Most RFQs fail at the first question: what can the machine actually hold? A tolerances band of ±0.005 mm is achievable on a rigid 5-axis center with temperature control and a proper inspection loop. It is not achievable by pushing a worn 3-axis mill harder. When a supplier quotes that band, ask which machine will run the part and how the feature will be measured.

Geometry drives the machine choice more than material does. A bracket with holes on five faces needs either multiple setups on a 3-axis mill or one setup on a simultaneous 5-axis center. Each extra setup adds a datum shift. If your drawing has position tolerances under 0.05 mm across faces, fewer setups is usually the cheaper path, even at a higher hourly rate.

Thin walls, deep pockets, and long slender parts behave differently. A 1 mm wall in aluminium 6061 will deflect under normal finishing passes. A 0.5 mm wall in stainless 316L will move more. Suppliers that machine these parts daily will tell you the wall thickness limit in the quote, and may suggest a rough-then-finish sequence with a stress-relief step between them.

Ask for the surface finish callout in Ra, not in words. Ra 1.6–3.2 μm is a standard as-machined finish. Ra 0.8–1.6 μm needs a finer finishing pass and a sharp tool. Ra 0.2–0.8 μm usually means additional lapping or polishing, and it changes both price and lead time. If the drawing says 'smooth', the quote is a guess.

• 1
  Tight tolerance±0.005 mm is realistic on a 5-axis cell with in-process checks.
• 2
  Multi-face featuresOne 5-axis setup beats three 3-axis setups for position accuracy.
• 3
  Thin wallsBelow 1 mm in aluminium, plan roughing and finishing as separate operations.
• 4
  Finish in RaRa 1.6–3.2 μm as-machined, Ra 0.8–1.6 μm with a finishing pass.

Certifications are a filter, not a ranking. ISO 9001:2015 covers a general quality system and is the baseline for most industrial work. IATF 16949:2016 adds automotive-specific process control, which matters for EV and powertrain parts. ISO 13485:2016 covers medical device manufacturing. ISO 27001:2022 covers information security, which is worth checking when your CAD files are confidential.

A certificate on a website does not tell you the scope. Ask for the certificate number and the scope statement. A shop certified for machining aluminium may not be certified for the same scope in titanium or Inconel. If your part is Inconel 718 or Ti-6Al-4V, confirm the certificate covers those materials before you send the RFQ.

For automotive and medical programs, expect a documented inspection flow: raw material check, in-process monitoring, and final inspection. Reports should be available on request. A supplier that cannot produce a material certificate or a dimensional report is a risk on any regulated program, regardless of the quoted price.

Confidentiality is part of compliance. If your drawings carry export-controlled or proprietary geometry, ask for an NDA before upload. A shop with a defined NDA process and secure upload handling is easier to work with than one that asks for files over a personal email account.

• 1
  General industrialISO 9001:2015 is the minimum.
• 2
  Automotive and EVIATF 16949:2016 with process control evidence.
• 3
  Medical devicesISO 13485:2016 and traceable inspection records.
• 4
  Confidential CADISO 27001:2022 and an NDA available on request.

Part size sets the floor on which machines can bid. A 4,000 mm long part needs a large-travel machine. A 500 mm part can run on a compact cell, which usually costs less per hour. If a supplier lists only large machines, small parts may carry unnecessary overhead. If they list only compact machines, your large part will be subcontracted.

The mix matters more than the total count. A shop with 5-axis centers, mill-turn centers, and small 3-axis mills can route each feature to the right machine. A shop with one machine type will force every part through the same setup. For parts with turned and milled features, a mill-turn center removes one setup and one datum shift.

Rotary tables add a fourth axis without a second fixture. For parts with radial holes or features around a bore, a Ø400 mm rotary table can hold the part while the spindle reaches the feature from one direction. This is often cheaper than a full 5-axis setup for simple radial work.

Ask how the shop handles first articles. A supplier that runs a first article on the production machine, not a separate prototype machine, gives you a more honest picture of the tolerances you will see in the run. If the first article runs on a different machine, the process capability data does not transfer.

• 1
  Large partsUp to 4,000 mm needs a large-travel machine and a planned lift.
• 2
  Small partsCompact cells keep setup time and hourly cost down.
• 3
  Mixed featuresMill-turn centers combine turning and milling in one setup.
• 4
  Radial featuresA rotary table handles many radial holes without a second fixture.

Lead time should be quoted from a defined start point. The useful start point is DFM approval, not the day you send the email. A shop that returns a DFM analysis with the quote usually identifies thin walls, deep pockets, and unmarked datums before cutting starts. That review is what keeps the schedule honest.

MOQ is a commercial filter. A supplier with no minimum order quantity can take one prototype and the same part at 10,000 units. A supplier with a high MOQ is set up for volume and will price a prototype poorly. For a new design, start with a shop that can run one piece and scale the same process to production.

Read the quote line by line. Does it include material certification, surface finish, first-article inspection, and packaging? A low price that excludes inspection is not a lower price, it is a smaller scope. For regulated work, the inspection cost is part of the part cost, not an optional extra.

Delivery risk is worth one direct question: what is your historical late-delivery rate? A supplier that tracks this number can answer it. A supplier that cannot is guessing. If your line stops when the parts are late, that answer matters more than a few percent on the unit price.

• 1
  Start pointLead time from DFM approval, not from RFQ email.
• 2
  Volume rangeOne prototype through 10,000+ part runs on the same process.
• 3
  Quote scopeConfirm material cert, finish, inspection, and packaging are included.
• 4
  Late riskAsk for the historical late-delivery rate in writing.
