Plastic Processing: How Polymer Behavior Sets Your Machining Window

• 1
  What plastic processing actually does to the material
• 2
  How common plastics behave at the spindle
• 3
  Design rules that decide whether the part machines cleanly
• 4
  Where plastic processing stops being the right answer
• 5
  Choosing the right plastic process for the part

Plastic processing is not one operation. It is a family of operations that all remove or reshape polymer. The important part for an engineer is that polymers respond to cutting differently than metals. A metal chip carries heat away as a solid curl. A plastic chip often goes soft, smears and sticks back onto the flute. That single difference drives almost every decision downstream.

Thermoplastics soften over a temperature range, not at one melting point. ABS starts to lose stiffness around 80 °C. POM holds shape closer to 100 °C. PEEK keeps working past 250 °C. When the cutting edge reaches those temperatures, the material stops behaving like a solid and starts behaving like a very stiff fluid. The cutter then pushes material instead of shearing it.

Heat has nowhere to go. Plastics conduct heat roughly a thousand times worse than aluminium. The heat generated at the tool tip stays at the tool tip. This is why a light finishing pass in plastic can burn a surface that a heavy roughing pass in steel would never damage.

The practical result is a narrow window. Feed too slow and the tool rubs, generating heat without cutting. Feed too fast and the part deflects away from the cutter. Both cases give you a bad surface and an out-of-tolerance dimension. Finding the window takes a test cut on the actual material grade, not a chart.

• 1
  Low conductivityHeat concentrates at the cutting edge instead of leaving with the chip.
• 2
  Softening rangeStrength drops gradually, so the part can deflect before it looks hot.
• 3
  Elastic recoveryMaterial springs back behind the edge and rubs the flank.

POM and PA are the friendly grades. They machine with sharp, polished carbide, high spindle speed and generous chip clearance. POM holds a ±0.05 mm tolerance comfortably and finishes around Ra 0.8–1.6 μm without special effort. PA is tougher but absorbs moisture, so a part machined dry on Monday can measure differently on Friday. If the drawing is tight, specify the conditioning state.

ABS and PC sit in the middle. ABS cuts cleanly but has low stiffness, so thin walls chatter and long slender sections need support. PC is stronger and more heat resistant, but it is notch sensitive and prone to stress cracking around a sharp internal corner. A 0.5 mm corner radius instead of a sharp corner often removes the problem entirely.

PMMA and PEEK are the difficult ends of the range. PMMA is brittle and chips out at the exit edge, so climb milling and a backing plate matter. PEEK is expensive and abrasive, and it needs sharp tooling and a coolant strategy that does not thermally shock the part. Both reward a slower, more deliberate setup.

Carbon fibre filled grades change the rules again. The fibre is abrasive, so tool life drops fast. They also machine to a much stiffer, more dimensionally stable part than the unfilled version, which is often the reason they were specified in the first place.

• 1
  POM / PAStable and predictable. Good default for functional prototypes.
• 2
  ABS / PCLow stiffness. Support thin walls and radius internal corners.
• 3
  PMMA / PEEKBrittle or abrasive. Sharp tooling, controlled heat, slower passes.

Wall thickness is the first number to check. Below roughly 1.0 mm, plastic walls deflect under normal cutting force and the finish suffers even if the nominal dimension holds. Between 1.5 mm and 4 mm is the comfortable band for most engineering grades. Thick sections are not free either: they hold internal stress from the stock and can move after machining.

Draft is not needed for CNC, but generous radii are. A sharp internal corner concentrates stress and forces a small cutter that has to run slow. A 2 mm radius instead of a sharp corner typically lets us use a larger tool, cut faster and leave a better surface. It also reduces the risk of a crack starting at that corner in service.

Threads and holes need their own review. Threads below M3 in plastic strip easily, so use a molded insert, a metal insert or a through-bolt instead. Deep holes in plastic drill oversize because the material relaxes after the drill passes. Keep depth under about 3× diameter unless you can accept a reamed tolerance.

Tolerance is where drawings most often overreach. Plastics move with temperature and moisture, so ±0.005 mm on a plastic feature is usually not meaningful over a real service range. Put the tight tolerance on the features that locate the part, and let everything else sit at ±0.1 mm.

• 1
  Wall thickness1.5–4 mm is the safe band for most engineering grades.
• 2
  Corner radii2 mm or larger lets a bigger cutter run and improves finish.
• 3
  ThreadsBelow M3, use inserts or through-bolts instead of cut threads.
• 4
  ToleranceReserve tight values for locating features only.

CNC is a subtraction process, so it removes material from a solid block. That is ideal for one to a few thousand parts, for design iterations, and for geometries that injection molding cannot fill. It is a poor fit for very high volumes, where the per-part machining time dominates cost and molding wins on unit price.

Some shapes simply cannot be cut. A closed internal cavity, a hollow sphere or a part with undercuts on every face will need 5-axis work at best, and often a different process. If the geometry needs a mold anyway, cutting a prototype by CNC first is still useful: it validates fit and function before tooling is committed.

Material choice can also force the decision. If the final part must be a specific filled or foamed grade that is not available in machinable stock, machining a prototype in a near-equivalent grade tells you about geometry but not about the real material behavior. Say so on the drawing so nobody over-reads the test result.

The honest rule is this: use plastic processing when the part is small to medium quantity, when the geometry is reachable by a cutter, and when the material exists in stock. Move to molding, casting or 3D printing when any of those three stops being true.

• 1
  Good fitPrototypes, bridge tooling, low to mid volume, hard-to-mold shapes.
• 2
  Poor fitVery high volume, closed cavities, materials not sold as machinable stock.
