Start at the machine, not at the screen. A 3-axis mill has three linear axes: X left and right, Y front and back, Z up and down. A 4-axis machine adds a rotary table, usually Ø400 mm on the machines we run. A 5-axis center tilts and rotates the part or the spindle, which lets a single setup reach five faces.

Stand at the control and name each part out loud: spindle, tool holder, vise, fixture, table, way covers. Watch a tool change and a tool offset call. Most beginner crashes come from a wrong offset or a wrong work zero, not from a bad toolpath.

Learn the coordinate systems next. Machine coordinates are fixed to the machine. Work coordinates sit on the part, set with an edge finder or a probe. Tool length offsets tell the control how long each tool is. Get these three straight and half of your future crashes disappear.

• 1
  AxesX, Y, Z linear; A, B, C rotary. Know which way is positive before you jog.
• 2
  Zero pointsWork zero on a corner or a center, then touch off every tool.
• 3
  SafetyHand on feed hold, single block on, rapid override down for the first run.

Write a few short programs by hand. A facing pass, a square pocket, a drilled hole. Ten lines of G-code teach more than ten hours of watching a CAM preview. Learn G00 rapid, G01 feed, G02 and G03 arcs, G81 drill cycle, and M03 spindle on.

Hand coding shows you why a CAM toolpath looks the way it does. When the software posts a long list of small arcs, you will know it is approximating a curve, not cutting 400 straight segments because it hates you.

Then move to CAM. Fusion 360 is cheap to start, Mastercam and NX CAM are common in job shops. Pick one and stay on it for six months. Switching packages early resets your learning curve every time. Post a simple 2.5D part first, then a 3D contour.

• 1
  Hand codeWrite and run a facing pass, a pocket and a drill cycle before touching CAM.
• 2
  CAM choiceOne package for six months. Fusion 360 to start, Mastercam or NX CAM in a shop.
• 3
  Post checkRead the posted code once per part. Wrong feed or missing coolant shows up here.

Three numbers control almost everything: surface speed, chip load and depth of cut. Surface speed is how fast the tool edge moves past the material, in m/min or surface feet per minute. Chip load is the thickness of material each tooth removes per revolution, in mm per tooth or inch per tooth.

For 6061 aluminum with a carbide end mill, surface speed runs around 300–500 m/min. For 304 stainless, drop to 60–120 m/min. For mild steel, 90–150 m/min. Feed rate equals spindle speed times number of teeth times chip load. If the tool has 3 flutes and you want 0.05 mm per tooth at 8,000 rpm, feed is 1,200 mm/min.

Depth of cut decides how much load the tool and the machine can take. Light passes at high feed often beat deep passes at low feed for tool life. If you hear chatter, reduce radial engagement first, then adjust feed. Do not just slow the spindle down.

• 1
  Aluminum 6061Surface speed 300–500 m/min, 3-flute carbide, air blast or mist.
• 2
  Stainless 304Surface speed 60–120 m/min, steady feed, no dwelling in the cut.
• 3
  Mild steel 1018Surface speed 90–150 m/min, coolant on, watch for work hardening.

A vise is the fastest way to hold a rectangular block. For thin plates, a vise will bow the part and the finished face will spring back when you release it. Use soft jaws machined to the part profile, or clamp the plate down to a fixture plate with low-profile clamps.

For the second operation, flip the part and set a new zero. If the part has a machined face, use a height setter or a probe on that face. Write the offset down. Reusing a stale offset from the first setup is a common way to cut into the vise.

Thin walls, deep pockets and long tools all move under cutting force. A 6 mm end mill sticking 60 mm out of the holder will deflect. Either shorten the stick-out, use a larger tool, or take lighter passes. The machine will not tell you the tool is bending, but the wall thickness will.

• 1
  Thin platesSoft jaws or fixture plate. Vise jaws alone will bow the part.
• 2
  Second opSet a fresh zero on a machined face, then verify with a dial indicator.
• 3
  Long toolsShorten stick-out or reduce radial depth. Deflection shows up in the wall.

Run the first part in air. Watch the position display and confirm every move in your head. Then run it in wax or a soft plastic block. If the part has a tight feature, this is where you find out that the tool holder hits the vise before the tool reaches the pocket.

Keep a log for each job. Material, tool, surface speed, chip load, depth of cut, spindle speed, feed, coolant, result. After twenty parts, the log tells you what works in your shop better than any online calculator. It also tells you what broke and why.

The habits that keep you safe are simple. One hand near feed hold. Single block on for the first part. Rapid override at 25%. Never reach into the machine while the spindle is turning. Check the tool offset after every tool change, every time.

• 1
  Air runFull program, no material, watch the display and the clearance.
• 2
  Wax or plasticSecond run in soft stock to catch holder and fixture hits.
• 3
  Job logRecord every number. After twenty parts it is your own cutting data book.
