A mold is a negative of the part it makes. Every surface on the core or cavity is transferred to the plastic, the aluminium or the stamping blank. CNC processing mold manufacturing is not just a shape decision. It sets the wall thickness, the shut-off, the vent depth and the surface the part will carry.

The process builds that negative by subtracting material from a solid block. A rotating tool follows programmed coordinates and strips material in passes. The machine holds the block, the spindle turns the tool, and the control moves the tool along X, Y and Z. On a three-axis machine the tool axis never changes. On a five-axis machine the tool tilts, so undercuts and steep walls can be reached in one setup.

Cutting data drives the result more than the machine brand does. A 12 mm carbide end mill in P20 steel typically runs at 180–250 m/min surface speed with 0.1–0.2 mm feed per tooth. Drop to a 3 mm tool for a rib and the same spindle speed will chatter unless you shorten the gauge length and reduce radial engagement.

Heat is the quiet variable. Roughing leaves 0.3–0.5 mm of stock for finishing, partly to remove the work-hardened skin left by the previous pass. Skip that allowance on a hardened insert and the finish pass will cut through hard and soft bands, and the wall will spring.

Most mold plates start on a three-axis mill. The cavity is opened, the mounting pockets are cut, and the water lines are drilled. This is fast and cheap per cubic centimeter of removed material. It stops being enough when the part has a deep rib, a drafted wall or a curved parting line that a vertical tool cannot reach without a long, thin cutter.

A four-axis machine adds a rotary table, usually Ø400 mm class. The block turns while the tool stays vertical. This suits cylindrical cores, thread cores and parts that need features on four sides in one setup. Positional work is the main use. Simultaneous four-axis motion is rarer.

Five-axis machining is where complex geometry becomes practical. The tool tilts to follow the surface normal, so a ball nose cutter can finish a deep cavity with a short flute length. Short tools deflect less. That is the real gain, not the axis count. A 16-machine five-axis cell will hold ±0.005 mm on a cavity wall where a three-axis setup with an extension holder would drift.

The trade-off is programming time and setup discipline. A five-axis finishing path takes longer to generate and longer to verify. For a flat plate with simple pockets, it is wasted money. For a mold core with 40 mm of wall height and 2° draft, it is usually the only way to hit the drawing.

CNC cutting is best on a single block of known material. It struggles when the geometry needs a hollow internal channel that no tool can reach. Conformal cooling channels fall into that group. So do thin, deep ribs under 1.5 mm wide at more than 8× depth.

Hardness is the other boundary. Pre-hardened steel at 30–34 HRC cuts fine with carbide. Above 45 HRC the tool life drops and the finishing strategy changes to smaller stepovers and slower feed. Many shops cut the cavity soft, then send the block for hardening and a final grind or EDM pass.

Size sets a ceiling too. GreatLight machines up to 4,000 mm on the largest travel. Beyond that, the block has to be split, and splitting means a joint line that shows on the part. A visible witness line is often worse than a slower process.

When a mold needs a mirror finish on a curved optical surface, CNC gets it close and then polishing takes over. We machine to Ra 0.2–0.8 μm on a good day, but that is not the same as a polished Class A surface. Plan the handwork in the quote.

Shrinkage is a mold design input, not a machining input, but it decides how much stock the machinist leaves. ABS shrinks about 0.4–0.7%, PP about 1.0–2.5%, and glass-filled grades less than the unfilled versions. If the cavity is cut to the nominal part size, the part comes out undersized and the mold is scrap.

Draft angle is the second number. A textured wall needs 1.5–3° of draft, a polished wall needs 0.5–1°. CNC processing mold manufacturing can hold those angles precisely, but only if the CAD model already carries them. Adding draft after machining means welding or recutting.

Vent depth is where the finish pass earns its keep. A 0.02–0.03 mm vent at the parting line is enough to pass air and not enough to flash most plastics. Cut that with a worn tool and the burr closes the vent. Then the part burns in the last-filled corner.

Fit between insert and pocket is the third. A typical insert pocket runs 0.01–0.02 mm over the insert size for a light press. Too tight and the insert cracks during installation. Too loose and it shifts under injection pressure, and the parting line steps. We inspect 100% of inserts before shipment for exactly this reason.
