CNC precision bore grinding
This page explains how CNC precision bore grinding removes material inside a hole, why it holds size better than boring or reaming, and where it stops making sense. Written for engineers and buyers who need to judge a bore callout before they release a print.

In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
How CNC precision bore grinding actually cuts
Bore grinding is not boring with a better tool. A small vitrified or resin-bond wheel spins at high surface speed and enters the existing hole. Contact is a line or a small arc, not a full circle. That is why the wheel can take 0.005–0.05 mm of stock per pass without pushing the wall away from the tool.
The wheel rotates in one direction and the workpiece rotates slowly in the other. The two motions cross, so each abrasive grain leaves a short scratch instead of a continuous groove. Average surface roughness after a spark-out pass lands around Ra 0.2–0.8 μm on hardened steel. That finish comes from many shallow passes, not one heavy pass.
On a CNC machine, the wheel axis is dressed to a known diameter, then the control feeds it in on a programmed path. Infeed, dwell and spark-out are all counted in microns. The machine does not guess the wall position from the last cut; it tracks the wheel diameter and the commanded depth.
The wheel itself wears. A 20 mm wheel may lose a few microns of radius over a production run, so the control compensates or the operator re-dresses between parts. Ignore wheel wear and bores drift toward the low side of the tolerance band.
- 1Slow workpiece rotationTypically 50–200 rpm, so the grain path crosses instead of tracking.
- 2High wheel speedVitrified wheels often run 30–45 m/s surface speed.
- 3Small infeed0.005–0.05 mm per pass, plus a spark-out pass with no added depth.
When grinding beats boring, reaming or honing
Boring and reaming cut a hole to size with a single-point or multi-edge tool. They work well when the hole is short, the wall is stiff and the tolerance is loose, say ±0.025 mm. Once you need ±0.005 mm on a hardened part, the cutting edge deflects and the finish stops improving.
Grinding removes less material per pass, so cutting force stays low. Thin walls, long bores and interrupted features survive the process. A 0.8 mm wall in 17-4PH stainless can be ground to size where boring would spring the wall inward and leave a taper.
Honing is the other alternative. It uses longer abrasive stones and a stroke, which is good for straightness over a deep bore. Grinding wins when the hole is short, the geometry is interrupted, or the same machine must also grind a face, a seat or a chamfer in one setup.
There is a cost side. Grinding needs a dressed wheel, more passes and often a dedicated setup, so a ±0.05 mm hole in mild steel should stay on a mill or a lathe. Do not add a grinding operation just because the drawing says 'precision'. Add it when the tolerance, hardness or finish cannot be met any other way.
What decides the result: fixturing, wheel choice and dressing
The bore cannot be more round than the fixture that holds it. A three-jaw chuck clamps at three points and pushes the bore into a triangle. For tight roundness, we use a collet, a mandrel, or a castable low-melt fixture that supports the wall without point loads. Clamp force matters as much as clamp type.
Wheel choice follows the material. Aluminium oxide suits hardened steel and tool steel. Silicon carbide handles cast iron and non-ferrous work. Diamond or CBN cuts carbide, hardened stainless above 45 HRC, and superalloys such as Inconel. Grain size sets the finish: coarse for stock removal, fine for the last 0.02 mm.
Dressing restores the wheel shape and opens the grain. A dull, loaded wheel rubs instead of cutting, and the bore heats up. Dress depth is usually 0.01–0.03 mm per pass. On a CNC machine the dress cycle runs between parts, so the wheel diameter stays predictable.
Coolant does three jobs: it carries heat away, flushes chips and keeps the wheel from loading. Through-spindle or high-pressure coolant reaches the contact zone better than a flood nozzle aimed at the top of the hole. On deep bores, chip evacuation is the limiting factor, not wheel speed.
- 1Roundness follows the fixtureAvoid three-point clamping on thin walls.
- 2Abrasive follows the materialAluminium oxide, silicon carbide, diamond or CBN.
- 3Dressing keeps size honest0.01–0.03 mm per dress pass, between parts.
Blind bores, interrupted cuts and thin walls
A blind bore limits wheel travel. The wheel needs clearance at the bottom, so the undercut or relief must be wide enough for the wheel corner. If the print calls a flat bottom and a sharp corner, grinding cannot reach it. Add a corner radius or a relief groove at the design stage.
Interrupted bores, such as keyways or cross holes, hit the wheel once per revolution. The impact can chip the abrasive and change the effective diameter. We slow the infeed and use a tougher bond for these parts, or grind before the interruption is cut when the sequence allows it.
Thin walls deflect under clamping and under cutting force. Roundness after unclamping can move out of tolerance even if the bore measured perfect on the machine. Support the outside diameter with a fixture that matches the wall, and measure the part free of the clamp.
Deep bores create a second problem: the wheel arbor bends. The length-to-diameter ratio of the arbor sets the practical depth. Past roughly 4:1, we step down to a smaller wheel or switch to a different process. A 60 mm deep Ø12 mm bore is reasonable. A 300 mm deep Ø12 mm bore is not a grinding job.
- 1Blind bore clearanceAllow a relief groove or a corner radius for the wheel.
- 2Interrupted featuresLower infeed and a tougher bond resist chipping.
- 3Arbor ratioPast about 4:1, arbor deflection limits the depth.
Which materials and parts suit the process
Hardened steel is the classic case. A 4140 or 4340 part heat treated to 50–60 HRC cannot be bored with carbide to a fine finish, so the bore is ground after hardening. Tool steel and 440C stainless behave the same way. Grinding after heat treat also removes the slight distortion that quenching leaves behind.
Stainless 17-4PH and 316L are common in medical and food-contact parts. They work-harden under a dull tool, so a sharp, freshly dressed wheel matters more than on carbon steel. Titanium TC4 and Inconel are gummy and heat-resistant; they need low wheel speed, generous coolant and lighter passes.
Aluminium and brass grind well but rarely need it. If a bore in 6061 only calls ±0.025 mm, a boring bar on a mill or lathe is faster and cheaper. Grinding enters the picture when the bore is very small, when the finish must be near-mirror, or when the part also carries a hardened insert.
Typical parts include hydraulic valve bodies, fuel injector sleeves, bearing seats, spindle housings, medical instrument bores and robotics joint bores. In each case the bore sets the fit, the wear life or the sealing surface, and a few microns decide whether the assembly passes.
How the bore is measured and controlled
An inside micrometer or a bore gauge gives size at a point. It does not tell you roundness or taper. For a ±0.005 mm bore, size alone is not enough. Roundness, cylindricity and taper must be checked against the drawing, and a two-point measurement can miss a three-lobed bore entirely.
Air gauging reads the average clearance around the bore and is fast enough for production. A dial bore gauge with a setting ring is slower but does not need a special fixture. For low-volume work we set the gauge with a ring or a calibrated master, then record readings at three depths and two planes.
On the machine, an in-process gauge or a touch probe can correct the last passes. This keeps wheel wear from pushing a run out of tolerance. Final inspection happens off the machine, with the part at room temperature, because a warm bore measures larger than it is.
We inspect every part before shipment and can supply dimensional reports on request. Raw material certificates, in-process checks and final reports cover the chain from stock to packed box. When a bore is critical, agree the measurement method with us before the first cut, not after.
- 1Size is not roundnessA two-point gauge can miss a lobed bore.
- 2Air gaugingFast, average clearance reading, good for production.
- 3Measure coldWarm parts read oversize; let them settle.
Bore grinding compared with boring, reaming and honing
Judgment depends on tolerance, hardness, bore length and geometry, not on habit.
| Process | Typical tolerance | Hardness range | Best fit |
|---|---|---|---|
| CNC bore grinding | ±0.005 mm | Up to 65 HRC | Hardened, thin-wall or interrupted bores |
| Fine boring | ±0.013–0.025 mm | Up to 40 HRC | Short bores in soft steel and aluminium |
| Reaming | ±0.013 mm | Up to 35 HRC | Straight through holes, one diameter |
| Honing | ±0.005 mm | Up to 60 HRC | Long bores needing straightness |
| Jig grinding | ±0.005 mm | Up to 65 HRC | Bore plus hole-pattern position |
The verdict on bore grinding
If the bore is hardened, thin-walled or held tighter than ±0.013 mm, CNC precision bore grinding is the right call. If it is a soft, short hole at ±0.025 mm or looser, boring or reaming will be faster and cheaper, and we will say so at quote.
Bore grinding questions engineers ask
What tolerance can CNC precision bore grinding hold?
Our general machining tolerance is ±0.005 mm (±0.0002 in) on ground bores, with surface finish from Ra 0.2–0.8 μm on a fine ground pass. The achievable number still depends on the bore diameter, depth, wall thickness and material.
A short bore in hardened steel is easier to hold than a deep bore in a thin wall. Share the full drawing and we will confirm what the setup can repeat.
Can you grind a bore after heat treatment?
Yes. Grinding after hardening is one of the main reasons to use the process. The wheel cuts material at 50–65 HRC that a boring tool cannot finish, and it also cleans up the slight distortion from quenching.
Sequence matters. We rough before heat treat, leave grinding stock, then finish the bore after the part has stabilized.
How do I specify a bore on the drawing?
Give the nominal diameter, the tolerance class or limit, the depth, and any roundness or cylindricity callout. Add the surface finish requirement and the datum if the bore locates another feature.
If the bore is blind, give the corner radius or relief groove. A sharp internal corner and a ground finish cannot both be met at the same spot.
Does grinding add a lot of cost?
It adds a setup and a slower cycle, so it costs more than boring. The trade is a bore that holds size and finish on a hardened or thin-wall part.
If the tolerance does not require it, we recommend the cheaper process. There is no minimum order quantity, so a single prototype bore can be ground and measured the same way as a production run.
What lead time should I expect?
Quotation and free DFM analysis come back within 12 hours. Production can start within 24 hours after the drawing is settled, and parts ship in 3–5 days.
Bore grinding usually sits late in the sequence, after heat treat, so the schedule depends on when the part reaches the grinder.
Can you work from a 3D model or a print only?
Both work. A STEP file plus a drawing that carries the bore tolerance and finish is ideal. If you only have a model, call out the critical bores in a note or in the email.
Uploads stay secure and confidential, and we can sign an NDA before you send the files.
