A cutter moving through aluminum removes material by shearing. It generates heat, and the chip carries most of that heat away. Plastic does not cooperate. Thermal conductivity of POM, PEEK or ABS is a fraction of aluminum, so heat stays at the cutting edge. The chip is soft, often stringy, and carries little heat. The part absorbs the rest.

That single fact drives everything downstream: tool geometry, spindle speed, feed rate, coolant choice, workholding and the achievable surface finish. An engineer who copies a metal program onto polymer stock will get melted edges, a gummy finish, and dimensions that drift as the part cools.

The second difference is stiffness. Aluminum at 6061 temper has a modulus around 69 GPa. Unfilled POM sits near 3 GPa, unfilled PA near 2.5 GPa. A wall that is rigid enough in metal will deflect under the same cutting force in plastic, and the cutter will chatter instead of cut.

So plastic parts processing starts with a different question. Not how fast can we remove stock, but how little force can we apply while still cutting cleanly. Everything else follows from that.

Heat builds at the tip of the tool because the polymer cannot conduct it away. Once the local temperature passes the glass transition point, the material stops cutting and starts smearing. The cutter pushes a soft mass instead of slicing it. That is the moment you see a raised burr, a cloudy surface, or a dimension that measures oversize right off the machine and undersize an hour later.

The usual fix is to lower the heat input per tooth. Higher spindle speed with a lighter chip load keeps the tool in the cut for a shorter time and reduces rubbing. Sharp, polished flutes matter more here than in metal work. A two-flute upcut end mill with a high helix clears the stringy chip fast, while a three-flute design gives a better wall finish on rigid grades.

Climb milling is standard for plastic parts processing. Conventional milling drags the tooth across the surface before it bites, which rubs the material and raises the local temperature. Climb milling starts the cut at maximum chip thickness and pulls heat out with the chip.

Chip evacuation is not a minor detail. A plastic chip that stays in the pocket gets re-cut, and re-cutting is rubbing. Air blast is usually enough. Flood coolant helps on PEEK, PEI and other high-temperature grades, but it must be clean. Contaminated coolant leaves marks on transparent and light-colored parts.

Material choice decides whether a tolerance is realistic before the program is written. Semi-crystalline thermoplastics such as POM, PA and PEEK hold dimensions well because they have a sharp melting range and low creep under load. Amorphous grades such as PC, PMMA and ABS machine cleanly, take a good finish, but move more with temperature and moisture.

Moisture is the hidden variable. Nylon absorbs water from the air, and a dry-machined PA part can grow several tenths of a percent after a few days in a normal shop environment. If a nylon part must hold ±0.05 mm, the stock needs to be conditioned before the final pass, not after.

Fillers change the picture again. Glass-filled and carbon-filled grades raise stiffness and reduce thermal expansion, which helps tolerance. They also wear tools quickly. A coated carbide tool that lasts a full shift in unfilled POM may need replacing twice a shift in 30% glass-filled PA.

PTFE is the opposite case. It is soft, it creeps under clamping pressure, and it has a very high thermal expansion. A tight tolerance on a large PTFE part is a drawing problem, not a machining problem. We usually ask for a functional tolerance instead of a nominal one.

Plastic deflects under clamping force. A vise tightened to the same torque used on a steel block will bow a thin polymer wall and spring back after the cut. Soft jaws machined to the part profile spread the load. Vacuum fixturing is better still for thin plates because it applies uniform pressure across the whole face.

Machining releases internal stress that was locked into the extruded or molded stock. A pocket milled into a stressed plate can close up after the part is unclamped. Rough the part, leave 0.5–1.0 mm of stock, let it rest, then finish. On critical parts we do a stress-relief anneal between the two operations.

Second-operation setup is where most plastic scrap happens. A part that was dimensionally perfect in the first setup can deform when flipped and re-clamped. Where the geometry allows, five-axis machining keeps the part in one setup. That removes the re-clamping risk entirely and is one reason we run 16 simultaneous five-axis centers.

Deburring needs its own plan. A sharp scraper that works on aluminum will gouge a plastic edge. We use controlled chamfers in the program, then hand-finish with a fresh blade or fine abrasive. For optical parts, the edge is polished rather than cut.

CNC cutting is a subtractive route. It is economical from one piece up to a few thousand, and it needs no tooling. Above that range, injection molding wins on unit cost. The crossover depends on part size and geometry, but a simple housing usually favors molding somewhere in the low thousands.

Geometry sets the other hard limit. Deep narrow slots, internal channels and undercuts that a mold can form with a slide are difficult or impossible to cut with a rotating tool. If the design needs a hollow internal cavity with no line of sight, the process to question is CNC, not the design.

Surface finish is a third boundary. Machined plastic can reach Ra 0.8–1.6 μm as a standard finish and Ra 0.2–0.8 μm on polished faces. That is close to a molded surface and often good enough. What CNC cannot do is reproduce fine mold texture, molded-in logos below 1.5 mm character height, or the exact skin of a textured tool.

There is also a thermal boundary. Parts that will run continuously above the heat deflection temperature of the chosen grade will creep regardless of how well they were machined. In that case the material change matters more than the machining change.

GreatLight works to ±0.005 mm on metal parts where the geometry supports it. Plastic is a different conversation. The achievable tolerance depends on the grade, the wall thickness, the part size and how much of the dimension is measured across a free span. For most engineering plastics, ±0.02 mm on a stable grade is realistic. On PTFE or on a long thin nylon part, ±0.1 mm may be the honest number.

We would rather tell a customer that up front than ship a part that measures well on the bench and fails after a week in service. That is why the DFM review happens before the quote, not after.

Inspection is 100% before shipment. We check raw material certificates, monitor dimensions during the run, and do a final inspection against the drawing. Reports are available on request. For plastic parts, measurement temperature matters, so inspection is done in a controlled environment and the reading is recorded with the result.

If a drawing calls for a tolerance the material cannot hold, the useful move is to relax the dimension or change the grade. Both are cheaper than sorting scrap.
