Cemented carbide is a powder metallurgy product. Tungsten carbide grains, typically 0.5–5 μm across, are pressed into shape and sintered with a metal binder, usually cobalt. The carbide grains carry the hardness. The cobalt holds them together and gives the tool its toughness.

That two-phase structure is why the material behaves the way it does. It reaches 1,400–1,600 HV, roughly three times the hardness of hardened tool steel, yet it keeps enough transverse rupture strength to survive interrupted cuts. Nothing about it is uniform. Change the grain size or the cobalt percentage and you get a different tool.

Carbide tools are not one product. A grade is a specific combination of grain size, binder content, and sometimes cubic carbides such as TiC, TaC, or NbC. Two inserts can look identical on the outside and cut completely differently on the same workpiece.

The binder is the weak link. Cobalt softens before the carbide grains do, so most carbide failure starts at the binder and works outward. That single fact explains crater wear, thermal cracking, and why coolant strategy matters as much as the grade itself.

Grain size controls hardness and edge sharpness. Submicron grades (0.4–0.8 μm) hold a keen edge and resist abrasive wear, which suits finishing passes and hardened steel up to about 45 HRC. They chip more easily under shock.

Medium grades (1–3 μm) are the general-purpose workhorse. They cover most steel and stainless turning, and they tolerate light interruptions. If you only stock one grade for mixed work, this is the one.

Coarse grades (3–6 μm) trade hardness for toughness. They handle interrupted cuts, castings with hard spots, and heavy roughing where a fine edge would spall on the first pass.

Cobalt content moves the same needle. Low cobalt, around 3–6%, gives maximum wear resistance for finishing. High cobalt, 10–15%, buys impact strength for roughing and for machining titanium and nickel alloys where chatter and edge chipping dominate.

There is no free upgrade. Every step toward toughness costs wear resistance, and every step toward hardness costs edge integrity. Grade selection is picking which failure mode you can live with on that job.

A coating is a thermal and chemical barrier. It keeps heat in the chip instead of letting it soak into the carbide, and it slows diffusion between the workpiece and the tool. That is the whole mechanism. Thickness and adhesion do the rest.

CVD runs at roughly 900–1,100 °C and lays down 5–15 μm of TiN, TiCN, or Al2O3 in layers. The alumina layer is the heat barrier, which is why CVD grades dominate turning steel at high speed. The downside is temperature: the process can soften the substrate near the surface, so CVD is a poor fit for very sharp edges.

PVD runs at 400–500 °C and deposits 2–5 μm. It keeps the substrate harder and the edge sharper, which is why PVD grades lead in milling, drilling, and anything with a small edge radius. It also handles interrupted cuts better.

Uncoated carbide still has a place. Aluminum, copper, and most plastics cut clean without a coating, and a polished uncoated insert avoids the built-up edge that a rough coating can encourage. For non-ferrous work, uncoated is often faster and cheaper.

Coating choice follows the failure mode, not the catalog. If your inserts die from flank wear, a harder coating helps. If they die from chipping, a thinner PVD layer and a tougher grade help more.

A sintered carbide edge is sharper than it should be. Left as-sintered, the edge radius can be under 5 μm, and a radius that fine fractures almost immediately under load. Edge preparation fixes that.

Honing rounds the edge to a controlled radius, usually 10–50 μm. Light honing for finishing, heavy honing for roughing and castings. The radius spreads cutting force over more material and removes the microscopic flaws left by grinding.

A T-land or K-land puts a narrow flat or negative chamfer behind the edge. It is standard on turning inserts for steel and cast iron because it converts a shearing cut into a more compressive one. The trade is higher cutting force, which needs a rigid setup and enough spindle power.

Geometry matters as much as the material. Positive rake cuts freely and suits thin walls, small diameters, and low-power machines. Negative rake is stronger and suits heavy interrupted cuts. A correct grade on the wrong geometry still fails.

Get the edge wrong and no grade or coating will save the tool. Chipping at the cutting edge on the first few parts usually points to edge prep or geometry, not to the carbide itself.

Flank wear is normal and expected. A uniform wear land on the clearance face means the grade and speed are roughly right. Replace the insert when the land reaches 0.2–0.4 mm, before it accelerates.

Crater wear appears on the rake face where the chip rubs. It comes from diffusion at high temperature, so it points to cutting speed being too high or a coating that is not holding up. Reduce speed or move to an alumina-coated grade.

Chipping and micro-breakage look like a ragged edge rather than a smooth wear land. That is a toughness problem, not a hardness problem. Reduce feed, add edge honing, or move to a higher-cobalt grade.

Built-up edge shows as a lump of workpiece material welded to the edge. It tears off and takes carbide with it. Raise speed, increase feed, or switch to a sharper positive geometry and a smoother coating.

Thermal cracking looks like fine comb cracks perpendicular to the edge. It comes from interrupted cutting with coolant applied hard. Reduce the coolant, or cut dry with a grade designed for it.

Notching at the depth-of-cut line is common in stainless and high-temperature alloys. It comes from work hardening at the surface. Change the depth of cut so the notch lands on fresh material, or use a grade with better notch resistance.
