A wire EDM cut is a series of sparks between a moving electrode and the workpiece. The wire is the electrode. It never touches the part; the gap is filled with deionized water and the discharge removes metal a few microns at a time. Because the wire is consumed, every meter you buy ends up as swarf. That changes how you should think about it. You are not choosing a durable tool, you are choosing a cut rate, an accuracy class, and a scrap cost.

The electrode has to do three jobs at once. It must carry current without heating up too much, it must flush debris out of a narrow gap, and it must survive the tension the machine pulls it to. Brass does all three reasonably well, which is why most shops run it. Zinc-coated and diffusion-annealed wires trade a little cut speed for better flushing and longer life at high current.

Wire diameter drives almost every other decision. A Ø0.25 mm wire cuts faster and flushes better, but the smallest inside corner it can reach is roughly wire diameter plus the spark gap. A Ø0.10 mm wire reaches finer detail, yet it snaps more easily and cannot push the same current. On a part with a 0.4 mm inside radius, the choice is already made for you.

Most entry-level mistakes happen here, not at the machine. If the wire grade and diameter do not match the feature size and the part height, no amount of offset tuning will save the job. Sort the wire first, then tune the process.

• 1
  Hard brassThe default. Cheap, predictable, fine for general tooling and one-off parts.
• 2
  Zinc-coatedBetter flush at high current, slower on thin sections.
• 3
  Diffusion-annealedHigh tensile, good for tall parts and automatic re-threading.
• 4
  MolybdenumFor very fine diameters, usually Ø0.02–0.05 mm.

Threading is the step most operators fight with. The machine cuts the wire square, feeds it through the upper guide, pushes it across the gap, and the lower nozzle catches it. If the wire end is bent, burred, or not cut square, it will not pass. Most machines cut the end with a small torch or a mechanical cutter; check that cut every time you re-thread, not just when it fails.

Water pressure at the flushing nozzle is the second variable. Too low and the wire stalls halfway across the gap. Too high and it whips and misses the lower guide. On most machines the sweet spot sits in the middle of the recommended range, and it changes with part height. A 50 mm tall part needs less pressure than a 200 mm stack.

Tension matters more than most people expect. If tension is too low, the wire bows in the cut and the wall comes out tapered. If it is too high, the wire breaks at the guide or at a corner. Set tension at the lower end of the machine's range for thin wire and the upper end for Ø0.25 mm and above.

Keep the guides clean. Brass and zinc build up on the carbide inserts over a shift, and a worn guide changes the wire position by a few microns. That is enough to lose a ±0.005 mm tolerance on a close-tolerance feature. Check guide wear on the maintenance schedule, not when a part comes out oversize.

• 1
  Cut the end squareAny burr or bend will fail the thread. Recut before every re-thread attempt.
• 2
  Anneal the endSome machines need a soft tip to pass the guide. Use the built-in annealer if fitted.
• 3
  Watch the flushIf the wire stalls mid-gap, raise pressure in small steps, not at once.
• 4
  Log every breakPosition, hour, and wire spool. Patterns show up after three or four events.

The offset is the distance the wire center travels from the programmed path. It equals the wire radius plus the spark gap, adjusted for each pass. On a rough cut the spark gap is wide and the offset is large. On a skim pass the gap is small and the offset shrinks. If the machine's built-in technology table is accurate for your material, use it as the starting point and adjust from there.

Material and height both move the offset. Cutting 50 mm of D2 tool steel is not the same as cutting 10 mm of 6061 aluminium. Aluminium cuts fast and the gap behaves differently; steel at height needs more flush and a slightly larger offset to keep the wall straight. Do not copy an offset from one material to another and expect the same size.

Skim passes are where tolerance and finish come from. A rough cut might leave the wall at Ra 3.2 μm and 0.03 mm oversize. Two or three skim passes bring it to Ra 0.8–1.6 μm and on size, with the last pass removing only a few microns. Each pass has its own offset and its own power setting. Mix them up and the part either goes undersize or the finish never improves.

Measure the first part before you run the batch. Cut one test feature, measure it on the CMM or with a micrometer, and correct the offset by the difference. One correction is normal. If you need three, the wire or the flush is the real problem.

• 1
  Rough cutLarge offset, high current, wall left oversize for skims.
• 2
  First skimSmall offset, medium power, removes most of the damage layer.
• 3
  Second skimVery small offset, low power, sets final size.
• 4
  Trim passOptional. For Ra 0.2–0.8 μm on medical and aerospace work.

Broken wire at a corner is almost always a tension or flush problem. The wire stops moving forward while the machine keeps discharging, and the local heat breaks it. Lower the tension slightly, raise the flush pressure a step, and slow the feed override through that corner. If it breaks in the same place twice, the guide is worn or the wire has a weak spot from that spool.

Tapered walls on a straight cut point to tension that is too low or a guide that is out of position. Check the wire alignment first, then the tension. If both are correct, the flush is pushing the wire off line. Reduce pressure and see whether the taper shrinks. A part that tapers only on one side usually has a worn lower guide.

Oversize or undersize parts that are consistent across the batch mean the offset is wrong, not the machine. Correct the offset and re-cut. If the size drifts during a long run, the wire diameter is changing as the spool unwinds or the guides are heating up. Check the spool and let the machine settle.

Poor finish after skims is usually a power setting problem. If the last pass runs too hot, it puts the damage layer back on the wall. Drop the power, shorten the on-time, and keep the offset small. Finish comes from the last pass, so nothing else on the machine can compensate for the wrong setting there.

• 1
  Break at the same spotWorn guide or a bad section of spool. Swap the spool and check the guide.
• 2
  Taper on one sideLower guide wear. Replace and re-align.
• 3
  Size drifts over hoursThermal growth in the guides or a changing wire diameter.
• 4
  Rough wall after skimsLast pass power too high. Slow it down and cut the on-time.
