How to Choose the Reamer Feed and Speed in a Machining Center
Reaming is a sizing operation, not a roughing one. This guide gives you the stock allowance, feed per tooth, rpm and coolant rules we use on 3-axis and 5-axis machining centers, plus the mistakes that push a hole out of tolerance.

In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
Key takeaways
What Actually Controls Reamer Feed and Speed
A reamer is a multi-edge finishing tool. It follows an existing hole and shaves a thin layer off the wall. Because the radial depth of cut is tiny, the cutting edge spends most of its time rubbing rather than shearing. That is why reaming numbers look so different from drilling or milling numbers.
Two variables decide whether the hole comes out round, on size and smooth. The first is feed per tooth, which sets chip thickness. The second is surface speed, which sets edge temperature. Get the chip thin enough and the edge stays sharp. Push it too thin and the tool burnishes the wall instead of cutting it.
There is a third factor most operators ignore. Reamer feed and speed only work if the pre-drill is straight and leaves the right stock. A reamer cannot correct a bell-mouthed or tapered hole. It will follow the error and reproduce it with a better finish.
Our shop runs 127 high-precision CNC machines, including 16 simultaneous 5-axis centers and 27 three-axis machines. Reaming jobs on parts from Ø2 mm to Ø50 mm follow the same logic: control the stock, control the chip, control the coolant. Everything below builds on those three.
Stock Allowance: The Number You Set Before Any Cutting
The radial stock left for the reamer (called the reaming allowance) is the single largest source of scrap on reamed holes. Too much stock overloads the flutes, raises cutting pressure and tears the wall. Too little stock lets the reamer skate over the surface without cutting cleanly.
For rough reaming with a standard HSS or carbide reamer, leave 0.1–0.3 mm on diameter. For finishing reaming where you need H7, tighten that to 0.03–0.1 mm on diameter. Never go below 0.02 mm. Below that the edge rubs and the hole burns out fast.
The pre-drill matters as much as the number. Drill to roughly 0.2 mm under the finished size for a standard allowance, and hold the pre-drill concentric. A drill that wanders by 0.05 mm will hand the reamer a curved hole, and the reamer will keep that curve.
If the pre-drilled hole is larger than expected, do not simply run the reamer anyway. Check the drill diameter, check runout, and check whether the material spring-back is opening the hole. Cutting air with half the flutes is how holes come out oval.
- 1Rough reaming0.1–0.3 mm on diameter of stock left for the reamer.
- 2Finishing / H70.03–0.1 mm on diameter. Below 0.02 mm the edge rubs.
- 3Pre-drill targetAbout 0.2 mm under final size, held concentric within 0.02 mm TIR.
- 4Split when neededFor tight sizes, rough ream then finish ream to hold the tolerance.
How to Set Reamer Feed per Tooth and per Revolution
Feed is expressed two ways: feed per tooth and feed per revolution. Most shop manuals and CAM posts use feed per revolution (mm/rev), because that is what the machine code carries. A typical reamer has 4 to 8 teeth, so the two numbers move together.
A safe starting band for feed per revolution is 0.1–0.3 mm/rev in aluminium and mild steel, dropping to 0.05–0.15 mm/rev in stainless and titanium. Multiply by the tooth count to get the chip load per edge. If the chip load drops below about 0.02 mm per tooth, the reamer starts to rub instead of cut.
The most common mistake is running too slow on feed to chase a better finish. That backfires. A thin chip does not shear off cleanly; it smears along the wall, raises the surface roughness, and work-hardens stainless in particular. If the finish is poor, increase feed first, then check coolant.
Another mistake is running the reamer at the same feed as the drill that made the hole. A drill has two edges and needs a much heavier chip. Copying that number onto a 6-flute reamer gives a chip load that is far too small and a hole that will not clean up.
- 1Aluminium / mild steel0.1–0.3 mm/rev starting band.
- 2Stainless / titanium0.05–0.15 mm/rev, do not go under 0.02 mm per tooth.
- 3Never copy drill feedA multi-flute reamer needs a very different chip load.
- 4Poor finish first fixIncrease feed before you touch spindle speed.
Spindle Speed and Surface Speed for Reaming
Reamers run at low surface speed compared with end mills. In carbon and alloy steel, use 6–15 m/min. In aluminium and brass, 10–20 m/min. Stainless, titanium and Inconel sit at 4–8 m/min. These numbers keep the edge cool and stop built-up edge from forming on the margin.
Convert surface speed to rpm with the standard formula: rpm = (1000 × surface speed) / (π × reamer diameter). For a Ø10 mm reamer in mild steel at 10 m/min, that gives about 318 rpm. Round to a clean value the controller will accept, then verify the actual feed per tooth.
The margin of a reamer is the cylindrical land just behind the cutting edge. It rubs the hole wall by design, which is what gives the size and finish. If the surface speed is too high, the margin heats up, the hole grows, and the finish degrades. If it is too low, the reamer burnishes and the wall work-hardens.
When in doubt, start low and step up in small increments. Run one or two holes, measure the diameter, then raise rpm by 10–15 percent and run again. Stop increasing once the size starts to drift or the surface roughness turns patchy. That is the practical ceiling for that tool and material.
- 1Carbon / alloy steel6–15 m/min surface speed.
- 2Aluminium / brass10–20 m/min.
- 3Stainless / titanium / Inconel4–8 m/min.
- 4Formularpm = (1000 × surface speed) / (π × diameter).
When the Hole Comes Out Wrong
Oversize holes usually trace back to runout or too much stock. Check the holder TIR first, then confirm the allowance. If both are correct, the reamer may be cutting on the margin because the surface speed is too high. Reduce rpm and re-measure.
Undersize holes are less common and often come from spring-back in stainless or from a worn reamer. Measure the reamer diameter with a micrometer before blaming the program. A tool that has lost 0.01 mm will never hold a tight H7 fit.
Poor surface finish with an on-size hole points at feed that is too light, coolant that is not reaching the cutting edge, or a retract that is too fast. Increase feed slightly, confirm flood coverage, and make sure the pull-out uses the programmed feed rate.
Chatter shows up as a spiral pattern on the wall. It comes from a long reamer, a weak holder, or a spindle speed that matches a natural frequency of the setup. Shorten the gauge length, switch to a stiffer holder, and shift rpm by 10 percent to break the resonance.
- 1OversizeCheck runout, allowance and surface speed, in that order.
- 2UndersizeMeasure the reamer, then check spring-back in stainless.
- 3Rough wallFeed too light, coolant starved, or retract too fast.
- 4ChatterShorten overhang, stiffen the holder, shift rpm by 10 percent.
Step-by-Step Setup on the Machining Center
- 1Confirm the pre-drilled holeMeasure the actual bore diameter and roundness. It should be 0.2 mm under final size for a standard allowance, held within 0.02 mm TIR. If it is oval or tapered, fix the drill step before reaming.
- 2Load the reamer in a rigid holderUse a collet or hydraulic holder, not a drill chuck. Check runout at the cutting edge. Keep TIR under 0.02 mm. Any more and the reamer will cut on one side and open the hole.
- 3Set feed per revolution firstProgram 0.1–0.3 mm/rev for aluminium and mild steel, 0.05–0.15 mm/rev for stainless and titanium. Divide by the tooth count to confirm the chip load stays above 0.02 mm per tooth.
- 4Set spindle speed from surface speedUse rpm = (1000 × surface speed) / (π × diameter). Start at the low end of the band for the material, then step up by 10–15 percent while monitoring size.
- 5Turn coolant on before entryFlood coolant through the flutes, not just on the outside. Reaming generates long, thin chips that need flushing. Through-spindle coolant is ideal for horizontal holes.
- 6Feed in and out at the same rateNever rapid out of a reamed hole. Retract at the same programmed feed so the margin does not score the wall. A quick retract is the fastest way to ruin a good finish.
- 7Measure the first two holesCheck diameter, roundness and surface roughness. Adjust feed or speed by one variable at a time, then re-measure before running the full batch.
Reaming Parameters by Material
Starting values for a sharp carbide or HSS reamer with flood coolant. Tune from the first two holes.
| Material | Surface speed (m/min) | Feed per rev (mm/rev) | Stock on diameter (mm) |
|---|---|---|---|
| Aluminium 6061 / 7075 | 10–20 | 0.15–0.30 | 0.05–0.15 |
| Brass C36000 | 10–20 | 0.15–0.30 | 0.05–0.15 |
| Mild steel 1018 / 1045 | 6–15 | 0.10–0.25 | 0.05–0.15 |
| Alloy steel 4140 / 4340 | 6–12 | 0.10–0.20 | 0.05–0.12 |
| Stainless 304 / 316 | 4–8 | 0.05–0.15 | 0.03–0.10 |
| Titanium Ti-6Al-4V | 4–8 | 0.05–0.12 | 0.03–0.10 |
| Inconel | 3–6 | 0.04–0.10 | 0.03–0.08 |
Set the stock, then the feed, then the speed
Fix the reaming allowance at 0.03–0.1 mm for H7 work, set feed per revolution from the material table, and pick rpm from surface speed. Change one variable at a time and measure the first two holes.
Frequently Asked Questions
Can I ream on a 3-axis machining center, or do I need 5-axis?
A 3-axis machine handles reaming perfectly well as long as the hole axis is vertical and the part is held rigidly. The reamer only needs spindle rotation and Z feed.
Five-axis centers matter when the hole sits on an angled face or when you want to ream in one setup with other features. Eliminating a re-fixture removes the alignment error that would otherwise throw the bore off.
Should I peck ream or go straight through?
Go straight through in one pass. Reaming is a sizing operation and the margin works best when it stays in continuous contact. Pecking lets chips pack under the flutes and can chip the margin.
The only time to break the pass is when the hole is deep enough that chip evacuation fails. In that case, use through-spindle coolant rather than pecking.
How do I hold H7 on a reamed hole?
Control three things: stock allowance in the 0.03–0.1 mm range, holder runout under 0.02 mm TIR, and a sharp reamer whose diameter you have measured. Then run two test holes and adjust speed before the batch.
If the hole still drifts, split the operation into a rough ream and a finish ream. The second pass removes a very thin layer and lets the margin settle the size.
Does coolant type change the numbers?
Yes. Water-soluble flood coolant is the default and supports the speed bands above. For aluminium, a higher-concentration emulsion cuts built-up edge. For titanium and Inconel, high-pressure through-tool coolant lets you stay at the top of the speed band without burning the edge.
Dry reaming is possible in cast iron, but you lose chip flushing. Keep the feed at the low end and add air blast if the chips do not clear.
How long should a reamer last?
Life depends on material, speed and how well the pre-drill is controlled. In aluminium with good coolant, a carbide reamer can run thousands of holes. In stainless or titanium, expect far fewer before the diameter drifts out of tolerance.
Track the hole size, not the hole count. When the measured diameter moves past the middle of your tolerance band, change the tool.
What is the biggest mistake with reamer feed and speed?
Running the feed too light to chase a finish. It rubs the wall, work-hardens the material and makes the surface rougher, not smoother.
The second mistake is ignoring the pre-drill. A reamer copies the hole it finds. If that hole is tapered or off-axis, no feed or speed setting will fix the result.
