Basic Knowledge of CNC Processing: How Metal Actually Comes Off

This page explains the basic knowledge of CNC processing for engineers and buyers who need to judge a part, a tolerance, and a process. You will see how material is removed, which machine type fits which geometry, and where the practical limits sit.

±0.005 mm achievableRa 0.2–0.8 μm fine finish127 CNC machines3–5 day shipping
Master the basic knowledge of CNC processing on a 4-axis machining center
Cutting mechanics

What happens where the tool meets the material

CNC processing is subtractive. A rotating cutter or a rotating workpiece meets a stationary edge, and the material in front of that edge shears away as a chip. Everything else on the machine exists to hold that meeting point steady: the bed, the ballscrews, the spindle bearings, the tool holder, the fixture.

Three variables define the cut. Surface speed is how fast the edge travels through the material. Feed per tooth is how much material each flute takes. Depth of cut is how deep the tool engages. Change one and the other two must follow, or the tool rubs instead of cutting.

Heat is the visible result. In aluminium, most heat leaves with the chip, so the part stays cool and you can run fast. In titanium and stainless steel, heat stays in the edge and the part. Slow the surface speed, keep the feed per tooth high enough to stay under the work-hardened layer, and use plenty of coolant.

Chip shape tells you whether the cut is healthy. Long curled chips in 6061 mean the feed is adequate. Fine powder in 304 means the tool is rubbing. Blue chips in steel mean the speed is too high for the coolant supply. Read the chips before you touch the offset.

Machine types

3-axis, 4-axis, or 5-axis: what each one can and cannot reach

A 3-axis mill moves the table in X and Y while the spindle moves in Z. Every feature you machine must be reachable from the top, or you flip the part and set a second origin. That second setup is where most positional error enters a job.

A 4-axis mill adds a rotary table, usually Ø400 mm class. The part turns about one axis, so you can machine four faces plus the ends without re-fixturing. Useful for shafts, manifolds, and parts with pockets on several sides.

A simultaneous 5-axis center tilts the tool as it moves. This is what makes undercuts, deep cavities with short cutters, and impeller blades practical. The trade-off is programming time and the need for a post-processor that matches the machine kinematics.

Turning is a different family. The workpiece spins and a single-point tool feeds along it. Mill-turn centers combine both, so a part that needs a turned OD and milled flats can finish in one setup. For parts under Ø60 mm with tight concentricity, that single setup is often the deciding factor.

Tolerance

What ±0.005 mm really costs

Tolerance is not a single number for the whole part. It applies to the features you dimension. A drawing with ±0.005 mm on one bore and ±0.1 mm on everything else tells the shop where to spend time. Marking the whole print ±0.005 mm raises cost without improving function.

The achievable number depends on the feature. A bored hole in aluminium can hold ±0.005 mm with a good boring head and a warm machine. The same callout on a 300 mm long slot in 316 stainless is a different problem, because thermal drift and tool deflection grow with length.

Surface finish and tolerance travel together. Turning to Ra 0.8–1.6 μm is routine. Pushing to Ra 0.2–0.8 μm usually needs a finishing pass with a small nose radius, a sharp insert, and a stable setup. If the print does not need that finish, ask for it anyway and pay for it.

Stack-up matters more than any single tolerance. If three features locate off one datum and each carries ±0.02 mm, the assembly sees up to ±0.06 mm. Calling out a tighter datum scheme is often cheaper than tightening every feature.

Materials

How material choice changes the process

Aluminium 6061-T6 is the default for prototypes and enclosures. It cuts fast, holds a good finish, and anodizes cleanly. 7075 gives higher strength for aerospace brackets but is less weldable and more prone to stress movement after roughing.

Stainless 304 and 316 work-harden. If the tool dwells, the surface hardens and the next pass cuts through hardened metal. The fix is constant feed, no rubbing, and a cutter that stays sharp. 17-4PH can be machined in the solution-treated state and then aged to reach strength.

Titanium Ti-6Al-4V and Inconel sit at the hard end. Cutting speeds drop, tool life drops, and the machine time rises. These are the parts where a 5-axis setup pays for itself, because one accurate setup beats three slow ones.

Plastics behave differently again. POM and PEEK machine to tight tolerance but move with temperature. ABS and PC are soft and prone to burrs, so a sharp cutter and a light finishing pass matter more than spindle speed. Carbon fibre needs diamond-coated tooling or the edge wears in minutes.

Setup and inspection

Where accuracy is won or lost before the spindle turns

A rigid setup beats a fast spindle every time. Workholding that lets the part vibrate will chatter no matter how good the tool is. For thin walls, support the back side or leave a sacrificial web and remove it in a later pass.

Datum choice drives repeatability. Pick a face and two holes that exist in every operation, and reference everything to them. If the first operation has no good datum, machine one in the first setup and use it for the rest.

Thermal drift is real. A machine that has been sitting cold will move as the spindle warms. For tight work, run a warm-up cycle and check the first part before releasing the run. In-process probing catches drift that a cold first-article check misses.

Inspection closes the loop. We check raw material on arrival, monitor dimensions during the run, and inspect 100% of parts before shipment. Reports are available on request. A first article that passes and a process that drifts will still ship bad parts, so the in-process check is the one that matters.

Selection

Choosing a process by geometry and tolerance

Use this as a first filter, then confirm with a DFM review.

Part conditionRecommended processWhy
Prismatic part, features on 3 sides3-axis with two setupsSimplest, lowest programming cost
Part with pockets on 4 faces4-axis with rotary tableOne setup, better positional accuracy
Undercuts or deep cavities5-axis simultaneousShort cutters reach without collision
Round part with milled flatsMill-turn centerTurned OD and flats in one setup
Wall under 1 mm, long reach5-axis plus support webReduces chatter and deflection
Titanium or Inconel geometry5-axis, low surface speedFewer setups offset the slow cutting

The short version

If the part has features on three sides or fewer and tolerances looser than ±0.02 mm, a 3-axis setup is the economical answer. If it has undercuts, deep cavities, or five-sided access, pay for 5-axis and get one accurate setup instead of three slow ones.

FAQs

Questions engineers ask next

What file formats do you need to quote a CNC part?

Send a STEP or IGES model plus a 2D drawing with the tolerances and finishes you care about. If the print is missing, we can quote from the model with a default tolerance and flag the features that need a callout.

PDF drawings are fine for reference. Native CAD helps us catch wall thickness and tool-access problems before quoting.

How tight a tolerance can you hold on a long part?

On a short feature, ±0.005 mm is routine. As length grows, thermal drift and tool deflection take over. A 300 mm dimension in stainless is a different job from a 30 mm bore in aluminium.

Tell us which dimensions actually matter. Concentrating the tight tolerance on two or three features usually costs less than tightening the whole print.

Does part quantity change the process?

Yes. One prototype is programmed and fixtured for speed of delivery. A 10,000-part run gets soft jaws, custom workholding, and a process designed for repeatability.

There is no minimum order quantity, so a single part and a production run go through the same quoting path.

What surface finishes can you produce directly off the machine?

As-machined is typically Ra 1.6–3.2 μm. A finishing pass brings it to Ra 0.8–1.6 μm. Ra 0.2–0.8 μm is possible on the right feature with a light finishing cut.

Anodizing, plating, powder coating, bead blasting, and polishing are available after machining if the finish callout is decorative or functional.

When is CNC the wrong process?

Very thin sheet parts are usually better stamped or laser cut. Hollow parts with complex internal channels are often better cast or 3D printed. Large flat panels waste material as chips.

If the geometry needs no tight tolerance and the volume is high, casting or die casting will beat machining on unit cost. We will say so rather than quote a process that does not fit.

How do you protect drawings and models?

Uploads are treated as confidential. We can sign an NDA before you send files, and access inside the shop is limited to the people who quote and run the job.

If you prefer, send a simplified model with the critical features intact and hold back the rest until the order is placed.
