How to Draw a Personalized Tool Path for CNC Grinding

• 1
  What matters before you draw a single move
• 2
  Collect part and wheel data before you open CAM
• 3
  Pick the grinding strategy the geometry actually needs
• 4
  Set stepover, depth, and lead moves with numbers
• 5
  Check the personalized tool path for CNC grinding before cutting
• 6
  Step by step from drawing to first good part
• 7
  Starting parameters by grinding strategy
• 8
  Symptoms, causes, and fixes in grinding paths

Most bad grinding paths start with missing inputs. Before you open CAM, gather four things: the final part drawing with tolerances, the stock condition, the wheel specification, and the machine's axis limits. If the drawing calls for ±0.005 mm on a bore, that number drives the whole strategy. You cannot pick a stepover until you know what the part actually needs.

The wheel specification matters more than most people expect. Record diameter, width, abrasive type, grit size, bond, and maximum peripheral speed. A 400 mm aluminum oxide wheel running at 30 m/s behaves nothing like a 200 mm CBN wheel at 80 m/s. The CAM library often ships with generic wheels. Replace those entries with the real values from your dressing room.

Stock condition sets the number of passes. A near-net forging may need only 0.3 mm of stock removal. A welded repair may need 2 mm or more on one side. Measure the blank in three places. If the stock varies by more than 0.2 mm across the surface, plan a roughing pass that follows the measured shape, then a finishing pass that follows the drawing.

Finally, check the machine. Rotary table size, maximum spindle speed, and coolant delivery all limit what the path can do. On our 5-axis centers we work with a Ø400 mm rotary table and 4,000 mm maximum part length. If your part exceeds the work envelope, no tool path will save the setup.

• 1
  DrawingFinal tolerances, surface finish callouts, and datum scheme.
• 2
  WheelDiameter, width, grit, bond, and rated peripheral speed.
• 3
  StockMeasured allowance per surface, not the nominal value.
• 4
  MachineAxis travel, rotary table size, spindle and coolant limits.

Three strategies cover most work: contour grinding, creep feed grinding, and form grinding. Contour grinding follows the profile with a small stepover and suits complex outlines. Creep feed takes a deep cut at low feed and suits slots and deep profiles. Form grinding uses a dressed wheel to produce the shape in one pass and suits high-volume simple parts.

Choose creep feed when the depth of cut is more than 3 times the wheel width and the material is hard. It removes stock in fewer passes and holds the profile well. The trade-off is heat. Creep feed grinding concentrates energy in a small zone, so coolant pressure and nozzle aim decide whether you get a clean part or a burned one.

Choose contour grinding when the profile changes direction often. A small wheel tracks the curvature better than a wide one, and the lower contact area reduces force. You pay for it in cycle time. A path with 0.5 mm stepover on a 300 mm profile can take 4 times longer than a creep feed pass. Decide which one you can afford before you draw.

Form grinding is the fastest option and the least flexible. Once the wheel is dressed, the profile is locked. It works well for a family of parts with the same geometry and a volume that justifies the dressing time. For one-off prototypes, skip it.

• 1
  ContourComplex outlines, small stepover, longer cycle.
• 2
  Creep feedDeep slots and hard material, watch the heat.
• 3
  FormRepeated geometry at volume, dressing time up front.

Stepover is the single value that changes heat, force, and finish at the same time. For contour grinding, start at 10 to 20 percent of wheel width. A 20 mm wheel gives you 2 to 4 mm stepover. Going wider raises the arc of contact and the temperature in the zone. On hardened steel above 55 HRC, stay at the low end.

Depth of cut per pass depends on the strategy. For contour finishing, take 0.01 to 0.03 mm per pass. For creep feed, one pass can remove the full 3 to 6 mm depth. For roughing with a coarse wheel, 0.05 to 0.15 mm is common. These are starting points, not rules. Listen to the spindle load and check the sparks. A bright white spark cone that reaches past the coolant nozzle means you are removing too much.

Lead-in and lead-out moves decide whether the entry leaves a mark. Use a tangential arc lead-in with a radius of at least 2 mm. Avoid plunging straight into the surface. A vertical entry leaves a dwell mark that shows up after finishing. On a ground bore, that mark can put you outside the ±0.005 mm tolerance on the first pass.

Keep the path continuous where you can. Lift-and-reposition moves add air time and can leave witness marks at the re-entry point. Where a lift is unavoidable, place it in a non-functional area. On a shaft, that means off the bearing seat. On a mold insert, it means off the sealing surface.

• 1
  Stepover10 to 20 percent of wheel width for contour work.
• 2
  Contour depth0.01 to 0.03 mm per finishing pass.
• 3
  Creep feed depth3 to 6 mm in a single pass on hard steel.
• 4
  Lead-inTangential arc, radius 2 mm or larger.

Simulation catches geometry errors. It does not catch process errors. Run both. First, simulate in CAM with the real wheel profile, not the simplified cylinder. Then run an air cut on the machine with the blank offset 5 mm above the table. Watch the wheel approach every surface. Collisions between the wheel side and a shoulder are the most common failure we see.

Check the coolant aim while the wheel is in the cut position. The nozzle should point into the contact zone, not at the top of the wheel. On creep feed work, a pressure of 4 to 8 bar through a coherent jet works better than a wide flood. If the jet breaks before it reaches the zone, you will see burn on the trailing edge of the part.

Measure the first part in the machine if you can. A touch probe or an on-machine gauge lets you correct the offset before the wheel wears further. If the first part lands at the low end of the tolerance, adjust the offset and run the second part. Do not run the whole batch and hope.

Log the values that worked. Wheel diameter after dressing, stepover, depth, feed, and spindle load. The next time the same part comes back, you start from a known point instead of a guess.

• 1
  SimulateUse the true dressed wheel profile in the CAM model.
• 2
  Air cutOffset 5 mm above the blank and watch clearances.
• 3
  Coolant4 to 8 bar aimed into the contact zone.
• 4
  First partMeasure in machine, adjust offset, then continue.
