Two shops can quote the same hard alloy part and land 40% apart. The gap is rarely the hourly rate. It is how many setups the route needs, how much tooling each route burns, and how much inspection the shop puts behind the cut. A route with five re-clamps on a 4340 bracket will always cost more than one five-axis route that holds the same tolerances in two setups.

Ask the shop to describe the route, not just the price. If a supplier quotes a titanium housing without mentioning cutter paths or coolant strategy, the low number is a guess. It will move once the first part scrapped.

Aluminium is the easy case. 6061, 6063 and 6082 cut fast on three-axis machines and hold ±0.005 mm without drama. The moment the part is 17-4PH, TC4 or Inconel, the rules change: speeds drop, tool life shortens, and the shop needs a real plan for heat.

• 1
  Ask for the setup countFewer setups usually means better position tolerance.
• 2
  Ask for the tool listCarbide grade and coating tell you how serious the shop is.
• 3
  Ask for the inspection planA route without one is a risk transfer, not a service.

A tolerance printed on a website is a capability claim, not a promise for your part. The useful question is narrower: can the shop hold ±0.005 mm on the features that matter after heat and stress relief? On long, thin hard alloy parts, the answer depends on fixturing and on whether the shop roughs, stress-relieves and then finishes.

Surface finish follows the same logic. As-machined Ra 1.6–3.2 μm is normal for structural work. Ra 0.8–1.6 μm is a reasonable ask on sealing faces and bearing bores. Ra 0.2–0.8 μm usually means a secondary operation, and you should price it that way.

Do not accept a finish number without a measurement method. A shop that measures with a profilometer and reports where it took the reading is easier to trust than one that quotes a number and stops there.

• 1
  Split the drawingMark the features that truly need tight tolerance.
• 2
  Name the datumInspection disputes almost always start at the datum.
• 3
  Ask for the reportRaw material, in-process and final inspection reports on request.

Five-axis machining matters most when the part has angled faces, deep pockets or features on several sides. Every re-clamp on a powerful alloy adds a chance of chatter marks and a chance of a scrapped part. A simultaneous five-axis center machines those faces in one pass, which is why it often wins on total cost even at a higher hourly rate.

Size is the other gate. A 4,000 mm maximum processing size and a 4,000 × 400 × 150 mm travel covers long structural parts. Mid-range travels of 750 × 1,150 × 550 mm and 600 × 600 × 600 mm handle most housings. Compact travels of 500 × 500 × 450 mm and 500 × 310 × 200 mm suit small medical and electronics work. A Ø400 mm rotary table is what lets a shop put four-sided features on a round part.

If your part sits near a machine's travel limit, ask about the fixture envelope, not just the part envelope. A vise or tombstone eats 30 to 60 mm of usable travel.

• 1
  Count the angled facesThree or more usually means five-axis is cheaper.
• 2
  Check the fixture allowanceLeave room for clamping, not just for the part.
• 3
  Ask about in-process probingIt catches drift before the finish pass.

Certification is a filter, not a quality score. If your part goes into a car or an EV, IATF 16949:2016 tells you the shop runs traceability and change control in a way your customer will accept. For medical devices, ISO 13485:2016 is the baseline. ISO 9001:2015 covers general industrial work. ISO 27001:2022 matters when you send drawings and CAD that you do not want copied.

Ask which certificate applies to the site doing your work. A group with three plants may hold different scopes at each one. The paperwork should name the facility, not just the brand.

Then ask for the material certificate and the inspection report. On Inconel and titanium, the mill certificate is how you confirm the alloy actually is what the drawing calls for. Without it, the part is unverifiable.

• 1
  Match cert to industryAutomotive, medical and IT security have different rules.
• 2
  Check the site scopeThe certificate should name the plant.
• 3
  Keep the mill certIt is the only proof of alloy grade after delivery.

A credible powerful alloy CNC processing service will quote and return a DFM analysis within 12 hours, start production within 24 hours once the drawing is released, and ship parts in 3–5 days for standard routes. Treat those numbers as the shop's normal rhythm. Hard alloys with long heat-treat cycles or outside finishing will take longer, and a supplier who hides that is quoting to win rather than to deliver.

MOQ is the other number to pin down. No minimum order quantity means a single prototype and a 10,000+ part run go through the same quoting path. That matters when you are validating a design and cannot commit to volume yet.

Ask what the quote includes. Machining only, or machining plus finishing plus inspection? Anodizing, electroless nickel, powder coating and laser marking are separate steps with separate lead times. A quote that lists them separately is easier to compare than a single lump number.

• 1
  Get the DFM back earlyIt is the cheapest place to fix a design problem.
• 2
  Confirm what is includedMachining, finishing and inspection are three line items.
• 3
  Ask about change controlKnow what happens when revision B arrives mid-run.
