A solid block has mass on its side. A shell does not. Once you open the cavity, the remaining wall is the only structure left, and every cutting force pushes against it. On a 6061 shell with a 2 mm wall and a 300 mm length, a 12 mm end mill at full radial engagement will move that wall before it cuts it cleanly. The symptom is a taper you cannot explain by tool wear alone.

Aluminum adds a second problem: it is soft, gummy and a good conductor of heat. Chips weld to the flute if the feed is too light, because the tool rubs instead of cutting. Heat leaves the cut zone fast, so the part grows and shrinks between passes. A shell measured warm on the machine can read 0.03–0.05 mm different after it cools.

The third factor is geometry. Shells usually carry a sealing face, a bearing bore or a connector cutout, and those features often sit on different sides. Each new orientation is a new setup, and each setup brings its own datum error. The goal of processing aluminum alloy shell parts is to reduce the number of times the part is released and re-clamped.

None of this is a reason to avoid shells. It is a reason to plan the process around stiffness and heat instead of around the fastest toolpath.

Grade selection sets the ceiling for the whole job. 6061-T6 is the default for housings: it machines cleanly, welds, anodizes evenly and holds a ±0.005 mm tolerance on stable walls. 7075 is stronger but less forgiving of thin sections and gives a duller anodized finish. 2024 machines well but corrodes faster and is rarely the right choice for an exposed enclosure.

Cast blanks change the rules. ADC12 die castings are near net shape and save material, but they carry porosity. A pore that opens into a sealing face becomes a leak path after machining. If the shell must hold pressure or IP-rated sealing, we check the casting supplier's porosity standard before quoting.

Stock allowance matters too. Leave 0.8–1.2 mm per side on a milled shell so the roughing pass can remove the cast skin and still leave 0.3–0.5 mm for finishing. Cutting straight to size in one pass saves a setup and costs you the ability to correct deflection.

For extruded profiles, check straightness before clamping. A 4,000 mm extrusion can arrive with enough bow that clamping it flat builds stress into the part, and that stress releases when you machine the second side.

• 1
  6061-T6Best all-round choice for machined shells with thin walls.
• 2
  7075-T6Use where strength matters more than finish or weldability.
• 3
  ADC12Good for cast shells, but verify porosity at sealing faces.
• 4
  5083 / 6082Consider for welded or marine enclosures.

The fixture is where most shell scrap is decided. A shell clamped only at the base will ring like a bell under a face mill. We add support under the wall, not more clamp pressure. Soft jaws machined to the actual blank profile, plus a low-melt or wax support for deep pockets, hold the wall without crushing it.

For open shells with a large cavity, vacuum fixturing works well when the floor is flat and the part is not porous. A cast ADC12 shell with porosity will not hold vacuum reliably, so we fall back to mechanical support. Vacuum gives even pressure across the whole footprint, which is exactly what a thin floor needs.

Zero-point systems pay for themselves on repeat orders. A pallet with a known datum lets us move the shell from a 3-axis to a 5-axis machine without re-indicating the part. That removes one source of positional error and one hour of setup.

Watch clamp placement against the sealing face. A clamp pad directly over a machined O-ring groove will distort the groove while you cut the opposite side, and the groove will spring back after release.

Aluminum wants speed and feed, not light passes. For a 12 mm three-flute carbide end mill in 6061, we run around 2,500–3,500 rpm with 0.08–0.12 mm per tooth, which keeps the chip thick enough to carry heat away. Dropping the feed to be safe is the most common mistake on shells: the tool rubs, work-hardens the surface, and the finish gets worse.

Rough with a larger tool and a trochoidal path. A 10–12 mm cutter at 30–40% radial engagement removes the bulk without loading the wall. Then step down to a 6 mm cutter for corners and a 3 mm cutter only where the radius demands it. Small tools on a long reach deflect, so keep the gauge length as short as the pocket allows.

Leave 0.3–0.5 mm on walls and floors for the finish pass. Run the finish after the part has cooled, and use a sharper, higher-rake cutter. For sealing faces we target Ra 0.8–1.6 μm; cosmetic outer surfaces can sit at Ra 1.6–3.2 μm as machined and be bead blasted later.

Drill and tap before the finishing pass where possible. Tapping into a finished thin wall can bow it, and a broken tap in a nearly complete shell is an expensive recovery.

Aluminum moves with temperature. A shell that is 15 °C warmer than the inspection room will measure large on outside dimensions and small on bores. We keep coolant flowing, avoid dry cutting on thin walls, and let the part stabilize before any tight measurement. On a 300 mm shell, a 10 °C change is worth roughly 0.07 mm of length.

Stress relief is not only a heat-treat topic. Removing a cast skin or an extruded surface releases internal stress asymmetrically, which is why a shell can bow after the first side is machined. Cutting equal amounts from both sides in alternating passes keeps the balance closer.

For parts that must hold ±0.005 mm across a long span, a rough-machining and rest cycle helps. Rough both sides, let the part sit, then finish. The delay costs machine time and saves rework.

If the shell will be anodized, remember that hardcoat adds 20–50 μm per surface and grows the part. Mask sealing faces and bores, or machine them undersize on purpose. This is a finishing decision, but it has to be made at the CNC stage.

In-process checks beat final inspection. Measure the wall after roughing, not after finishing, because that is when you can still correct deflection with a lighter finish pass. A wall that reads 1.9 mm when the drawing says 2.0 mm after roughing will read worse after finishing if you keep the same parameters.

Sealing-face flatness is the feature most likely to fail on a shell. Check it on a surface plate or with a CMM before anodizing, since coating thickness changes the result. For an O-ring groove, verify both the groove width and the surface finish; a groove that is dimensionally correct but torn will leak.

Bores deserve their own check. A thin-wall shell can have a round bore when clamped and an oval one after release. Measure bores with the part free, not in the fixture. If the ovality exceeds the tolerance, the fixture is the problem, not the boring bar.

Keep records per batch. When a shell fails at assembly, the setup sheet and the in-process numbers tell you whether it was material, fixture or tool wear.
