An instant CNC machining quote online is not a guess. The platform reads your CAD geometry, extracts features, and maps them to machine time, setup count, and material cost. Most engines work from a STEP or IGES file, sometimes SLDPRT. It rebuilds a lightweight solid, finds faces, holes, pockets, and bosses, then estimates how many tool changes and setups the part needs.

The engine then applies rules. A pocket deeper than four times its width needs a long-reach tool, which cuts slower and may need a second operation. A wall under 0.8 mm in aluminium is likely to deflect or chatter. A corner radius smaller than the tool that can reach it forces a smaller cutter and more passes. Each rule adds cost.

What it cannot do is judge intent. It does not know which face is cosmetic, which bore is a bearing seat, or whether a 0.5 mm chamfer is functional. That is why the number you see is a starting point, not a contract. For a part with one critical bore and the rest loose, you can often cut cost by relaxing the tolerances the engine cannot read anyway.

Treat the first quote as a baseline. Upload the same part twice with different tolerances or finishes and compare. That comparison teaches you more about your own design than any general advice about machining.

• 1
  Supported inputsSTEP and IGES are safest. STL loses feature data and usually triggers a manual review.
• 2
  What the engine readsFeature geometry, tool access, setup count, stock size, and material removal volume.
• 3
  What it missesCosmetic requirements, datums, inspection needs, and assembly fit.

Most bad quotes start with a bad file. Export a single solid, not an assembly with hidden hardware. Delete construction surfaces, sketches, and reference geometry. If your model has threaded holes, decide whether the thread is modeled or called out in notes. Modeled threads slow the engine and rarely change the price.

Set the units correctly. A part modeled in inches but uploaded as millimeters comes back 25.4 times too large, and the price reflects that. Check the bounding box before upload. If your part is 120 mm long and the quote shows a 3,000 mm stock size, the units are wrong.

Name the file with the part number and revision. This matters less for the algorithm and more for you when five quotes sit in your inbox. Add a short note for anything the geometry cannot show: mating surfaces, press fits, or a face that will be visible after assembly.

Do not remodel the part to chase a lower number before you know where the cost is. Quote the real design first, then iterate. You need a baseline to compare against.

• 1
  Export as a single solidRemove fasteners and assembly-level components unless they are machined too.
• 2
  Verify the bounding boxCompare it to your drawing before trusting the quote.
• 3
  State the tolerance in notesSTEP carries geometry, not tolerance. Default general tolerance is not enough for fits.
• 4
  Keep one revision per fileOverwriting a file mid-quote makes the returned price meaningless.

Every serious quoting engine returns manufacturability notes. Read them before you read the price. A warning about a 0.5 mm wall is not a rejection. It is the engine telling you the part needs a different setup or a slower feed, and the cost reflects that.

The three warnings that move price most are deep pockets, small internal radii, and thin floors. A pocket 50 mm deep and 10 mm wide needs a long tool with a small diameter. It will chatter unless you reduce the depth of cut, so cycle time rises. Change the design to 30 mm deep and the same pocket can be cut with a stiffer tool in fewer passes.

Internal corner radii are the second lever. If your part is 6061 aluminium and you specify a 1 mm corner where a 3 mm radius would work, you force a small cutter and a slower program. On stainless 316L the same choice can double the cycle time. Design the largest radius the function allows.

Thin floors deflect during roughing and finishing. If a floor is under 1.5 mm in aluminium, expect the shop to leave extra stock and take a light finishing pass. That is a real cost, and it is cheaper to thicken the floor by 0.5 mm than to pay for the extra operation.

• 1
  Deep pocketDepth-to-width above 4:1 needs long-reach tooling and slower feeds.
• 2
  Tight internal radiusA radius under 2 mm limits tool diameter and raises cycle time.
• 3
  Thin wall or floorBelow 0.8 mm in aluminium, expect chatter control measures.
• 4
  Undercut or 5-axis featureConfirm the shop has simultaneous 5-axis capacity before trusting the number.

Material cost is easy to see and often overestimated. Machining time is where the money hides. Aluminium 6061 cuts fast and is cheap. Stainless 316L cuts at roughly half the speed and work-hardens if the feed is wrong. Titanium Ti-6Al-4V is slower again and consumes tooling. Inconel is a different category; quote it only when the service temperature demands it.

Tolerance is the second lever. A part held to ±0.005 mm needs a finishing pass, temperature control, and sometimes a separate inspection step. A part held to ±0.05 mm on non-critical faces does not. Mark tolerances only where they matter. A drawing covered in tight callouts will get a high quote even if only two features are actually functional.

Surface finish follows the same logic. As-machined at Ra 1.6–3.2 μm needs nothing extra. Ra 0.8–1.6 μm needs a finishing pass. Ra 0.2–0.8 μm on a large face can add a polishing operation. If the finish is cosmetic, consider bead blasting or anodizing instead of a finer cut; both are usually cheaper.

Quantity changes the shape of the cost curve. Setup is amortized across parts. One prototype carries the full setup. A run of 500 spreads it thin. If you plan to scale, quote both quantities now so you can see the setup cost explicitly.

• 1
  Aluminium 6061Fast to cut, low tool wear. The default for prototypes and enclosures.
• 2
  Stainless 316LRoughly half the cutting speed of aluminium; watch work hardening.
• 3
  Titanium Ti-6Al-4VSlow, tool-hungry, but needed for strength-to-weight and corrosion.
• 4
  Tight tolerance on one featureCheaper than tight tolerance on every feature on the drawing.
