  Open Loop vs Closed Loop on the Same Machine Frame

A tape machine reads a punched or magnetic tape once, then runs open loop. The controller sends pulses, the table or feed screw moves, and nothing measures the result. Every error the mechanics introduce stays in the part. On a band saw cutting 4,000 mm stock, a 0.5 percent feed error becomes a 20 mm length error at the end of the cut.

Two error sources dominate. The first is the hydraulic or mechanical feed drive. Oil temperature changes viscosity, so the same valve opening delivers a different feed rate in the morning than after four hours of running. The second is the length reference itself: a mechanical stop or a limit switch has hysteresis, and its contact point moves as the switch wears.

Relay logic adds a third layer. Each relay coil has a pull-in and drop-out voltage that differ, so timing between two relays shifts with ambient temperature and contact oxidation. Operators compensate by tweaking settings, which makes the process depend on the person running the machine rather than the drawing.

The practical result is that tape machines hold a wide tolerance band and need frequent manual correction. They are not broken. They are limited by the absence of feedback, not by the iron.

The retrofit swaps the open loop for a closed loop. A servo motor or a servo-driven ball screw replaces the hydraulic feed cylinder. A rotary encoder on the motor shaft, or a linear scale on the axis, reports actual position back to the NC. The controller compares command and feedback several thousand times per second and corrects the difference.

This is the whole engineering idea. Everything else in the retrofit exists to make that loop mechanically clean. A ball screw with low backlash, a stiff coupling, and a properly preloaded thrust bearing let the servo move the axis without lost motion. If backlash is 0.1 mm, the controller can measure the error but cannot remove it.

The NC also takes over sequencing. Instead of relay chains, the controller handles clamp, feed, cut and retract as a program. That removes the timing variation between relays and lets one operator change a cut length by editing a number instead of moving a hard stop.

The tape reader itself is retired. Programs move to the controller memory or to a USB or network transfer. Part numbers, cut lists and nesting can then come from the same file that drives the saw.

The frame decides the outcome. A cast iron saw base or a heavy mill column that has been stress relieved and is still straight will hold a servo loop well. A welded frame with visible cracks, or one that has been shimmed at three corners, will fight the controller. Measure the geometry first: flatness of the mounting faces, squareness between axes, and wear on the guideways.

Guideway condition matters more than spindle condition on a saw. If the table slides on worn dovetails with 0.15 mm of play, the servo will chase that play and the cut length will still scatter. Regrinding or replacing the ways is usually the largest single line item, and it is the one buyers under-estimate.

Spindle or saw arbor bearings should be checked with a dial indicator and a push-pull test. A few thousandths of radial play is acceptable on a rough cut, but it will show up as wall thickness variation on a tube or a bar.

There is a size ceiling in practice. Machines with travel up to roughly 4,000 mm can be retrofitted with standard servo packages. Beyond that, the screw whip and the inertia of the moving mass start to demand a different drive architecture, and the cost approaches a new machine.

The ball screw sets the resolution. With a 5 mm lead screw and a 10,000 count per revolution encoder, one count is 0.5 μm of commanded travel. That does not mean the machine holds 0.5 μm. It means the controller can see and correct small errors before they accumulate.

Tuning is a balance between speed and stability. Too much proportional gain and the axis hums or overshoots at the end of a rapid move. Too little and it lags behind the command, leaving a following error that shows as a rounded corner or a short cut. Most retrofits settle on a proportional gain that allows a few hundredths of a millimeter of following error at full feed.

Backlash compensation helps but has limits. The controller can add a fixed offset when the axis reverses. It cannot fix backlash that varies with position, which is what happens on a worn screw or a loose nut. Replace the nut or the screw instead of relying on the compensation table.

Thermal growth is the remaining error. A 1,000 mm steel screw grows about 12 μm per degree Celsius. In a shop that swings 10 °C between morning and afternoon, that is 120 μm of drift if nothing compensates it. A linear scale on the axis removes most of this because it measures the part side, not the motor side.

The NC does not replace the safety circuit. Emergency stop, guard interlocks and the saw or spindle contactor should stay hard-wired and independent of the controller. A software stop is a process stop, not a personnel stop. Keep the safety relay chain physical and test it after the retrofit.

Keep the original manual jog and handwheel functions. Setup and troubleshooting are faster when the operator can move an axis without running a program. Most controllers allow a handwheel input and a teach position, which is also useful for recording a reference point after a fixture change.

The operator interface should show actual position, following error and the active program line. If the screen shows only the command value, the operator cannot tell a mechanical problem from a programming one. That single display choice saves hours of downtime later.

Back up parameters after commissioning. Screw pitch, encoder resolution, backlash table and soft limits are the values that define the machine. Losing them means re-measuring the whole setup.

Changeover is the first visible gain. A cut list with twelve different lengths becomes twelve program lines. The operator recalls the program instead of moving a stop and re-measuring a first article. Setup time drops from minutes to seconds per length.

Scrap usually drops because the loop catches drift before the part is finished. On a saw, that means the last piece in a bar is as long as the first. On a mill, it means a pocket depth does not creep over a run of parts.

Operator dependence falls. A new operator can hold tolerance because the machine measures, not because the operator has years of feel. Training moves from hand skill to reading a drawing and checking the first article.

The retrofit does not turn an old machine into a new one. It gives a sound frame a modern control. If you need ±0.005 mm on complex geometry with many setups, a purpose-built machining center is the right answer. If you need consistent length, repeatable depth and fast changeover on a machine that is still straight, the retrofit is usually the cheaper route.
