Milling removes metal with a rotating multi-tooth cutter while the workpiece stays clamped. Each tooth takes a small chip per revolution. The chip has a thickness, the tool has a rake angle, and the metal deforms plastically ahead of the edge. That deformation is where heat and force come from.

Three things limit the cut: tool strength, spindle power and heat leaving the zone. Push feed too high and the edge chips. Push it too low and the tool rubs, work-hardens the surface and wears fast. The window between those two failures is narrow on stainless and titanium, wide on aluminium.

The practical consequence is that CNC metal milling elements are not independent settings. Change the tool coating and the speed window moves. Change the workholding stiffness and the depth of cut you can take drops. Operators tune these together, not one at a time.

A 3-axis mill moves X, Y and Z. The tool always approaches from one direction, so every feature needs a clear line of sight from above or from the side. Undercuts, cross-drilled holes and deep pockets with curved floors usually need a second setup on another face.

Every extra setup adds a re-clamp, which adds positional error. A 4-axis mill adds a rotary table, typically Ø400 mm on our machines, so the part can index to four faces without leaving the fixture. A 5-axis center tilts the tool as well, letting a short rigid cutter reach angled walls in one pass.

The trade is not simply better with more axes. Five-axis motion is slower to program and to verify, and a tilted tool leaves a different surface pattern than a flat one. If a part is a plate with drilled holes, a 3-axis machine will make it faster and cheaper.

• 1
  3-axisFlat plates, housings with open faces, simple drilled patterns.
• 2
  4-axisShaft-like parts, multiple faces, holes on a bolt circle.
• 3
  5-axisImpellers, angled ports, deep cavities with one setup.

An end mill with more flutes has more cutting edges in the work per revolution, so it feeds faster at the same chip load. But more flutes means less chip clearance. In aluminium, a 3-flute tool clears chips well and runs at high speed. In steel, a 4 or 5-flute tool carries the load better.

Corner radius matters more than most drawings suggest. A sharp internal corner concentrates stress in the part and in the tool. Adding a radius to the cutter leaves a fillet that reduces both. It also lets the tool run faster, because the corner is no longer the weak point.

Reach is the quiet constraint. A tool that is long enough to reach the bottom of a deep pocket is also flexible. Deflection grows with the cube of the length, so a tool reaching 4× diameter deep will chatter unless depth of cut and feed come down. Sometimes the answer is a different setup, not a longer tool.

Aluminium 6061 and 7075 cut clean and fast, which is why prototypes so often start there. 7075 is stronger but less weldable and more prone to stress movement after roughing. Stainless 304 and 316 work-harden, so a light rubbing pass is worse than a firm one. Titanium Ti-6Al-4V conducts heat poorly, and the heat stays in the edge.

Hardness is not the whole story. Thermal conductivity decides where heat goes. In aluminium, most heat leaves with the chip. In titanium, it goes into the tool. That single difference explains why titanium runs at a fraction of the surface speed.

Our shop mills aluminium 6061, 2024, 5052, 6063, 6082 and 7075, stainless 303 through 17-4PH, steels including 4140 and 4340, copper and brass grades, titanium, Inconel and magnesium, plus engineering plastics such as POM and PEEK.

Surface speed, feed per tooth, axial depth and radial width are the four numbers that set a cut. For aluminium, cutting speeds commonly sit in the 300–600 m/min range. For 304 stainless, more like 80–150 m/min. For Ti-6Al-4V, 40–70 m/min. These are starting bands, not promises; the tool grade and coolant decide the top of the range.

Radial engagement is the lever most people under-use. Cutting at 70–100% of tool diameter is a slotting cut that loads the tool hard. Dropping radial width to 10–30% and increasing axial depth spreads the load along the flute. The tool runs cooler and the machine uses more of its rigidity.

Roughing and finishing want opposite settings. Roughing removes volume and cares about metal removal rate. Finishing cares about surface finish and dimensional accuracy. Running one pass to do both usually gives a worse finish and a shorter tool life than two separate passes.

A vise holds most prismatic parts. For thin plates, a vacuum chuck or a fixture plate with low-profile clamps works better because the part cannot bow. Thin walls move when the clamps release, and that movement shows up as an out-of-tolerance dimension.

Tolerance and finish are linked to the setup. Our machines hold ±0.005 mm (±0.0002 in) on well-fixtured features. Fine finishing reaches Ra 0.2–0.8 μm, a standard machined finish sits around Ra 1.6–3.2 μm. Asking for fine finish on a flexible wall is a different problem from asking for it on a solid block.

Inspection closes the loop. We check incoming material, monitor in process and inspect before shipment, with reports available on request. If a dimension is critical, say so on the drawing rather than leaving it to a general tolerance block.

The chain starts with a solid model, then a CAM programmer chooses tools, order of operations and stock. G-code and M-code come out of that step. The program is proven on the machine, often with a dry run or a reduced feed, before it cuts metal.

Fixtures are made or selected before the first cut. On a single part, the fixture can cost more than the machining time. That is why prototypes are often designed so that a standard vise and a soft jaw can hold them.

Finishing comes after milling. We offer anodizing, plating, powder coating, black oxide, bead blasting, polishing and laser marking. Masking a sealing face before anodizing is the kind of detail worth writing on the drawing early, because it changes the sequence.
