Transformation of Planning Grinding on a CNC Surface Machine

• 1
  Key takeaways
• 2
  What the transformation of planning grinding actually changes
• 3
  Axis layout and control requirements
• 4
  Programming the transformed machine: convex plating plan
• 5
  Cutting parameters that hold the surface
• 6
  When the transformation of planning grinding is the wrong choice
• 7
  How GreatLight supports rebuilt and new mill-grind work
• 8
  Rebuilt mill-grind machine vs dedicated surface grinder vs CNC machining center

A planer-type machine already has a long, stiff bed and a gantry that carries a head across the work. The transformation of planning grinding keeps that frame and replaces the drive, the head and the control so the same machine can take a milling cut and then a grinding pass without unclamping the part. The value is not the spindle. It is the datum.

On a conventional planer you would mill a guide rail, measure it, then move it to a surface grinder for finishing. Each move adds a setup, and each setup adds a stack of error: fixture repeatability, clamping distortion, and thermal drift between the two machines. A rebuilt machine holds the part once and does both passes in the same coordinate system.

The retrofit is common on B2316-class molding and planer machines, where the original relay logic and single-axis feed are past their useful life. Typical scope: new X and Z servo axes, a CNC that supports interpolation and canned cycles, a grinding head with in-process dressing, and a re-ground bed. That is the minimum to call it a mill-grind machine rather than a planer with a new motor.

It is not a universal upgrade. The frame has to be straight enough to be worth controlling. We measure bed straightness, column squareness and slideway clearance first. If those are out of tolerance, the rebuild becomes a re-scrape job, and the cost changes by a large factor before any electrical work starts.

• 1
  Same datumMill and grind in one clamping position; no re-zeroing between operations.
• 2
  One operatorCombined cycles reduce handling and queue time between two machines.
• 3
  Long partsSuits rails, platens and die shoes up to 4,000 mm.

The usual layout drives X along the bed and Z into the work, with the grinding head on the same ram as the milling spindle or on a second saddle. A NUM1020-class control is enough for two-axis interpolation and wheel dressing cycles. If the head tilts, add a C axis; that alone decides whether you can grind a crown or a radius without a form wheel.

Servo sizing follows the table mass, not the part. A 4,000 mm bed with a heavy work table needs the X axis to accelerate that mass without following error, or the milled surface shows pitch marks that no grinding pass can hide. We size X for the table plus fixture, then check the Z thrust against the grinding force, which is lower than milling but far more sensitive to vibration.

Feedback matters more on the grinding side. Linear scales on X and Z keep the depth of cut honest after the machine warms up. Without them, a 0.01 mm thermal shift over a two-hour cycle turns into taper at the ends of a long rail. With them, the control compensates and the part stays inside ±0.005 mm.

Spindle speed range is the other split. Milling wants low speed and high torque; grinding wants 1,500–3,000 rpm at the wheel with a balanced arbor. If you run one spindle for both, you compromise the wheel speed, and the surface finish lands around Ra 1.6–3.2 μm instead of Ra 0.8–1.6 μm.

• 1
  X and Z servoSize for table mass and grinding thrust, not part weight.
• 2
  Linear scalesClose the loop on position so thermal growth does not become taper.
• 3
  Dressing cycleProgram wheel dressing at fixed intervals or part counts.
• 4
  Rigid foundationGrinding transmits vibration the original planer foundation may not damp.

Take a convex plating plan as the example. The part needs a crowned surface: high in the middle, falling to the edges by a few hundredths of a millimeter. On a manual planer this is a form-dressing job. On the transformed machine it is a programmed path.

Define the crown as an arc in the XZ plane, not as a series of straight steps. The control interpolates the arc while the wheel rotates, so the crown is generated by motion. Pick the arc radius from the required drop across the part width. For a 300 mm wide platen with a 0.03 mm crown, the radius works out to roughly 375 m. Feed the arc at 0.05–0.15 mm per pass in Z.

Run the milling pass first with a 0.2–0.3 mm stock allowance, then the grinding pass to final size. Keep the same work offset for both. If you re-zero between passes, you lose the whole point of the retrofit. Store the crown arc in a subprogram and call it for each pass, changing only the Z depth.

The common mistake is dressing the wheel to the crown shape and then running a straight path. That gives a crown that fades as the wheel wears, and the last parts in the batch are flat. Generate the shape by motion, and dress the wheel straight. Wheel wear then affects size, not form, and size is easier to correct.

• 1
  Arc, not stepsInterpolate the crown in XZ; do not approximate it with straight segments.
• 2
  Mill then grindLeave 0.2–0.3 mm and finish in the same clamping.
• 3
  Straight dressShape comes from the path, not the wheel profile.

Milling on a rebuilt planer is a roughing operation. Use a 50–80 mm face mill, 0.5–1.5 mm depth of cut, and 150–250 m/min surface speed in 1045 or 4140 steel. Higher speeds on a long bed invite chatter because the gantry is not as stiff as a machining center column.

Grinding is where the finish is made. Wheel speed 1,500–3,000 rpm, table feed 5–15 m/min, and depth of cut 0.005–0.02 mm per pass. Above 0.02 mm, burn marks appear on hardened steel and the wheel loads up. Coolant should flood the contact zone, not spray it, or the part grows and the last 200 mm of a long rail comes out undersize.

For aluminum and plastics, the same machine mills cleanly but grinding is rarely needed. A sharp carbide cutter at Ra 1.6–3.2 μm is enough for most fixtures. Grinding earns its place on hardened steel above 45 HRC, on stainless that work-hardens, and on any surface that needs Ra 0.8 μm or better with flatness under 0.01 mm.

Check the first part, not the tenth. Measure flatness and finish after the machine has run for 30 minutes, when the bed and head have reached thermal steady state. Cold measurements on a rebuilt machine are optimistic, and the error shows up later in the batch.

• 1
  Rough with the mill0.5–1.5 mm depth, 150–250 m/min in medium carbon steel.
• 2
  Finish with the wheel0.005–0.02 mm depth, 5–15 m/min table feed.
• 3
  Flood, do not sprayCoolant coverage controls size on long parts.

Small parts are the clearest no. A 100 mm die insert does not need a 4,000 mm bed, and the rebuilt machine's thermal mass makes it slower to settle than a compact surface grinder. For parts under 300 mm, a dedicated grinder with a fine-pitch table is cheaper to run and easier to hold to Ra 0.2–0.8 μm.

High-volume single-operation work is the second no. If you grind one face of one part, all day, the retrofit's flexibility is wasted. A production grinder with an automatic cycle beats it on cycle time and on wheel cost.

The third case is a frame that is already worn past recovery. Re-scraping a long bed and re-machining the column is real machine-building work. At that point, compare the rebuild against a used CNC surface grinder of similar size. Sometimes the honest answer is to buy the used machine and keep the planer for roughing only.

Between those limits, the retrofit pays back through setup time. Every part that would have taken two clampings now takes one. On a job shop floor with mixed long parts, that is the number to calculate before committing.

• 1
  Under 300 mmUse a dedicated surface grinder, not a rebuilt planer.
• 2
  One face, high volumeA production grinder wins on cycle time.
• 3
  Frame past recoveryCompare against a used CNC grinder before rebuilding.

Most customers do not rebuild their own planer. They have a long part that needs milling and grinding, and they need it held to tolerance. That is the job we quote. Our 127 CNC machines include 16 simultaneous 5-axis centers and mill-turn centers, with a maximum processing size of 4,000 mm and travels up to 4,000 × 400 × 150 mm on the large machines.

For long guide rails, platens and die shoes, we mill and finish in the same setup where the geometry allows, then inspect 100% before shipment. Tolerances hold at ±0.005 mm on critical features, with finishes from Ra 1.6–3.2 μm as-machined down to Ra 0.2–0.8 μm where the drawing calls for it.

Materials cover the usual range: 6061 and 7075 aluminum, 303 and 17-4PH stainless, 1045 and 4140 steel, plus Inconel and titanium where the part demands it. Anodizing, electroless nickel, black oxide and bead blasting are handled in-house or through qualified partners.

Quotation and a free DFM analysis come back within 12 hours. Production can start within 24 hours, and parts ship in 3–5 days. There is no minimum order quantity, from one prototype to 10,000+ part runs. Uploads stay confidential, and an NDA is available on request.

• 1
  4,000 mm capacityLong parts milled and ground without re-clamping.
• 2
  ±0.005 mmHeld on critical features, verified 100% before shipment.
• 3
  12-hour quoteDFM feedback with the quotation, production in 24 hours.
