Every CNC builder prints a connected load on the machine data plate. That figure is the sum of spindle motor, axis servos, coolant pump, hydraulic unit, chip conveyor and cabinet cooling, all assumed to run at once. It is a safety number, not a consumption number. If you size a breaker from it you will never nuisance-trip. If you size a utility budget from it you will overestimate by two or three times.

The gap between plate and practice is duty cycle. A 15 kW spindle rarely sees 15 kW for more than a few seconds. Roughing aluminum at high material removal rates gets close. Finishing passes at 0.2 mm radial depth draw a fraction of that. On a mixed job shop floor, the average over a shift typically lands between 30 and 60% of connected load.

So the first real question is what you are sizing. A breaker, a transformer, a generator or a monthly bill each need a different number. Write down which one you need before you touch a calculator.

• 1
  Connected loadData plate sum, used for breaker and feeder sizing.
• 2
  Average drawTypical running load over a shift, used for energy cost.
• 3
  Peak drawShort spikes during acceleration or heavy roughing.
• 4
  Standby drawIdle consumption between cycles and overnight.

The spindle motor is the single largest consumer on almost every machine. On a 40 taper vertical mill it might be 7.5 to 15 kW. On a large horizontal boring mill it can exceed 30 kW. Spindle draw scales with spindle speed, depth of cut and material hardness, so the same machine cutting 6061 aluminium and 17-4PH stainless will show very different demand profiles.

Axis servos come second. They draw hard during rapid moves and direction changes, then settle to a small holding current. A machine running many short moves with high acceleration will pull more from its servos than one running long straight cuts.

Ancillary loads are easy to forget but add up. Coolant pumps run continuously on many machines. Hydraulic power units for tool changers and clamps cycle on and off. Chip conveyors, mist collectors, cabinet air conditioners and work lights all sit on the same drop. On a small machine these can be 20 to 30% of total draw.

• 1
  SpindleOften 40 to 60% of running load on a mill.
• 2
  ServosPeaks during rapids; low steady-state holding.
• 3
  Coolant and hydraulicsPumps and power units run most of the shift.
• 4
  Support systemsConveyors, mist collection, cabinet cooling.

A compact 3-axis vertical mill for prototyping usually carries a 3.7 to 7.5 kW spindle and a connected load around 10 to 15 kVA. In a job shop running mixed small parts, its average draw often sits near 4 to 6 kW. That fits a 20 A three-phase circuit in most cases, though the plate may call for more.

A 5-axis machining center with a 40 taper spindle and a pallet changer typically shows a connected load of 20 to 35 kVA. Average draw during production runs lands around 8 to 15 kW. These machines usually need a dedicated 40 to 60 A three-phase feed and a clean ground.

Large mill-turn centers and gantry machines can exceed 50 kVA connected. Their duty cycles vary widely with part size, so metering is the only reliable way to plan. We run 16 simultaneous 5-axis centers and 16 mill-turn centers in our Dongguan plant, and each class sits in a different band on the panel schedule.

• 1
  Small 3-axis mill10 to 15 kVA connected, 4 to 6 kW average.
• 2
  5-axis machining center20 to 35 kVA connected, 8 to 15 kW average.
• 3
  Large mill-turn or gantryAbove 50 kVA connected; meter to confirm.

Once you know average draw per machine, adding machines is arithmetic with a diversity factor. Ten machines at 10 kW average each do not draw 100 kW at once. They start at different times, idle at different times and rarely rough at the same moment. A diversity factor of 0.6 to 0.8 is common for a mixed shop, but it depends on how synchronized your production schedule is.

Power factor matters for transformer sizing. Older machines with diode front ends can run a power factor around 0.7 to 0.85. Modern drives with active front ends push it above 0.95. If your utility bills reactive power, this is worth checking before you buy.

Voltage drop and harmonic distortion are the two problems that show up after installation. Long feeder runs to a distant machine bay can cause nuisance faults during spindle acceleration. Harmonic currents from many drives on one panel can overheat neutral conductors. Both are solvable, but only if you plan for them before the concrete is poured.

• 1
  Diversity factor0.6 to 0.8 for a mixed job shop.
• 2
  Power factor0.7 to 0.85 on older drives; above 0.95 on modern ones.
• 3
  Feeder sizingAllow for voltage drop over long runs.
