The CNC machining process definition is simple: a computer converts a part model into a sequence of machine commands, and a cutting tool removes material until the blank matches that model. Computer numerical control means the machine executes the commands without an operator turning handwheels. Everything else, the tooling, the fixtures, the inspection, follows from that idea.

The commands are G-code. Each line tells the controller where to move an axis, how fast to spin the spindle, how fast to feed the tool, and when to turn coolant on or off. On a 3-axis mill the axes are X, Y and Z. A 5-axis machine adds two rotary axes, so the tool can approach a face from an angle instead of only from the top.

Machining sits in one of two families. Turning rotates the workpiece against a single-point tool, which suits shafts, bushings and threaded parts. Milling rotates the tool and moves it across the workpiece, which suits pockets, slots and prismatic shapes. Mill-turn centers do both in one setup, which removes a re-chucking step and the error that comes with it.

• 1
  TurningWorkpiece spins. Best for round, symmetrical parts.
• 2
  MillingTool spins. Best for flats, pockets and complex contours.
• 3
  DrillingOften folded into milling on the same machine and setup.

CNC machining wins when tolerance matters more than unit cost at low volume. Metals such as 6061-T6 aluminum, 316L stainless, 17-4PH and Ti-6Al-4V all cut cleanly with the right feeds and tools. Plastics like POM, PEEK and ABS also machine well, though they need sharp tooling and lighter cuts to avoid melting or chipping.

The process is a poor fit for thin, large, flat panels. A 1 mm aluminum plate at 500 mm across will deflect under cutting force and chatter. Sheet metal fabrication bends that part faster and cheaper. Likewise, a hollow shell with internal ribs is easier to mold or cast than to carve out of solid stock.

Volume changes the answer. One prototype and a 10,000-part run are different problems. For runs above roughly 5,000 pieces, die casting or injection molding usually beats milling on unit cost, and machining becomes the finishing step for critical faces. Between one and a few thousand pieces, CNC is normally the fastest route to a usable part.

Hardness sets a ceiling too. Above roughly 45 HRC, carbide tooling wears quickly and the cut gets expensive. Pre-hardened 4140 at 28–32 HRC machines fine. Fully hardened tool steel above 55 HRC is usually ground, not milled.

• 1
  Good fitPrismatic metal parts, tight tolerances, low to mid volume.
• 2
  Poor fitVery thin walls, large flat panels, hollow shells with internal ribs.
• 3
  Watch the hardnessAbove 45 HRC, tool wear and cost rise sharply.

A CNC machine needs three inputs: a valid model, a program, and a fixed workpiece. If any one is missing or wrong, the run fails. The model is usually STEP or IGES, though native CAD files also work. 2D drawings still matter for tolerances, surface finish callouts and datum references that a 3D model cannot carry.

The program comes from CAM software. A programmer selects tools, sets stock size, defines the coordinate system and generates tool paths. The output is G-code, checked in a simulator before it ever reaches the machine. On a 5-axis job, collision checking between tool holder, fixture and workpiece is not optional. A single missed check can crash a spindle.

The workpiece must be held rigidly. Vises, chucks, collets and custom fixtures all do this, but the choice affects access. A part held in a vise cannot be cut on the bottom face without a second setup. A custom fixture costs more upfront and saves setups later. For a short run, the vise usually wins on total cost.

• 1
  ModelSTEP or IGES with a separate tolerance drawing.
• 2
  ProgramCAM output, simulated before the first cut.
• 3
  FixtureRigid hold, with tool access to every machined face.

Not every dimension needs the same tolerance. A general block can hold ±0.1 mm easily. A bearing bore might need ±0.005 mm. Each tight callout adds inspection time and sometimes a dedicated finishing pass. Put tight tolerances only where the function requires them, and the part gets cheaper without getting worse.

Surface finish works the same way. As-machined surfaces sit around Ra 1.6–3.2 μm. A controlled finish pass reaches Ra 0.8–1.6 μm. Fine finishes at Ra 0.2–0.8 μm usually mean slower feeds, smaller tools or a secondary operation, and they cost accordingly. Specify finish only on faces that see sealing, sliding or optical contact.

The tolerance you can hold also depends on the feature. A bored hole in a rigid setup holds tighter than a long thin wall. A 300 mm deep bore drifts more than a 30 mm one. When a print calls for ±0.005 mm on a thin cantilever, talk to the machinist before the run starts.

• 1
  Loose±0.1 mm general dimensions, no extra cost.
• 2
  Standard precision±0.02 mm on critical features, normal CAM effort.
• 3
  Tight±0.005 mm needs careful setup and inspection.

The most common problem is a model that looks fine and cuts badly. Sharp internal corners are the classic case. A rotating end mill always leaves a radius equal to its own radius, so a square corner needs either a smaller tool, a relieved design, or EDM. Adding a corner radius of at least 1 mm solves most of these issues at the design stage.

Deep pockets are the second. If a pocket is more than 4× the tool diameter deep, chip evacuation becomes the limiting factor and the tool may rub instead of cut. Either widen the pocket, reduce depth, or accept a larger corner radius so a stiffer tool fits.

Thin walls are the third. Aluminum walls below 1 mm and stainless walls below 1.5 mm tend to deflect and chatter. Chatter shows up as a wavy finish and a dimension that drifts along the wall. If the design needs a thin wall, expect slower cutting and extra support material.

Program errors are rarer than geometry problems but more expensive. Wrong work offset, wrong tool length, or a missing simulation check can break a tool or scrap a part. Our standard is to simulate every program, verify offsets with a probe and hold the first article until it passes inspection.

• 1
  Corner radiusAt least 1 mm internal radius, or plan for a smaller tool.
• 2
  Pocket depthKeep under 4× tool diameter where possible.
• 3
  Wall thickness1 mm minimum in aluminum, 1.5 mm in stainless.
• 4
  Hole depthBlind holes deeper than 6× diameter need a pilot and peck cycle.
