Metal cutting removes material by plastic deformation and shear. Polymer cutting does something different. The edge pushes a small zone ahead of it into a rubbery state, then fractures it. That zone is soft, springy, and hard to predict. A sharp flute with a high rake angle shears cleanly. A dull flute rubs, heats the wall, and leaves a smeared finish that looks polished but measures wrong.

The elastic recovery is the part most drawings ignore. After the edge passes, plastic springs back toward the tool. Cut a slot and the wall pushes inward by a few hundredths of a millimeter. On a 6 mm deep pocket in unfilled POM, that recovery can eat half of a ±0.05 mm window. Filled grades such as 30% glass PEEK recover far less because the fiber network resists it.

Chip evacuation decides the outcome. Plastic chips are light and cling. They wrap around the tool, rub the finished wall, and trap heat. Air blast beats flood coolant for most grades because it clears the chip and cools the edge without a thermal shock. For deep pockets, a through-spindle air line and a short peck cycle keep the flutes open.

The practical rule: treat a plastic cut as a heat and spring problem, not a hardness problem. Pick a two or three flute end mill with polished flutes, keep the chipload light, and let the air do the clearing work. The spindle does not need to run at its ceiling.

Stiffness separates the grades that machine well from the ones that fight back. ABS, PC, PMMA, POM, PA, PP, HDPE, PEEK, and carbon fiber all cut on a CNC. They do not behave the same. POM and PEEK hold a tolerance with little fuss. PP and HDPE flex under the clamp and spring back after the cut, so they need light passes and soft jaws.

POM is the default for tight mechanical parts. It has low friction, good dimensional stability, and cuts to a clean edge. Watch its thermal expansion: a long POM part measured hot will shrink as it cools. PC is tough and takes impact, but it scratches and stress-cracks near sharp inside corners. Add a fillet where you can.

PEEK and carbon fiber are the high-end choices. They cost more, wear tools faster, and need slower feeds. In return they hold strength at temperature and resist chemicals that destroy other grades. Use them when the part must survive a hot or aggressive environment, not just because the datasheet looks strong.

PMMA gives optical clarity but chips brittle. Support the exit edge with a backing plate or a light climb cut. PA absorbs moisture and moves after machining, so control the shop humidity or accept a wider tolerance window. If a grade absorbs water, machine it, then measure it a day later before you sign off.

Plastic has a narrow cutting window. Too slow and the edge rubs, generating heat that softens the wall. Too fast and the same thing happens from friction. The sweet spot is a light chipload at a moderate surface speed, with enough flute clearance to throw the chip clear.

For POM with a 6 mm two-flute end mill, a starting point is 8,000 to 12,000 rpm and 1,200 to 2,000 mm/min feed, giving a chipload near 0.05 to 0.10 mm per tooth. For PEEK, drop to 4,000 to 6,000 rpm and 500 to 900 mm/min. These are starting points, not recipes. Listen to the cut and watch the chip color.

Chipload matters more than spindle speed. A heavy chipload in soft plastic pulls the part into the tool and tears the wall. A chipload that is too light rubs and glazes the surface. The chip tells you which is happening. A clean chip curls off and leaves the wall cool. A gummy chip means the edge is rubbing.

Depth of cut should stay shallow on thin walls. A 0.5 mm radial stepover on a 2 mm wall keeps the load low and limits deflection. Rough with a larger tool, then finish with a smaller one at a light stepover. This two-tool approach controls both heat and spring back in one pass.

Plastic parts move when you clamp them. A vise tightened like steel will bow a plastic block and cut a shape that springs out of tolerance when released. Soft jaws machined to the part profile spread the load and keep the force low. For thin plates, vacuum fixturing or double-sided tape on a flat plate is often better than any clamp.

Support the exit edge. When a cutter breaks through the far side of a plastic wall, the material chips and tears. Back the part with a sacrificial plate of the same or softer material. This is standard for PMMA and other brittle grades. For a through hole, drill from both sides or use a pilot and a reamer.

Heat from clamping is real but slow. A part held for an hour in a tight vise can creep. Use light pressure and check the size after the part has sat at room temperature. If a plastic part matters, measure it cold, not off the machine.

For long parts, support along the length. A 4,000 mm plastic extrusion will sag and chatter in the middle. Use multiple supports, keep the tool close to a support, and reduce the depth of cut near unsupported spans. Rigidity comes from the setup, not from the plastic.

As-machined plastic finishes land near Ra 1.6 to 3.2 μm with a sharp tool and a clean cut. A finer finish of Ra 0.8 to 1.6 μm needs a light finishing pass with a polished flute and a small stepover. Below Ra 0.8 μm, plastic is hard to hold because the material smears rather than cuts. Set the finish callout to what the function needs.

Bead blasting gives a matte surface and hides tool marks. Tumbling softens edges and removes burrs on small parts. Brushing and polishing work on acrylic and PC where clarity matters. Laser marking works on most grades; keep character height at 1.5 mm or more so the mark stays legible after any secondary step.

Anodizing and plating do not apply to plastics. Those are metal finishes. For plastic parts, the useful options are blasting, tumbling, brushing, polishing, and laser marking. If a drawing calls for a conductive or hard surface, that part is probably metal, not polymer.

Machined plastic often goes straight into service with no coating. The main post-step is cleaning. Blow out chips, wipe with a compatible solvent, and check that no coolant or tape residue remains. A clean part avoids stress cracking later, especially on PC and acrylic.
