Tolerance is the first number engineers ask about, and the first number that gets misread. A shop quoting ±0.005 mm is describing its best case on a rigid setup with probing, not a blanket guarantee on every feature of every drawing. That number applies to a defined dimension on a stable material. Thin walls, long unsupported sections and deep bores all move once the tool pressure comes off.

The practical approach is to tolerance only what the assembly needs. Put ±0.005 mm on a bearing bore or a mating spigot, and leave general dimensions at ±0.1 mm. This is not a compromise. It tells the machinist where to spend time. If everything on the drawing carries a tight call, the shop has to slow every pass, add semi-finish cuts and inspect more often. Piece price climbs, and lead time moves out.

Material changes the answer too. Aluminum 6061 and 7075 hold tight limits well because they cut cleanly and move little. Stainless 316L and 17-4PH work-harden, so a light finishing pass is needed to hit a tight bore without pushing the tool. Titanium TC4 (Ti-6Al-4V) needs lower cutting speeds and more coolant. Inconel is the slowest of the group and will not hold ±0.005 mm on a thin section without stress relief.

Ask what inspection method backs the claim. Calipers and micrometers are fine for ±0.05 mm. For ±0.005 mm you want a CMM report on the critical features, and a shop that will send it with the parts. If a supplier cannot describe the gauge or the report, the tolerance is a sales number, not a process.

• 1
  Tight where it matters±0.005 mm on fits, ±0.1 mm on everything else.
• 2
  Watch thin wallsBelow 1 mm wall thickness, expect deflection and extra passes.
• 3
  Match material to the limitAluminum is easy, stainless needs care, titanium and Inconel need time.

Quotation speed is a proxy for how the shop runs its front office. A local CNC machining service that returns a quote and a DFM analysis inside 12 hours is reading your file, not just counting parts. The DFM note is the useful part. It should flag features that will not cut as drawn, thin floors, sharp internal corners, or a tolerance that needs a different setup.

Production start is a separate promise from quote speed. A shop that can start within 24 hours of PO has open spindle time and material on the shelf. That is a capacity statement. It also means your job may sit in a queue behind another rush order if the schedule tightens. Ask which machine your part is planned on, and whether that machine is currently loaded.

For most machined parts, shipment in 3–5 days covers the run. The number that matters more is the tail risk. Ask a supplier what share of past orders shipped late. A shop tracking below 2% late delivery is measuring its own schedule, which usually means it will tell you early if something slips. Shops that do not track it cannot warn you.

Do not confuse shipping speed with process speed. A two-day air shipment does not fix a week of queue time. If the date is critical, book the machine slot, not the courier.

• 1
  Quote in 12 hoursExpect a DFM note, not just a price.
• 2
  Start within 24 hoursConfirms material and spindle time are available.
• 3
  Ask about late rateUnder 2% means the shop tracks its schedule.

A no-minimum-order shop is built for prototypes. It will quote one piece, because its fixturing and programming workflow is set up to absorb a single setup. That does not make the one-off cheap. Setup, programming and first-article inspection are spread over one part instead of a thousand, so the piece price is high by design. That is normal and not a sign of a bad quote.

Past a few dozen pieces, the setup cost fades and the price tracks cycle time and material. This is the point where you should ask for a price break table: 1, 10, 100, 1,000, 10,000+. A shop that gives you a curve is telling you where its process changes, for example when it moves from a vise to a soft jaw or from a 3-axis to a 5-axis setup.

Runs of 10,000+ parts sit at the edge of what machining makes sense for. At that volume, die casting or injection molding usually wins on unit cost, and the machining question becomes which features still need to be cut after the casting. A supplier that also runs casting and finishing can quote the whole path and take the tolerance risk off your plate.

Watch for hidden first-article charges. Programming, fixture design and CMM reports should be listed as line items, not folded into the piece price. You want to see them to compare quotes fairly.

• 1
  One piece is fineNo MOQ means the shop expects prototype work.
• 2
  Ask for a price curve1 / 10 / 100 / 1,000 / 10,000+ shows where setup fades.
• 3
  Separate the setup linesProgramming, fixturing and inspection should be visible.

The machine list tells you what the shop does every day. A plant running 127 high-precision CNC machines with 16 simultaneous 5-axis centers, 27 three-axis machines, 12 four-axis mills and 16 mill-turn centers can cover most part families without sending work out. That matters because subcontracted operations add a second queue and a second set of tolerances.

Five-axis work is not automatically better for every part. It pays off when a feature needs to be reached from an angle, when true position across several faces is tight, or when a single setup removes stack error. For a simple plate with holes on one face, a 3-axis machine is faster and cheaper. Ask the shop to justify the machine choice rather than assume the newest one is right.

Part size sets the floor. Maximum processing size runs to 4,000 mm, with travel envelopes of 4,000 × 400 × 150 mm for long parts, 750 × 1,150 × 550 mm and 600 × 600 × 600 mm for medium frames, and 500 × 500 × 450 mm plus 500 × 310 × 200 mm for compact work. A Ø400 mm rotary table covers round parts that need indexing.

Turned parts with milled features are the classic case for mill-turn. Doing both operations on one center removes a re-chuck and keeps concentricity. If your part has a turned bore and an off-axis hole pattern, ask whether it is planned on a mill-turn center or across two machines.

• 1
  Ask for the machine planWhich center, how many setups, which fixtures.
• 2
  5-axis for access, not prestigeUse it when angles or true position demand it.
• 3
  Mill-turn for concentric featuresOne chucking beats two for round-to-milled relationships.

Certifications are a filter, not a ranking. ISO 9001:2015 covers general quality management and fits most industrial work. IATF 16949:2016 is the automotive standard and is expected by tier-1 purchasing systems. ISO 13485:2016 applies to medical devices, where traceability and process control get audited. ISO 27001:2022 covers information security, which is what you want if your drawings are sensitive.

Inspection is where the paperwork meets the part. A shop inspecting 100% before shipment, with raw material checks, in-process monitoring and a final inspection, can hand over reports on request. For a first article, ask for dimensional results on the critical features, material certs and a finish callout check. That package is what protects you if a fit fails at assembly.

Confidentiality needs a real answer. Uploads should be handled as secure and confidential, and an NDA should be available on request without a long negotiation. If a supplier hesitates on an NDA for a simple bracket, that tells you how it handles a full product drawing.

Finishes sit in the same box. Anodizing, plating, powder coating, bead blasting and laser marking are separate processes with their own lead times. Laser marking has a minimum character height of 1.5 mm, so check your label layout before you send it.

• 1
  Pick the cert that matches9001 general, 16949 auto, 13485 medical, 27001 data.
• 2
  Request the inspection packDimensional report, material cert, finish check.
• 3
  NDA before files moveAvailable on request, no long negotiation.
