A press brake does not cut or remove material. It traps a flat blank between a punch and a die, then drives the punch down so the sheet yields past its elastic limit. The metal takes a permanent set at the bottom of the stroke. Everything else — tonnage, tool geometry, backgauge position, crowning — exists only to control where that set happens and how even it stays across the part.

The CNC layer is the control system. It stores ram depth, ram speed, backgauge X and R positions, and the angle correction needed for each material batch. On a modern machine the controller also compensates for deflection in the bed and ram, so the middle of a 3,000 mm bend does not open up while the ends stay tight.

Why this matters to a design engineer: every bend consumes material length. The flat pattern you send to the shop is not the sum of your finished dimensions. If the bend deduction is wrong by 0.4 mm on a four-bend bracket, the hole pattern drifts and the part will not bolt to its mating plate.

This guide stays on the mechanics. It explains what happens inside the tooling, where the accuracy comes from, and when bending is the wrong process for a part.

Air bending dominates job shops because one punch and one die cover a wide angle range. The punch does not bottom out. The angle comes from how deep the ram travels. That is why a CNC braking technical guide always starts with the V-die opening, since it sets the inside radius, the required tonnage, and the minimum flange the part can carry.

A common starting rule is a V-die opening of 6 to 12 times the sheet thickness. Thin material near 1 mm runs closer to 6 × t to keep the inside radius tight. Plate at 6 mm and above drifts toward 10 × t or 12 × t because the tonnage climbs fast. For 3 mm mild steel, a 24 mm V-die is a normal choice. For 1.5 mm stainless, an 8 mm to 12 mm V-die is typical.

Tonnage per meter rises with thickness squared and falls with a wider V. Doubling thickness roughly quadruples the force. Stainless 304 needs about 1.5 times the tonnage of mild steel at the same thickness. Aluminum 6061 sits lower, near 0.6 times. If the calculated load exceeds the machine rating, widen the V or split the bend.

Flange length has a floor. A safe minimum is about 4 × t plus the inside radius. Go shorter and the punch cannot seat the material, the bend line wanders, and the operator is left fighting an angle that will not repeat.

• 1
  Wide V, lower forceWider opening cuts tonnage but opens the inside radius.
• 2
  Narrow V, tighter radiusWatch punch load and tool marking on soft alloys.
• 3
  Minimum flangeRoughly 4 × t plus the inside radius.
• 4
  Material factorStainless ≈ 1.5 ×, aluminum ≈ 0.6 × versus mild steel.

When metal bends, the outer fibers stretch and the inner fibers compress. One layer in between keeps its original length. That is the neutral axis. The K-factor is the position of that axis as a fraction of thickness, measured from the inside face. For air bending in mild steel it often lands between 0.33 and 0.45. For a tight radius it drops. For a large radius relative to thickness it rises toward 0.5.

Bend allowance is the arc length of the neutral axis through the bend. Bend deduction is what you subtract from the total flat length. CAD software computes both once you set the K-factor and inside radius. The trouble is that the real K-factor depends on material, tooling, and how the operator runs the stroke. A shop that bends the same alloy every day knows its number. A shop running mixed work has to verify.

Practical check: cut one blank, bend it, measure the finished outside dimensions. If the part is 0.3 mm long, adjust the deduction. On tight-tolerance brackets, always confirm the flat pattern from a first article rather than trusting a default library value.

Radius also matters for function. A sharp inside radius on 6061-T6 aluminum invites cracking at the outer surface. A generous radius costs almost nothing and removes the risk.

Every metal springs back a little when the punch releases. The amount depends on yield strength, thickness, and the inside radius. Mild steel might return 1° to 2°. Stainless 304 or 17-4PH can return 3° to 5°, and high-strength alloys go further. A machine without angle correction will fight this all day.

CNC controls handle springback in two ways. The first is over-bending: the controller drives the ram deeper by a stored correction so the material relaxes into the target angle. The second is in-process angle measurement, where sensors read the bend and the control adjusts the next stroke. Both depend on a stable material batch. Change the heat lot and the correction drifts.

Crowning tackles a different error. Under load, the ram and bed deflect in the middle. On a long bend the center angle opens while the ends stay closed. A crowned bed or a hydraulic crowning system pushes back against that deflection. Without it, a 2,500 mm bend can vary by more than a degree end to end.

Tool condition belongs in the same conversation. A worn punch tip or a nicked die shoulder transfers marks to the part and shifts the bend line. Keep tooling clean, and reserve a dedicated set for visible surfaces.

Sheet metal bending wins when the part is thin-walled, starts as flat stock, and carries mostly 90° or simple angles. An enclosure panel, a bracket, a chassis rail. Cycle time is short, material waste is low, and the same tooling runs thousands of parts. If the design stays inside a consistent thickness and a few standard radii, bending is the cheap path.

Machining wins when the part needs pockets, bores, threads, or faces that must sit in one setup. A bent bracket with a bored bearing seat usually becomes two operations: bend the blank, then machine the seat. That is normal, and it is how most real assemblies are built. The risk is tolerance stack-up between the formed face and the machined datum.

A part is a poor fit for bending when the flange is shorter than about 4 × t, when the inside radius must be smaller than the material can take without cracking, or when the bend line crosses a hole or a slot. Holes within roughly 2.5 × t of the bend line will distort. Move them or add a relief.

For prototypes, one more option exists. If the geometry is complex and the quantity is one or two, machining the whole part from solid plate often beats building tooling and fixtures for a bend. The cost per part is higher. The lead time is not.
