CNC machining is subtractive. A cutter follows a toolpath and removes material until the remaining geometry matches the CAD model. For CNC machining Lexington engineers, the useful question is not what the machine can do in theory, but how much of the drawing the setup can reach without repositioning the part. Every reposition adds error.

A three-axis mill moves X, Y, and Z. The tool always approaches from one direction, so undercuts and deep side pockets need a second setup or a different tool. A five-axis center tilts the tool or the table, so the cutter can reach five faces in one fixturing. That is the real difference: not speed, but how many setups disappear.

Setup count drives cost more than spindle time on most prototype and low-volume work. A part that takes four setups on a three-axis machine may take one on a five-axis center. Fewer setups mean fewer datum transfers, and datum transfers are where stacked tolerance error comes from.

The cutting itself follows the same physics everywhere. Chip load, surface speed, and coolant strategy determine tool life and finish. What changes between shops is how tightly they control those variables and how they inspect the result.

• 1
  Three-axisSingle-direction access, best for prismatic parts with open faces.
• 2
  Four-axisAdds rotation around one axis, good for cylindrical and indexed work.
• 3
  Five-axisSimultaneous tilt and rotation, reaches five faces in one setup.

A tolerance of ±0.005 mm is achievable on a rigid setup with the right machine and a stable material. It is not achievable on every feature of every part. The limiting factors are thermal growth, tool deflection, and how the part is held.

Aluminum 6061 moves about 23 μm per meter per degree Celsius. A 100 mm feature that warms 5 °C during roughing shifts roughly 11 μm before finishing even starts. That is already over half of a ±0.005 mm window. Rough, let the part cool, then finish.

Thin walls deflect under cutting force. A 0.5 mm wall on a 40 mm tall pocket will push away from the cutter and spring back, leaving a taper. Adding a finishing pass at low radial engagement and high spindle speed reduces the load enough to hold the wall.

Not every dimension needs the tight number. Put ±0.005 mm on the features that mate or locate, and leave general dimensions at ±0.1 mm. Tightening everything raises cost without improving function, and it makes inspection slower.

• 1
  Fine finishRa 0.2–0.8 μm for sealing faces and sliding contact.
• 2
  Standard finishRa 0.8–1.6 μm covers most machined surfaces.
• 3
  As-machinedRa 1.6–3.2 μm is fine for non-functional faces.

The same toolpath that works in 6061 aluminum will fail in 316 stainless. Aluminum cuts fast and galls if the chip is not cleared. Stainless work-hardens when the cutter rubs instead of cuts, so feed per tooth has to stay high enough to bite under the hardened layer.

Titanium Ti-6Al-4V conducts heat poorly. The heat stays in the cutting edge, not the chip. Tool life drops fast unless speed comes down and coolant reaches the edge. A feature that takes 10 minutes in aluminum may take 40 minutes in Ti-6Al-4V.

Plastics behave differently again. POM and PEEK machine cleanly but hold internal stress, so a part hogged out of solid bar can move after machining. ABS and PC soften with heat and need sharp tools and air blast rather than flood coolant.

Inconel and other nickel alloys sit at the hard end. They are machinable with carbide and the right parameters, but cycle times are long and tool wear is high. That cost belongs in the quote from the start, not discovered at the machine.

• 1
  Aluminum6061, 7075, 2024, 6082, ADC12 and more.
• 2
  Stainless303, 304, 316L, 17-4PH, 440C.
• 3
  TitaniumTA1, TA2, TC4 (Ti-6Al-4V), Inconel.
• 4
  PlasticsPOM, PEEK, PA, PC, PMMA, ABS, HDPE.

Corner radii matter more than most drawings admit. A cutter has a diameter, so an internal corner can never be sharper than the tool radius. If the drawing calls for a 1 mm internal corner, the shop needs a 2 mm cutter, which limits depth and increases deflection.

Deep pockets need clearance for the holder, not just the cutter. A 6 mm cutter in a 50 mm deep pocket may need a necked holder that flexes. The result is chatter and a poor wall finish. Widening the pocket or splitting the feature usually costs less than fighting the geometry.

Threads, slots, and text follow the same rule. A laser-marked character below 1.5 mm height will not read cleanly. Fine threads in soft aluminum strip if the hole is not tapped with the right drill size.

Send a STEP file and a drawing with GD&T. The DFM review within 12 hours will flag the features that will not hold before the machine starts, not after the first article fails.

• 1
  Internal cornersNo sharper than the smallest practical cutter radius.
• 2
  Deep pocketsCheck holder clearance, not just cutter reach.
• 3
  EngravingMinimum character height 1.5 mm.

A tolerance is only real if it can be measured. A ±0.005 mm callout needs a CMM or a high-resolution gauge, and it needs a temperature-stable room. Measuring a hot part off the machine gives a number that changes as the part cools.

In-process monitoring catches drift before the part is finished. If a roughing pass leaves 0.3 mm instead of the planned 0.5 mm, the finishing pass has to remove more material than expected and may pull the wall. Checking between operations avoids that.

Final inspection before shipment covers dimensions, surface finish, and any specified plating or anodizing thickness. Reports are available on request. For regulated work, the certificates that matter are ISO 9001:2015, IATF 16949:2016, ISO 13485:2016, and ISO 27001:2022.

The goal is not to inspect quality into the part. It is to confirm that the process held and to catch the parts that drifted.

• 1
  Raw material checkVerify alloy and condition before cutting.
• 2
  In-processMeasure between operations to catch drift.
• 3
  Final100% inspection before shipment.

Local machining makes sense when the part is large, when the revision cycle is fast, or when a physical meeting saves a week of misunderstanding. A 4,000 mm rail is expensive to ship and hard to repackage. If the design is still moving, being able to walk a prototype across town has value.

For production parts with a frozen design, the calculation changes. The variables are tolerance capability, material availability, and how fast the supplier can return a first article. A shop with 127 high-precision CNC machines, including 16 simultaneous five-axis centers, can absorb a 10,000-part run without pushing out the prototype queue.

No minimum order quantity matters at the prototype stage. Being able to run one part and then scale to 10,000+ without changing suppliers removes a re-qualification step. The same process, same inspection, same certificates.

Confidentiality is a real constraint for defense, medical, and automotive work. Uploads should be secure, and an NDA should be available on request before the drawing is sent. That is standard practice, not a special favor.

• 1
  Quote and DFMWithin 12 hours of receiving files.
• 2
  Production startCan begin within 24 hours.
• 3
  DeliveryParts ship in 3–5 days.
