Graphite arrives as a pressed and baked billet, usually a rectangular block or a round bar. It is not a metal. The structure is carbon grains bonded by a carbon binder, so the chip behaves like a brittle powder rather than a curled shaving. Material comes off in small particles that must be captured, not flushed.

Because the material is brittle, cutting forces stay low. A light depth of cut with a high feed works better than a heavy pass. We typically run 0.2–1.0 mm radial engagement and keep the axial depth under 5 mm on fine-grain grades. Push harder and the corner of the part fractures.

The absence of coolant changes everything downstream. No flood coolant means no fluid to carry chips away, so vacuum extraction at the tool is not optional. It also means thermal growth comes from the spindle and the part, not from a chilled fluid. Operators plan for that with a warm-up cycle and in-process probing.

Graphite CNC processing is not a finishing-only operation. Roughing and finishing usually happen on the same machine with the same dust system. That keeps the part from being handled twice and re-datumed, which is where most dimensional error creeps in.

Grade choice decides more about the outcome than machine choice. Fine-grain, high-density graphite takes a sharp edge and keeps it, so a 0.5 mm rib or a sharp electrode corner survives handling. Coarse grades are cheaper per block but the grain pulls out at the edge, leaving a rough wall and a rounded corner.

Density matters for surface finish too. A denser billet has less open porosity, so the machined face reads smooth and takes a coating evenly. Porous grades show pits after finishing and trap dust. If the part will sit in a vacuum chamber or touch optical surfaces, that porosity becomes a functional problem, not a cosmetic one.

There is a size ceiling worth checking early. Our largest travel is 4,000 × 400 × 150 mm, and graphite plates beyond that need to be split or sourced differently. Long thin plates also deflect during clamping, so a 4,000 mm part needs support along its length, not just at the ends.

One caution on additives. Some graphite grades are impregnated with resin or metal to seal porosity. Those grades cut differently, may need coolant, and behave more like a filled plastic than a pure carbon. Tell us the grade before quoting, not after the first cut.

• 1
  Fine grain, high densityBest for electrodes, thin ribs and optical surfaces.
• 2
  Medium grainWorkable for fixture plates and heat shields with looser finish.
• 3
  Coarse grainAvoid on sharp corners and sealing faces.
• 4
  Impregnated gradesConfirm the binder before machining; process changes.

Diamond-coated carbide is the standard tool for graphite. Two flutes, a high helix angle and a polished flute face move the powder out instead of packing it. Uncoated carbide works for a first article, then dulls. Tool life in graphite is measured in meters of cut, not hours, so we log it and change on schedule rather than on failure.

Dust control is the safety argument and the quality argument at once. Graphite powder is electrically conductive and can damage spindle bearings and linear guides. A sealed enclosure with vacuum extraction at the cut zone, plus a downstream filter, keeps the machine alive and keeps the operator out of the dust.

Clamping needs care. Graphite is brittle and does not like point loads. We use soft jaws or a vacuum chuck with a large contact area, and we keep the clamping force low. A part that slips during a finishing pass is scrap, and a part that is over-clamped cracks before the first cut.

Measurement happens on the machine wherever possible. Touching off with a probe after roughing tells us how much stock is left, so the finishing pass can be adjusted without unclamping. On electrodes we check the critical dimensions again at final inspection, with reports available on request.

Electrical discharge machining electrodes are the largest use. Graphite machines faster than copper, weighs less on the spindle, and wears less during the burn. A ribbed electrode with 0.8 mm walls is a normal job for a 3-axis mill, and a 5-axis cycle reaches geometry that would need two setups otherwise.

High-temperature fixtures and heat shields are the second group. Graphite keeps its shape where aluminium sags and steel oxidizes. Furnace sleds, brazing fixtures and induction heating components fall here. The design rule is simple: avoid sharp internal corners, because graphite cracks at a stress riser.

Consumer and industrial products use graphite where thermal conductivity and low friction matter. Heat sinks, bearing sleeves, seal rings and glass-contact tooling are common. In these parts the finish is functional, so we hold Ra 0.8–1.6 μm and, where needed, Ra 0.2–0.8 μm on a sealing face.

Sintering and powder metallurgy tooling is a fourth group. Graphite dies survive repeated thermal cycling and release the pressed part cleanly. These parts are usually simple in shape but tight on the bore, and the bore is where graphite's brittle edge becomes the deciding factor in the process plan.

• 1
  EDM electrodesThin ribs, deep pockets, multiple cavities.
• 2
  Furnace and heat-shield partsThermal cycling, no oxidation at temperature.
• 3
  Thermal management partsHeat sinks, sleeves, seal rings.
• 4
  Sintering diesRepeated cycles, tight bores, clean release.

Graphite fails under impact. If the part will be struck, dropped or used as a structural member, it will crack. There is no plastic deformation to absorb the energy. A design that needs a bolted joint carrying load should use aluminium or steel instead.

Thin sections are the second limit. A wall below roughly 0.5 mm becomes fragile in handling and in the machine. We can cut it, but the part may not survive shipping. Where a thin wall is unavoidable, we add a sacrificial web and note it on the drawing so the customer removes it in the assembly step.

Wear surfaces that see sliding contact at high load need a metal. Graphite wears against itself and against most metals, and the powder it produces contaminates the assembly. If the application needs a long sliding life, a bronze bushing or a coated steel shaft is the better answer.

Finally, cost per part falls only with volume. Setup, dust handling and tool changes dominate a one-off. A single graphite electrode is still economical because copper alternatives take longer to cut, but a low-volume structural part rarely is. That judgment is worth making before the drawing is frozen.
