The first CNC milling project for beginners should be a flat plate with one pocket and four corner holes. Nothing else. The plate gives you a stable surface to clamp, the pocket teaches depth control, and the holes let you check position with calipers. A 100 × 100 × 12 mm blank in ABS or POM is enough. If you cut metal on day one, use 6061 aluminum and keep the depth of cut light.

Pick a 6 mm two-flute end mill for the pocket and a 5 mm spot drill for the holes. On plastic, run 12,000 rpm at 800 mm/min with a 1.5 mm stepdown. On 6061, drop to 6,000 rpm and 500 mm/min with a 0.5 mm stepdown, and add a few drops of cutting fluid. These numbers are starting points, not rules. Listen to the cut.

The mistake beginners make most often is clamping the plate on its edges so the middle bows upward. The cutter then takes a deeper bite in the center than at the walls, and the pocket floor comes out dished. Support the blank underneath with parallels or a sacrificial plate, and check that a feeler gauge will not slide under the middle.

After the cut, measure the pocket width, depth, and the hole-to-hole distance. Write the numbers down. A first part at ±0.1 mm is a fine result, and the record tells you what your machine actually does rather than what the datasheet says.

Project three is a slotted bracket: an outside profile, a 6 mm slot, and a counterbore. This is where you learn tool changes and work offsets. Machine the outside profile first while the part is still attached to the stock, then the slot, then the counterbore. If you cut the profile first, the part moves and every later feature lands in the wrong place.

Hold the bracket with step clamps on two sides and leave 3 mm of stock around the profile. Cut the slot with the same 6 mm end mill at full depth in two passes. A counterbore for an M4 socket head screw is Ø8 mm to a 4.5 mm depth; check that the screw head sits flush or slightly below the surface.

Project four is a small two-part assembly: a base with a pocket and a lid that fits into it with 0.1 mm clearance on each side. This is your first taste of tolerance stacking. Cut the pocket 0.2 mm undersize and the lid 0.2 mm oversize, then sneak up on the fit with light finishing passes. A snug slide fit is the goal, not a press fit.

This is also the project where you should start keeping a tool list. Note the tool number, diameter, flute count, and the feed and speed that worked. By the fifth part you will not need to guess.

For the fifth part, build something you will actually use: a motor mount, a sensor bracket, or a small fixture plate. Functional parts force you to think about bolt patterns, clearance holes, and how the part will be mounted in service. That is the shift from practice piece to real work.

A motor mount for a NEMA 23 stepper is a good choice. It needs four Ø5.5 mm holes on a 47.14 mm square pattern, a Ø38.1 mm pilot bore, and a 6.35 mm shaft clearance. Draw it in CAD at true size, then check the drawing against the motor datasheet before you cut. Half of all beginner scrap happens at this step.

Machine the pilot bore with a smaller end mill and a helical path, or use a boring head if you have one. A bored hole holds size better than an interpolated one. Aim for a bore that lets the motor register slip in with light hand pressure.

When the part is done, mount the motor and turn the shaft by hand. If it binds, the hole pattern is off. If it wobbles, the pilot bore is oversize. Either way you have a real diagnostic, which is worth more than a perfect-looking part that does nothing.

A hobby router with a 500 W spindle will cut plastic and aluminum, but slowly and with chatter. A benchtop mill with a 1.5 kW spindle and a rigid column is a different class of machine. Before you buy stock, measure the backlash on each axis and check the spindle runout with a dial indicator. If runout is over 0.02 mm, no toolpath will save your tolerance.

On material, match the alloy to the job. 6061-T6 machines cleanly and takes anodizing well. 7075 is stronger but gummier and will grab a small cutter if the chip load is too low. Brass C36000 is the easiest metal to learn on because chips break short and the surface comes out bright. Avoid 304 stainless for a first project; it work-hardens the moment the cutter rubs instead of cuts.

Facing is the operation that exposes a weak setup fastest. Run a facing pass across the whole blank first. If the surface shows chatter marks or a step in the middle, fix the workholding before you cut any feature.

Keep a dial indicator, a 0–150 mm caliper, and a set of gauge blocks on the bench. Those three tools cover almost every check a beginner project needs.
