Hot stamping is embossing with a heated tool. A master carrying the channel pattern is pressed into a thermoplastic substrate while both are held above the material's glass transition temperature. The polymer softens, flows into the cavities of the master, and takes the inverse shape. The tool stays in contact while the stack cools below Tg, so the channels freeze in place before the master is released.

The JK-XHP1500 controls three things at once: platen temperature, closing force, and the dwell time at temperature. Temperature decides how far the polymer can flow. Force decides whether the deepest channels fill without flashing at the edges. Dwell time decides whether the replication is complete or only partial at the channel floor.

Cycle time runs in minutes, not seconds like injection molding. That is the trade. You give up throughput and gain a simpler tool path, lower tooling cost, and the ability to change channel depth by changing pressure rather than cutting a new mold.

Vents matter as much as channels. Air trapped in a closed cavity will leave a short shot at the end of a long channel run. The JK-XHP1500 uses vacuum-assisted clamping to pull the residual gas out before the tool closes, which is what allows high-aspect-ratio features to fill at the far end of a 60 mm channel.

On PMMA and COC, 20 μm channel width is the practical floor for production work. Below that, the polymer needs more heat and more time, and the demolding step starts to tear sidewalls. Depth is the easier direction: 100 μm depth on a 50 μm width is routine, and 5:1 aspect ratios hold their shape when the tool is polished to Ra 0.2–0.8 μm.

Corner radius is where most new designs fail. A sharp internal corner on the master becomes a stress riser during demolding, and you get a rounded channel corner in the part plus a torn tool edge over time. We specify a minimum 5 μm radius on all internal corners of the master. It costs nothing at the CNC stage and saves the tool.

Draft is not required the way it is in injection molding, because the substrate is compliant at release temperature. What is required is a smooth sidewall. A master machined to Ra 1.6–3.2 μm releases, but it drags. A master polished to Ra 0.2–0.8 μm releases cleanly and passes the pattern on to every part in the run.

Feature density has a limit too. A 75 × 25 mm chip area with more than about 40% channel coverage starts to behave like a solid block under load, and the polymer has nowhere to displace. We add a small perimeter reservoir in those layouts. It gives the excess material a place to go instead of building flash.

The master is the part that carries your channel geometry, and it is usually machined. For channels of 100 μm and above, a direct CNC-machined master in brass or hardened tool steel is the fastest route. Our 5-axis centers hold ±0.005 mm, which is fine for these features, and the master is ready in days rather than weeks.

Below 100 μm, machining the master directly gets difficult because tool deflection and chip evacuation dominate. Silicon masters made by photolithography give better sidewall quality at that scale, and they can be replicated into a nickel shim by electroforming. The shim is then used in the press. This adds a step and a vendor, but it holds 10 μm features.

Master material affects tool life. Brass masters are cheap and fast, but they wear at the edges after a few thousand cycles on glass-filled or high-temperature polymers. Hardened steel or nickel shims cost more up front and hold channel depth over much longer runs.

A worn master does not fail suddenly. Channel depth drops gradually, bond quality drifts, and the first sign is usually a change in fill time during a capillary test. Track depth on a witness sample every few hundred cycles rather than waiting for a customer complaint.

PMMA is the default for prototyping and for chips that need optical clarity, because its Tg of about 105 °C sits in a comfortable range and it releases well. COC and COP cost more but bring lower water absorption and better solvent compatibility, which matters for reagent storage and for chips that see organic solvents.

PC has a higher Tg near 147 °C. It gives better heat resistance and impact strength, but the wider gap between softening and degradation means the process window is narrower. Temperature control has to be tighter, and the cycle is longer because the stack has to cool further before release.

PS and PP appear in disposable and high-volume applications. Both replicate well, and both are cheap. PS is brittle after molding if the wall is thin; PP is chemically resistant but has poor optical clarity, so it suits detection methods that do not need a transparent readout.

Filler content changes everything. Glass-filled or heavily pigmented grades raise melt viscosity, need more force, and wear the master faster. If the chip has to be opaque, use a pigment that disperses cleanly, and expect to shorten the master service interval.

Judge replication on the channel floor and the sidewall, not on the top surface. A chip can look perfect from above and still have a rounded floor that changes the cross-section and therefore the flow resistance. Cross-section a witness part and measure depth at three points along the channel.

Depth variation across a 75 mm chip should stay within a few percent for a well-controlled cycle. If the inlet end is deeper than the outlet end, the platen is not parallel or the pressure is uneven. If the center is deeper than the edges, the master is deflecting under load, and a thicker backing plate or lower force is the fix.

Surface finish inside the channel drives capillary behavior. For chips that rely on capillary flow, Ra 0.8–1.6 μm is usually enough. For optical detection through the channel wall, you want the molded face smoother, and that comes from polishing the master rather than changing the press settings.

We inspect 100% of parts before shipment, and we run raw material checks, in-process monitoring, and a final dimensional inspection. Reports are available on request, and the inspection plan is agreed before the run starts rather than after.
