price.

Thin walls behave differently. Below roughly 1 mm wall thickness in aluminium, and 0.8 mm in steel, the cutter pushes the wall instead of cutting it. The quote will include lighter passes, a support strategy or a stress-relief step. Those are not padding. They are what keeps the part in tolerance.

Undercuts and internal corners that no standard end mill can reach are the hardest to price. A corner radius smaller than 1 mm in a deep pocket may force EDM or a custom tool. Flag those before the quote is issued, not after.

• 1
  Use standard radiiPick a corner radius at least one third of the pocket depth.
• 2
  Start from near-net stockCast or forged blanks cut roughing time sharply.
• 3
  Avoid deep narrow slotsDepth over 4× tool diameter needs reduced feed.

Material price is the easy part. The harder part is machinability, and it changes cutting parameters. Aluminium 6061 machines fast with high spindle speeds and generous feed. Stainless 316 work-hardens if the cutter rubs, so the program uses a heavier chip load and a slower surface speed. That is more time per part.

Titanium TC4 (Ti-6Al-4V) is worse. It conducts heat poorly, so the cutting edge stays hot while the chip carries heat away slowly. Speeds drop, tool life shortens and coolant strategy becomes part of the quote. Inconel sits in the same family for cost purposes.

Plastics are not automatically cheap. POM and ABS cut quickly but hold burrs and can move after machining. PEEK costs more per kilogram than many metals and needs sharp, polished tooling. Carbon fibre is abrasive and wears carbide, so tool cost enters the price.

A practical rule: if two materials meet the functional requirement, quote both. The cheaper bar stock is not always the cheaper part.

• 1
  Aluminium 6061-T6The default for prototypes and brackets. Fast and stable.
• 2
  Stainless 303 vs 316L303 machines more freely. 316L is chosen for corrosion, not speed.
• 3
  17-4PHStrong and corrosion resistant. Condition matters for cutting.

A drawing covered in ±0.01 mm callouts is not automatically a precision part. Only a few dimensions usually control function: a bearing bore, a mating face, a shaft diameter. Mark those and leave the rest general. A quote built on a fully toleranced drawing will be higher than the part needs.

The same logic applies to surface finish. Ra 1.6–3.2 μm is a normal as-machined result. Ra 0.8–1.6 μm needs a controlled finishing pass. Ra 0.2–0.8 μm may need a separate operation. If the surface only needs to look clean, bead blasting is cheaper than chasing a finer cut.

Geometric tolerances are the quiet cost driver. Flatness, perpendicularity and true position all require either a single-setup strategy or a careful re-datum between setups. Datum features should be surfaces the machine can actually reach and clamp.

GreatLight holds ±0.005 mm (±0.0002 in) on critical features and inspects 100% of parts before shipment, with raw material check, in-process monitoring and final inspection. Reports are available on request.

• 1
  Tolerance only what mattersFunctional dimensions tight, the rest general.
• 2
  Pick datums you can clampA datum on a curved surface adds setup risk.
• 3
  Separate cosmetic from functionalBlasting is cheaper than a finer machined finish.

Setup count is the most underrated line in a quote. Each orientation needs a fixture, a zero point, a first-article check and a transfer between operations. Every transfer adds a small alignment error and a real amount of time.

A part with features on five faces can be run on a 3-axis machine in five setups, or on a 5-axis machine in one or two. The 5-axis route usually wins on tolerance because fewer transfers mean fewer stacked errors. The 3-axis route can still win on simple parts, where programming and fixturing are trivial.

Five-axis also allows the tool to approach at an angle, so shorter cutters can reach deep features. Shorter cutters deflect less. That often shows up as a better surface finish without any change to the drawing.

GreatLight runs 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. Maximum processing size is 4,000 mm, so long parts can be quoted without splitting the job.

• 1
  One setup beats fiveFewer transfers means less stacked tolerance error.
• 2
  Short cutters cut better5-axis angles let you reach deep with a stub tool.
• 3
  Mill-turn for round partsTurning and milling in one setup removes a transfer.

Some parts should never be released on an automated number alone. Parts with organic surfaces, deep cavities or features that need EDM usually need a programmer to look at the model first. The same applies to assemblies with mating tolerances across several components.

Prototype runs of one or two pieces are also worth a manual review. Setup dominates the cost at that quantity, and a small fixture change can move the price more than any material swap.

High-volume runs need a different conversation. At 10,000+ parts, tooling, cycle time and inspection strategy matter more than the first-part price. GreatLight has no minimum order quantity, so both ends of that range are quoted the same way.

Confidentiality is part of the process. Uploads are secure and confidential, and an NDA is available on request before any file is shared.

• 1
  Organic or freeform surfacesAsk for a manual review before releasing.
• 2
  Multi-part assembliesStacked tolerances need a human check.
• 3
  Very high volumeTooling and inspection planning change the cost base.
