A medical device drawing usually names an alloy before it names a process. That order is correct. The alloy decides whether the part can be sterilized, whether it will corrode in body fluid, and how the cutter behaves on the last 0.2 mm of a thin wall.

Stainless grades are the common starting point. 316L is the default for anything that sees steam autoclave cycles, because the low carbon content limits carbide precipitation at the grain boundaries. 303 machines faster and gives a better finish, but the sulfur addition makes it a poor choice for implant contact. 17-4PH (SUS630) is the step up when you need yield strength above what annealed 316L delivers, and it responds to a simple aging treatment after machining.

Titanium is the other family that comes up constantly. Ti-6Al-4V (TC4) has roughly half the thermal conductivity of stainless. Heat stays at the cutting edge, so tool life drops fast if the shop runs the same parameters it uses on 316L. A shop that quotes titanium without asking about flute count and coolant-through capability is quoting a number, not a process.

• 1
  316LAutoclave and body-fluid contact. Low carbon, weldable, machines at moderate speed.
• 2
  17-4PH (SUS630)Higher strength after aging. Needs passivation control after machining.
• 3
  Ti-6Al-4V (TC4)Low thermal conductivity. Requires sharp tooling and strong coolant delivery.
• 4
  Magnesium AZ31B / AZ91DLight and machinable, but corrosion control is a design decision, not a shop fix.

Five-axis machining earns its cost on parts with compound angles, organic contours, or features that would need three separate fixtures on a three-axis machine. A single setup removes the alignment error that stacks up between operations. On a bone plate with a curved underside and angled screw holes, that is the difference between a part that fits and a part that gets reworked.

The trade-off is throughput. Five-axis centers are slower per part on simple geometry, and the hourly rate reflects that. If your part is a flat bracket with holes on one face, a three-axis machine with a good fixture will hit the same tolerance for less money.

Mill-turn centers cover a different case. Shafts, cannulas and stepped connectors often need turning and milling on the same part. Moving that work between two machines adds a second setup and a second chance for runout. A mill-turn center with a Ø400 mm rotary table keeps the datum intact.

Size is the last filter. A shop that tops out at 500 mm cannot help with a 4,000 mm part no matter how good its tolerance is. Check the travel envelope against the real part envelope, including the fixture.

• 1
  Choose 5-axisCompound angles, organic contours, one-setup datum control.
• 2
  Choose 3-axisFlat geometry, holes on one face, cost-sensitive runs.
• 3
  Choose mill-turnShafts and stepped parts with turning plus milling features.
• 4
  Check sizeTravel up to 4,000 × 400 × 150 mm on large machines.

ISO 13485:2016 is the certificate that matters for medical work. It is not a badge. It defines how the shop controls design transfer, process validation, traceability and corrective action. Ask to see the scope statement. A certificate that covers assembly but not machining does not cover the parts you are buying.

ISO 9001:2015, IATF 16949:2016 and ISO 27001:2022 can all sit alongside it. ISO 27001:2022 is worth noting if your drawings are sensitive. It means the shop has a documented information security system, which matters more than most buyers expect when a new device is still unannounced.

Inspection is where the tolerance claim gets tested. A shop that inspects 100% before shipment and can produce dimensional reports on request is telling you the process is stable. Sampling inspection on a 50-piece medical run is not the same thing. Ask what happens when a dimension drifts mid-run, and who signs off before the parts ship.

• 1
  ISO 13485:2016Process validation, traceability, corrective action for medical work.
• 2
  ISO 9001:2015General quality system baseline across all work.
• 3
  IATF 16949:2016Automotive-grade discipline where the same shop serves both markets.
• 4
  ISO 27001:2022Information security for confidential drawings and device programs.

Lead time on a medical part is really three numbers: quote turnaround, production start, and shipping. A shop that quotes and returns a free DFM analysis within 12 hours is giving you room to fix a design before the first chip is cut. Production can start within 24 hours once the drawing and material are confirmed.

Parts ship in 3–5 days on repeat work. That number assumes material is in stock and the first article is already approved. First articles take longer, because the shop is proving the process, not repeating it. Any quote that ignores that distinction is hiding the real timeline.

MOQ is the criterion that surprises buyers most. A shop with no minimum order quantity can run one prototype and then a 10,000+ part production run on the same process. That continuity matters. The first article is made on the same machine and the same fixture as the production parts, so the approval means something.

Quotes are built from material, machine time, finishing and inspection. If a quote is far below the others, one of those four is missing. Finishing is the usual culprit. Anodizing, electroless nickel, passivation and laser marking all add steps, and laser marking has a minimum character height of 1.5 mm that affects the drawing.

• 1
  Quote in 12 hoursIncludes a free DFM analysis you can act on before cutting metal.
• 2
  Start within 24 hoursOnce drawing and material are locked.
• 3
  Ship in 3–5 daysRepeat parts with an approved first article.
• 4
  No MOQOne prototype through 10,000+ part runs on the same process.

Finishing on a medical alloy part is a functional decision. Passivation removes free iron from a stainless surface and restores the chromium oxide layer. Skip it on 17-4PH and you leave a surface that pits earlier in a chloride environment.

Anodizing suits aluminum housings and instrument bodies. Hardcoat anodizing adds wear resistance on sliding surfaces. Conductive anodizing keeps a ground path alive. Each variant changes the dimension on the surface, so the drawing has to state which one applies and whether the coating is included in the tolerance.

Bead blasting, tumbling, brushing and polishing control Ra. A callout of Ra 0.8–1.6 μm is a normal machined medical finish. Ra 0.2–0.8 μm is achievable but adds a polishing step and inspection time. Surface finish is measured, not eyeballed, so ask which instrument the shop uses.

Laser marking closes the loop on traceability. With a minimum character height of 1.5 mm, it fits most instrument bodies. Put the marking requirement on the drawing early. Adding it after the first article means a new setup.

• 1
  PassivationRestores the oxide layer on stainless after machining.
• 2
  Hardcoat anodizingWear resistance on aluminum sliding surfaces.
• 3
  Ra 0.8–1.6 μmStandard machined medical finish, measured with a profilometer.
• 4
  Laser markingMinimum character height 1.5 mm for traceability.
