Custom Chinese Sheet Metal Fabrication Solution: How the Process Actually Works

• 1
  Why a Sheet Metal Fabrication Solution Starts With Process Order
• 2
  Blanking: Laser, Punch, or Waterjet
• 3
  Forming: Where Sheet Metal Tolerance Is Really Made
• 4
  Joining: Welding, Riveting, and Hardware Insertion
• 5
  Finishing and Inspection: What You Can and Cannot Fix Later
• 6
  Choosing the Right Route for Your Part

Sheet metal is not machined from a solid block. It is deformed, and every deformation changes what the next station can hold. A bracket that is blanked, bent, then welded will move at the weld. A bracket that is bent after welding will not. This is why the process route matters more than any single machine on the floor.

The usual sequence is blanking, forming, joining, finishing, inspection. Each stage adds stress. Laser cutting leaves a heat-affected zone of roughly 0.1–0.3 mm on the cut edge. Bending introduces springback that varies with material and grain direction. Welding pulls the part toward the heat. Finishing adds or removes a few micrometres.

A supplier who quotes one flat price without telling you the route is guessing. Ask which operations happen before the first bend. If welding comes before forming on a part with tight hole-to-bend dimensions, the bend will fight the weld distortion.

For parts held to ±0.1 mm across a bend line, plan the route so all welding is done before the final forming pass, or add a stress-relief step. For general enclosures at ±0.5 mm, the standard order is fine and cheaper.

Blanking decides edge quality, lead time, and how much secondary work you inherit. Fiber laser cutting is the default for prototypes and mid-volume runs. It cuts 1–6 mm mild steel cleanly, holds ±0.1 mm on hole position, and needs no tooling.

Turret punching wins when you have thousands of identical holes. A punch tool costs money up front, then runs at a fraction of the per-part laser time. For a 500 × 400 mm panel with 200 ventilation slots, punching is often the cheaper route once volume passes a few hundred pieces.

Waterjet cuts thick plate, 10 mm and up, with no heat-affected zone. It is slower and leaves a slightly tapered edge. Use it for thick aluminium brackets or when the material is heat-sensitive.

Watch the hole-to-thickness rule. A punched hole smaller than the material thickness tends to break the punch. On a 2 mm panel, keep hole diameters at 2 mm or larger unless you switch to laser.

Press brake bending is the step that most often fails inspection. Three variables control the result: die opening, bend radius, and material springback. A common starting point is a die opening of 6 to 8 times the material thickness.

Bend radius should be at least equal to the material thickness for mild steel. Going tighter risks cracking on the outside of the bend, especially on 5052 aluminium or 304 stainless. If the drawing calls for a sharp internal corner, expect a V-groove or a machined relief instead.

Springback is material-specific. 6061-T6 aluminium springs back more than mild steel. 304 stainless springs back more and work-hardens as it forms. A supplier with a modern press brake and angle measurement can compensate automatically. A manual shop will shim the die and hope.

Hole-to-bend distance is the other silent failure. Keep holes at least 2.5 times the material thickness away from the bend line, or the hole will deform into an oval.

Joining turns flat panels into a chassis. TIG welding gives clean cosmetic seams on stainless and aluminium but is slow. MIG is faster for steel frames. Spot welding suits thin galvanized panels where heat distortion must stay low.

For enclosures that will be powder coated, weld spatter and porosity show through the coating. Grinding the seam helps, but grinding also thins the material. On a 1.5 mm panel, a ground weld can leave 1.2 mm behind.

Riveting and clinching avoid heat entirely. Self-clinching nuts, standoffs, and studs pressed into the panel give you threaded attachment points without welding. They hold well in 1.5–3 mm sheet and are the usual choice for electronic enclosures.

Decide early whether hardware goes in before or after finishing. Pressed nuts installed before anodizing will be coated too, and the thread will need masking. Installing after finishing avoids masking but risks scratching the coating.

Surface finishing is where cosmetic expectations meet physics. Powder coating hides small scratches and gives a uniform 60–120 μm layer. Anodizing is thinner, roughly 5–25 μm, and shows every scratch and every weld line underneath.

Bead blasting before anodizing gives a matte, uniform look and hides minor tool marks. Brushing gives a directional grain that must run the same way on every panel of an assembly, or the parts will look mismatched under light.

Inspection is the last gate. A supplier should check raw material, monitor in-process dimensions, and inspect 100% of parts before shipment. Reports are available on request. For a first article, ask for a dimensional report on the bend angles and hole positions, not just a photo.

Tolerance in practice: laser-cut profiles hold ±0.1 mm, bend angles hold ±0.5°, and hole-to-hole across a formed part lands around ±0.2 mm. If your drawing asks for ±0.005 mm on a bent sheet part, the drawing is wrong. That number belongs to CNC machining, not forming.
