How Do I Input Idea Into CNC Machine?

A sketch, a napkin drawing, or a CAD file has to become geometry, then toolpaths, then G-code before any spindle turns. This guide covers each conversion step, the tolerances that decide toolpath strategy, and the checks that stop a scrap part. Written for product engineers and buyers preparing a first prototype.
