How to Edit Part Count in a CNC Machine

• 1
  Key takeaways
• 2
  What the part count actually controls
• 3
  What to check before you edit the value
• 4
  Why the counter stops at the wrong number
• 5
  Editing the count in CAM and process planning
• 6
  Symptoms, causes, and what to do
• 7
  How to edit part count in cnc machine controls, step by step
• 8
  Which count to edit, and when

On the machine side, the part count is a register inside the CNC controller. You set a target quantity, and the control compares it to the number of completed cycles. When the two match, the control stops the program, sounds an alarm, or lights a lamp. That is all it does. It is a counter, not a scheduler.

On the CAM side, the part count is a setup parameter. It tells the software how many identical workpieces come out of one bar, one plate, or one casting. Change it from 1 to 8 and the toolpath, the stock model, and the cycle time all change with it. This is where cost is decided.

The two numbers are linked but not equal. A machine may run one program cycle that produces four parts from a single tombstone fixture. The controller counts one cycle; the shop counts four parts. If you edit only the controller value, you will stop the machine at one quarter of the intended output.

So before you touch anything, decide what you are editing: a cycle counter for the operator, or a quantity in the process plan. Mixing them up is the most common cause of a short run.

• 1
  Controller registerCounts completed cycles, not finished pieces.
• 2
  CAM setup countCounts pieces per bar, plate, or casting.
• 3
  Fixture multiplierPieces per cycle. Keep it visible next to the counter.

Put the machine in MEM or MDI mode and stop the spindle. Most controls ignore counter edits during automatic operation, and a few will fault if you try. If the part is mid-cut, finish the cycle or use feed hold and spindle stop first. Never edit a counter while an axis is moving.

Confirm the offset page matches the current job. A counter edit on a machine still holding the previous setup's work offset will stop at the right number but produce the wrong parts. Check work offset, tool offsets, and the active program number on the screen.

Write down the old value. If the new count is wrong, you want a known number to return to. A setup sheet with three columns, old value, new value, and time, takes ten seconds and has saved many runs.

Decide what should happen at the target. On many controls you can choose between a simple stop, a stop with alarm, or a stop with M00. For lights-out or unattended cells, an alarm is safer because it is visible on the network. For manual loading, a plain stop is usually enough.

• 1
  Mode checkMEM or MDI, spindle stopped, no axis motion.
• 2
  Offset checkWork and tool offsets must match the current job.
• 3
  Record the old valueWrite it on the setup sheet before you change it.

The counter reads two cycles per part. This happens when the program ends with M30 and a subprogram also returns with M99 into the main body. The control counts both ends. Look at the end of the program and make sure only one cycle-end block increments the counter.

The counter resets on every M30. Many controls clear the part counter at M30 by default. If your batch keeps returning to zero, check the counter reset parameter or switch to a counter that M30 does not touch. This is a parameter setting, not a programming error.

The counter keeps running after the target. On some controls the target is a display only, and the stop comes from a separate M-code or macro. If the machine never stops, the target field is not linked to the stop output. Read the setting page again.

The count is right but the parts are short. A fixture holding four pieces per cycle needs a target of 250 cycles for 1,000 parts, not 1,000 cycles. Keep the pieces-per-cycle number on the setup sheet so nobody has to divide under pressure.

Power loss or an E-stop drops the counter. If the control does not keep the value in non-volatile memory, the count restarts at zero. For long runs, log the count at every shift change so a restart can be corrected by hand.

• 1
  Double incrementTwo cycle-end blocks in one program.
• 2
  Auto resetM30 clears the counter by parameter default.
• 3
  Target not linkedDisplay field is not wired to the stop output.

In CAM, the setup quantity changes the stock model. Set 8 parts from one 3,000 mm bar and the software lays out the nesting, the remnant, and the parting operations. Set 1 and you get a single-part program with a long remnant. The machining time per part usually drops as the count rises, because the remnant is shared.

For milled parts from plate, the count decides how many blanks you nest on one plate. A 500 × 500 × 450 mm work envelope can hold several small blanks at once. The trade-off is fixturing: more blanks per cycle means more clamping points and a longer setup, which only pays off above a certain quantity.

The break-even is not a fixed number. It depends on setup time, material cost, and how much of the bar or plate becomes scrap. A part with a 40-minute cycle and a 30-minute setup benefits from higher nesting. A part with a 3-minute cycle and a 2-hour setup often does not.

When the count changes, the program number, the fixture, and the inspection plan should change with it. An inspection plan written for one part per cycle will sample the wrong pieces when four come off the tombstone. Update the plan before the first production cycle, not after.

• 1
  Bar workHigher count shares the remnant, lowers time per part.
• 2
  Plate workMore blanks per cycle means more clamping points.
• 3
  Inspection planMust match pieces per cycle, not cycles.

Machine stops after one part when you asked for 250. The target field was not written, only displayed. Key the value again and press INPUT until the field shows the new number without a cursor.

Machine never stops. The target is set but the stop output is disabled in the setting page. Enable the stop or alarm output, or the run will continue until the bar runs out.

Count reaches the target but the batch is short. Pieces per cycle is greater than one. Multiply the target by the fixture multiplier, or the run stops at a fraction of the order.

Counter resets after every cycle. M30 is clearing the register. Change the reset parameter or use a counter that M30 does not clear, then verify with a dry run.

Two operators report different counts at handover. One is counting cycles, the other is counting pieces. Put both numbers on the setup sheet with clear labels so the shift change takes thirty seconds.

• 1
  Stops too earlyTarget not written or fixture multiplier ignored.
• 2
  Never stopsStop output disabled in the setting page.
• 3
  Resets each cycleM30 clearing the counter register.
