Every supplier page says high precision. The useful question is which features get measured and with what instrument. A part can be held at ±0.005 mm on a bearing bore and sit at ±0.1 mm on a mounting flange, and that is usually fine. Ask the supplier to mark up your drawing with the features they will inspect at the tight band.

Surface finish follows the same logic. Ra 0.2–0.8 μm needs a separate finishing pass and sometimes a different tool. If your print calls for Ra 0.8–1.6 μm on a sealing face, say so at quote time. Adding it after the first article means a second setup, and a second setup usually means a second price.

For Orange County work in aerospace and medical, a lot of parts are small and feature-dense. Small tools deflect. A 3 mm end mill cutting a 30 mm deep pocket will wander unless the shop uses a stub tool or a smaller stepdown with a 0.1–0.2 mm finishing pass. That is a process choice, not a machine choice.

• 1
  Send a marked-up printHighlight the three or four features that actually matter. Shops quote tighter when the scope is clear.
• 2
  Separate cosmetic from functionalA bead-blasted cover does not need Ra 0.4 μm.
• 3
  Ask for the inspection report formatFirst article, in-process, and final are three different documents.

Suppliers quote lead time as one number. Break it into three. The quote and DFM feedback come first, then material and programming, then machining and inspection. A shop that answers in 12 hours and starts cutting within 24 hours is not the same as one that answers in three days.

For a first article, the real question is when you can hold the part and check it against the print. Ask for the date the first article ships, not the date the job enters the queue. Parts typically ship in 3–5 days once production starts, but that window assumes the material is in stock and the print is frozen.

Late risk is worth asking about directly. A supplier tracking their own on-time rate can tell you what percentage of jobs slipped. Anything under 2% late delivery is a healthy number for job-shop work. If nobody can answer the question, that is your answer.

• 1
  Freeze the revisionA rev change after programming restarts the clock.
• 2
  Confirm material stock7075 and Ti-6Al-4V plate are not always on the shelf.
• 3
  Ask who inspectsIn-house CMM versus outsourced changes the turnaround.

Certification is a filter, not a ranking. ISO 9001:2015 covers general quality management. IATF 16949:2016 is what automotive and EV programs expect. ISO 13485:2016 is the medical device standard. ISO 27001:2022 covers information security, which matters when you are uploading proprietary CAD.

For a CNC processing Orange County service supporting aerospace, automotive, and medical customers, the supplier should be able to show which certificate covers which plant. Certificates are issued per site. A group holding a certificate at one factory does not automatically cover a second factory.

Traceability runs alongside certification. Ask whether material certs come with the shipment, whether heat lot numbers are recorded, and whether the inspection data is archived against the part serial. In medical and aerospace work, that record is often the deliverable, not just the part.

• 1
  Check the site on the certificateThe address must match the plant doing the work.
• 2
  Ask for material certsMill certs with heat numbers, not a generic statement.
• 3
  Confirm NDA before uploadSign it before CAD leaves your network.

Minimum order quantity is the quiet cost driver. A shop with a 500-piece minimum forces you to order 500 parts before the design is settled. A shop with no minimum lets you run one part, test it, and change the model without eating inventory.

Unit price on a prototype is mostly setup and programming, not cutting time. That is why a 1-piece and a 10-piece quote can look almost identical at the top. When you compare quotes, ask for the setup charge and the per-part price separately. A low unit price with a large setup fee is a bad deal for a one-off.

Volume pricing should step down in a predictable way. If the 100-piece and 1,000-piece quotes differ by less than 20%, the shop is probably not changing its process. Real volume work moves to bar feeders, dedicated fixtures, or hard tooling, and the price reflects that.

• 1
  Ask for the setup line itemIt separates real cost from sales math.
• 2
  Test before volumeRun one part, measure it, then commit.
• 3
  Check the quote validity windowMaterial prices move. A 30-day window is normal.

A shop that runs aluminum all day will quote your 17-4PH stainless, but the learning curve shows up in the cycle time. Ask what they cut most often. Aluminum 6061 and 7075, stainless 303 and 304, and steel 1018 and 4140 are common ground. Titanium TC4 (Ti-6Al-4V) and Inconel are a different category: slow speeds, heavy tool wear, and coolant pressure matter more than spindle speed.

Finishes are usually outsourced, which adds a vendor in the chain. Anodizing, electroless nickel, zinc and gold plating, powder coating, and black oxide are standard. Bead blasting, tumbling, and polishing handle cosmetic requirements. Laser marking is fine down to a minimum character height of 1.5 mm; below that, the mark becomes unreadable and the shop should tell you.

If your part needs a finish before assembly, plan the sequence. A masked anodize on a threaded hole costs more than an unmasked one. Hardcoat anodizing changes dimensions by roughly half the coating thickness per surface, so tight bores need to be cut undersize before coating.

• 1
  Name the alloy and temper6061-T6 and 6061-O machine very differently.
• 2
  Ask where finishing happensIn-house or subcontracted changes lead time.
• 3
  Plan coating allowanceHardcoat builds dimension. Cut accordingly.

A quote that returns only a price and a lead time is not enough to make a decision. A useful response includes DFM notes: thinner walls that will chatter, holes too deep for the tool, tolerances that cannot be held at that feature size, and any datum that is hard to reach in one setup.

It should also state the machining route. If the supplier plans 5-axis for a part that could run on a 3-axis mill, you are paying for capability you do not need. If they plan 3-axis for a part with undercuts, you will get a multi-setup job with alignment error.

Finally, the quote should name the inspection plan. First article with a dimensional report, in-process checks on critical features, and a final inspection before shipment. If the part is going into a regulated assembly, the reports travel with it.

• 1
  DFM notes in writingA phone call is not a record.
• 2
  Machining route stated3-axis, 4-axis, 5-axis, or mill-turn.
• 3
  Inspection plan namedFirst article, in-process, final.

The first mistake is quoting a STEP file with no drawing. A model shows geometry, not tolerance, datum, finish, or material condition. Shops guess, and guesses come back as change orders.

The second is choosing on unit price alone. Two quotes 30% apart usually reflect different setups, different inspection levels, or different material sources. Ask what changed before you take the cheaper one.

The third is ignoring the shipping and communication time zone. A supplier in Asia can serve an Orange County team well if the handoff is structured: drawings reviewed overnight, questions answered in the morning, first article shipped by the end of the week. Without that structure, the time difference becomes delay.

• 1
  No drawing, no quoteTolerance and finish belong on paper.
• 2
  Price gaps need explanationAsk what is different, not who is cheaper.
• 3
  Set a handoff windowOne reviewed drawing pack per revision.
