Dahlih CNC precision machining: how the process actually works
A plain explanation of Dahlih CNC precision machining for engineers and buyers: what the axes do, where tolerance comes from, which materials and finishes fit, and when a simpler machine is the better call. Read this before you send a drawing out for quote.

In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
What Dahlih CNC precision machining changes in the cut
Dahlih CNC precision machining is a subtractive process. A rotating tool removes metal from a solid block, and the machine positions that tool along controlled axes. The name matters less than the setup behind it: what fixture holds the part, how many setups the part needs, and whether the cutting forces stay balanced as the tool moves.
Most shops talk about the machine. The machine is only one variable. A 16 five-axis simultaneous machining center gives you reach and angle control, but a poorly planned fixture will still push a part out of tolerance. Precision comes from the whole chain: stock, workholding, toolpath, thermal behavior, and inspection.
In our plants, 127 high-precision CNC machines run across three wholly-owned facilities covering 7,600 m². Of those, 16 are simultaneous 5-axis machining centers and 16 are mill-turn centers. That mix matters. It lets us put a job on the machine that fits it instead of forcing every part onto the biggest spindle.
The engineering question is never "is CNC accurate?" It is "which setup holds this geometry at the tolerance the drawing actually needs?" That is where cost, lead time and repeatability are decided.
- 1Tolerance is a system resultMachine, fixture, tool, temperature and inspection all contribute.
- 2Fewer setups means tighter stacksEach re-clamping adds a positioning error you cannot remove later.
- 3Match the machine to the partA 3-axis job on a 5-axis center burns money without adding accuracy.
How many axes does the part really need?
Three axes move the tool in X, Y and Z. The part stays put. This is fast, rigid and easy to inspect. If your part has features reachable from one direction, or from two or three faces that can be reached by re-fixturing, a 3-axis machine is usually the cheapest correct answer.
A fourth axis adds rotation around one axis, typically A. The part turns while the tool cuts. This reaches features on the side of a shaft or a housing without re-clamping. It is the workhorse for cylindrical parts, cross-drilled holes and slot patterns wrapped around a diameter.
Five-axis simultaneous machining tilts and rotates the tool or the table while all axes move together. That lets a ball nose tool stay normal to a curved surface, so you cut complex contours in one setup. Undercuts, deep pockets with angled walls and blended freeform surfaces become reachable.
Five-axis is not automatically more accurate. It is more capable. The trade is programming time, longer cycle times on complex paths, and a bigger fixture investment. Use it when geometry demands it, not as a default.
- 13-axisPrismatic parts, plates, one-direction features. Lowest cost per part.
- 24-axisShafts, housings, wrapped features, cross holes. Fewer setups.
- 35-axisFreeform surfaces, undercuts, tight angle control in one setup.
- 4Mill-turnTurning plus milling on one platform. Good for round parts with off-axis holes.
Where the ±0.005 mm actually comes from
A tolerance callout is a limit, not a target. If the drawing says ±0.05 mm and the process holds ±0.02 mm, you paid for capability you did not need. Tightening a callout raises cost quickly because it forces slower feeds, more passes, temperature control and more inspection time.
We hold ±0.005 mm (±0.0002 in) on parts that require it. That number is reachable on the right machine with the right fixture, stable stock and a controlled shop floor. It is not reachable on every feature of every part. Deep bores, thin walls and long unsupported sections behave differently from a flat face.
A real tolerance stack includes the machine's positioning accuracy, the fixture's repeatability, tool wear, thermal drift and the measurement itself. If you measure with a caliper, the measurement uncertainty may be larger than the tolerance. That is why final inspection uses the right instrument for the feature, not one tool for everything.
Surface finish and tolerance travel together. A Ra 0.8–1.6 μm finish is a normal machined target for functional surfaces. For sealing faces, bearing bores and optical features we go to Ra 0.2–0.8 μm. As-machined surfaces sit around Ra 1.6–3.2 μm. Chasing a mirror finish on a non-functional face just adds cycle time.
- 1Do not over-specifyTolerance only on the features that function. Leave the rest loose.
- 2Watch the datumA clear datum scheme prevents argument at inspection.
- 3Thin walls moveUnder 1 mm wall sections need light passes and stress relief.
Material choice drives the cutting strategy
Aluminum cuts fast and holds tight tolerances well. Grades like 6061, 6061-T6, 6082 and 7075 are common for housings, brackets and prototype frames. 7075 is stronger but more prone to distortion after heavy material removal, so roughing and finishing may need to be separated.
Stainless steel is tougher on tooling. Grades 303, 304, 316 and 316L are routine. 17-4PH (SUS630) machines well in the annealed condition and gains strength after heat treatment, which means the sequence of machining and treatment has to be planned, not guessed.
Titanium and nickel alloys like TC4 (Ti-6Al-4V) and Inconel generate heat at the cutting edge and work-harden if the tool rubs. Low cutting speeds, high feed per tooth and rigid setups are the rule. These jobs also consume more tool life, so quoting them from a photo never works.
Plastics and composites behave differently again. POM and PEEK hold dimension well but expand with heat. Carbon fibre wears tools quickly and creates dust that needs extraction. In all cases the material decision sets feeds, speeds and the number of operations before any code is written.
- 1Aluminum6061, 2024, 5052, 5083, 6082, 7075, ADC12.
- 2Stainless303, 304, 316L, 420, 440C, 17-4PH.
- 3Steel1018, 1045, 4130, 4140, 4340, A36, tool steel.
- 4Titanium and specialTA1, TA2, TC4, Inconel, magnesium AZ31B / AZ91D.
Finishing changes dimensions, so plan it early
Anodizing, plating and coating add or remove material. Hardcoat anodizing builds a layer that can shift a press fit. Electroless nickel adds a uniform layer on complex geometry, which is why it is often chosen for wear surfaces and for parts with internal passages that cannot be masked easily.
Bead blasting and tumbling change surface texture and can round edges slightly. If a sharp edge is functional, say so on the drawing. Laser marking is used for part numbers and traceability, with a minimum character height of 1.5 mm to stay legible after coating.
The practical rule: decide the finish before machining starts. If masking is needed, the machinist has to leave material or add a feature. Discovering the finish requirement after the parts are cut usually means a second operation and a longer schedule.
For appearance parts, powder coating and black oxide cover different needs. Powder coating builds a thicker, more protective layer. Black oxide is thin and keeps dimensions close to nominal. Both change how the part looks and how it wears, so pick based on function first.
- 1AnodizingClear, colour, hardcoat, conductive.
- 2PlatingElectroless nickel, zinc, silver, gold.
- 3MechanicalBead blasting, tumbling, brushing, polishing.
- 4MarkingLaser engraving, minimum character height 1.5 mm.
Inspection is part of the process, not the last step
Every part that leaves our floor is inspected before shipment. That covers raw material check, in-process monitoring and final inspection. Inspection reports are available on request. The reason for in-process checks is simple: a feature that is going out of tolerance is cheaper to correct while the part is still on the machine.
We hold a 99.99% qualification rate across production runs. That number is a result, not a promise for a specific job. It comes from controlled processes, trained operators and measurement that matches the feature being checked.
For tight-tolerance work, the first article is the checkpoint. If the first part is right and the process is stable, the rest follow. If the first article is marginal, the whole run is at risk, and it is better to adjust the setup than to sort parts later.
Audit-ready documentation matters in regulated industries. We operate under ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. For medical and automotive buyers this means the paperwork trail exists before it is requested.
- 1Raw material checkGrade and condition verified before cutting.
- 2In-process monitoringCritical dimensions checked during the run.
- 3Final inspection100% before shipment, reports on request.
Choosing the setup for a part
Match geometry to the machine before you match it to a price.
| Part feature | Best setup | Why | Watch for |
|---|---|---|---|
| Flat plate, holes one side | 3-axis | Single setup, rigid, fast | Re-fixturing on the back side |
| Cross holes in a shaft | 4-axis | Indexing without re-clamp | Rotary table runout |
| Angled walls and undercuts | 5-axis | Tool stays normal to surface | Longer programming time |
| Round part with off-axis holes | Mill-turn | Turning and milling in one | Tool clearance inside bore |
| Freeform contoured surface | 5-axis | Continuous tool axis control | Ball nose step-over marks |
| Thin wall under 1 mm | 3-axis or 4-axis | Light passes, less heat | Distortion after roughing |
| Bore concentric to a diameter | Mill-turn | Same datum for turn and mill | Chuck jaw marks |
| Deep pocket, small radius | 3-axis with long reach tool | Stiffness over reach | Tool deflection at depth |
When five-axis is worth it, and when it is not
If the part has freeform surfaces, undercuts or angled features that would otherwise need three or more setups, use five-axis. If it is prismatic and reachable from one or two directions, stay on 3-axis or 4-axis and put the savings into material or inspection.
Questions engineers ask before quoting
What tolerance can you actually hold on a production run?
We hold ±0.005 mm (±0.0002 in) on parts that require it, on the right machine and fixture. Not every feature of every part can sit at that limit. Deep bores, thin walls and long unsupported sections need a realistic callout.
If your design only needs ±0.05 mm, we will machine to that and keep the cost down. Tightening a tolerance without a functional reason raises cycle time and inspection cost.
Is there a minimum order quantity?
No minimum order quantity. We run from a single prototype to 10,000+ part runs.
For prototypes, the setup and programming dominate the cost, so a second part from the same program is usually much cheaper than the first.
How fast can parts ship?
Quotation and free DFM analysis come back within 12 hours. Production can start within 24 hours after that, and parts typically ship in 3–5 days.
These times depend on material availability, finish requirements and the number of operations. Complex five-axis work with coating takes longer than a bare 3-axis run.
What is the maximum part size?
Up to 4,000 mm maximum processing size. Large travels include 4,000 × 400 × 150 mm. Medium travels are 750 × 1,150 × 550 mm and 600 × 600 × 600 mm. Compact machines cover 500 × 500 × 450 mm and 500 × 310 × 200 mm.
We also run a Ø400 mm rotary table for 4-axis work.
Can you work under an NDA?
Yes. Uploads are secure and confidential, and an NDA is available on request.
For regulated work, we operate under ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022.
Do you provide DFM feedback?
Yes. Free DFM analysis comes with the quote. We flag features that will drive cost or risk, such as deep pockets with small corner radii, tolerances tighter than the function needs, and sharp internal corners that need a smaller tool.
Catching these before cutting saves a revision cycle.
