A biological part is any machined component that touches the body, contacts sterile tissue, or sits inside a fluid path that reaches a patient. That covers bone screws, dental abutments, surgical forceps, pump housings, biopsy cutters, and the fixture plates that hold a sample. The common thread is not the shape. It is the requirement that the part must not introduce contamination, corrode in a wet environment, or fail after a known number of cycles.

When we quote CNC processing biological parts, the first question is not tolerance. It is exposure. A part that only touches intact skin has a different finish and cleaning route than one in contact with blood for 30 days. Engineers usually know the intended use but leave the exposure class out of the drawing. Put it in the notes. It changes material choice, passivation, and how much documentation travels with the shipment.

Most biological parts are low volume compared with automotive work. A surgical instrument line may run 200 units a year. An implant trial may be 12 pieces. CNC suits that pattern because there is no tooling to amortize. A mill-turn center can cut a titanium bone plate in one setup, and the same program can be adjusted for a revised hole pattern without a new mold.

• 1
  Direct contactTouches tissue or blood; cleaning and finish matter most.
• 2
  Indirect contactSits in a fluid or air path; corrosion and leachables matter.
• 3
  Equipment onlyInstrument trays, fixtures, and housings outside the body.

Titanium is the default for load-bearing implants. Ti-6Al-4V (TC4) gives high strength at roughly half the density of stainless, and it forms a stable oxide layer that resists body fluid. The trade-off is heat. Titanium conducts heat poorly, so cutting edges run hot and tools wear fast. We keep surface speed low, use abundant coolant, and accept that a titanium bone plate takes longer than the same plate in 316L.

Stainless 316L and 17-4PH cover instruments, cannulas, and temporary fixation. 316L is easy to passivate and weld; 17-4PH can be precipitation hardened to reach higher strength for a drill guide or a reamer shaft. 420 and 440C hold an edge, which is why they show up in scalpel handles and cutter blades, but they need a passivation step after machining to remove free iron from the surface.

PEEK and POM appear where metal would block imaging or create a stress shield. PEEK is machinable to tight tolerance, tolerates autoclave cycles, and is radiolucent. POM is cheaper and easier to cut but softens at lower temperature, so it suits jigs and trial fittings rather than long-term implants. For any polymer, the chips must be cleared and the part washed, because plastic swarf clings to edges.

• 1
  Ti-6Al-4VLoad-bearing implants; slow speeds, heavy coolant.
• 2
  316L / 17-4PHInstruments and fixation; passivate after cutting.
• 3
  PEEKRadiolucent, autoclavable, tight-tolerance polymer parts.
• 4
  420 / 440CCutting edges; free iron removal is mandatory.

Bone plates, cranial mesh, and dental frameworks are not boxes. They are free-form surfaces that have to sit flush against an irregular contour. On a 3-axis machine, each face needs its own setup, and every re-clamp adds stack-up error. With 16 simultaneous 5-axis machining centers, we cut a contoured plate from one datum, so the hole axes and the seating surface stay related to each other within the same tolerance band.

Simultaneous 5-axis also lets a short, stiff tool reach undercuts and blended fillets that a long tool cannot. That matters for the transition between a screw hole and a curved plate face. A long tool deflects, leaves chatter, and forces a hand blend. A stub tool on a tilting head produces the blend in the cut, and the surface comes off the machine at Ra 0.8–1.6 μm without a polishing step.

For long parts, the 4,000 mm travel handles one-piece spinal rods and instrumentation shafts. For small dense work such as a dental abutment, the 500 × 310 × 200 mm envelope with a Ø400 mm rotary table is the right cell. The rotary table indexes the part so five faces are cut without operator intervention. Fewer setups means fewer chances to lose the datum.

• 1
  One datumContoured faces and hole axes machined in the same setup.
• 2
  Stub toolingLess deflection, blend produced in the cut.
• 3
  Ø400 mm tableFive faces indexed automatically for small implants.

We hold ±0.005 mm (±0.0002 in) on critical features. That number is not applied to every dimension. It is applied where the drawing calls it out, usually a bearing bore, a taper, or a mating face. Putting a blanket tight tolerance on a whole print raises the price and does not improve function. Mark the two or three features that decide fit, and let the rest run at general tolerance.

Surface finish drives cleaning as much as it drives friction. A rough surface with Ra 3.2 μm has valleys that trap polishing media, blood residue, and bacteria. For tissue contact we aim at Ra 0.8–1.6 μm as a machined baseline, and Ra 0.2–0.8 μm where the part slides against another surface. A finer finish is not always better: a mirror-polished implant can reduce bone ongrowth, so some surfaces are intentionally left rougher.

The finish also sets the inspection method. A Ra 0.4 μm bore can be checked with a profilometer stylus, but the stylus needs a clear approach path. If the bore is deep and narrow, we cut a coupon from the same setup and measure that instead, or use an optical method. Agree on the measurement method before the first chip, not after.

• 1
  Call out critical featuresBlanket tight tolerance adds cost without benefit.
• 2
  Ra 0.8–1.6 μmTissue-contact baseline straight off the machine.
• 3
  Ra 0.2–0.8 μmSliding and sealing surfaces.
• 4
  Optical checkUse when a stylus cannot reach the surface.

Cleaning is a process step, not a final wipe. After machining, parts carry cutting fluid, fine chips, and a disturbed surface layer. Stainless parts go through passivation to restore the chromium oxide film and remove embedded iron from tooling. Titanium gets an acid clean to strip the alpha case left by heat and to remove any iron transfer from steel tooling. Both steps go into the router before finishing, not after packaging.

Deburring comes first. A hand file or a brush leaves a rolled edge that traps particles. We use controlled edge breaks, then a tumbling or bead-blast step depending on the finish callout. Bead blasting gives a uniform matte surface that hides tool marks; polishing gives a reflective surface but can round a sharp edge. Choose per feature, not per part.

For implantable parts, the last operation is often laser marking. We can mark data matrix codes and lot numbers at a minimum character height of 1.5 mm. Marking after cleaning keeps the mark legible and avoids re-contaminating a clean surface. If the mark is on a wear surface, tell us, because a laser mark changes the local finish.

• 1
  Passivate stainlessRestores oxide film, removes free iron.
• 2
  Acid clean titaniumRemoves alpha case and iron transfer.
• 3
  Controlled edge breakPrevents particle traps better than hand filing.
• 4
  Mark after cleaning1.5 mm minimum character height.

Every part is inspected before shipment. The sequence is raw material check, in-process monitoring, and final inspection. For a biological part, the final inspection report is usually required by the customer's quality system, so we build the report as the parts are made rather than reconstructing it later. Reports are available on request.

We run ISO 9001:2015, IATF 16949:2016, ISO 13485:2016, and ISO 27001:2022. ISO 13485 covers the medical device quality path and is the certificate most relevant to biological parts. It does not replace the customer's own regulatory submission. It supports it by keeping traceability, calibration records, and nonconformance handling in a system an auditor can follow.

The qualification rate across our production is 99.99%. That figure comes from measuring every shipped part, not from sampling. When a feature is hard to measure in the machine, we move the part to a temperature-stable inspection room and re-datum it. If a dimension is out, we tell you before shipment and propose a rework route rather than shipping and hoping.
