When engineers ask for CNC automatic components explained, they usually mean parts that go into equipment which runs with little or no operator input: indexing tables, tool changers, grippers, feeders, valve bodies, sensor housings, spindle adapters. The part itself is not automatic. The machine it sits in is.

That distinction matters at the drawing stage. A bracket in a manual fixture can be cut to ±0.1 mm and nobody notices. The same bracket guiding a linear slide in a cam indexer will bind, wear, or lose position if the bore spacing drifts past ±0.02 mm. Function drives tolerance, not the word "automatic".

So this page covers four things: the part families that show up most often, how metal removal actually constrains geometry, where precision stops paying for itself, and how to read a tolerance callout before you send it out for quote. No marketing language, just the shop-floor version.

GreatLight has run 127 high-precision CNC machines across three wholly-owned plants since 2011, including 16 simultaneous 5-axis centers. That mix shapes the advice below: some parts belong on a five-axis machine, and a lot of them do not.

• 1
  Function firstAsk what the feature locates or seals before picking a tolerance.
• 2
  Process secondChoose 3-axis, 4-axis, or 5-axis based on reachable faces, not habit.
• 3
  Inspection lastIf you cannot measure it, you cannot hold it in production.

Housings and covers are the largest group by volume. They carry bores, counterbores, o-ring grooves, and mounting patterns. Most are aluminium or zinc alloy, and most are cut from plate or billet rather than cast because the run is under a few thousand pieces.

Motion parts come next: shafts, spools, cam plates, eccentric pins, and roller carriers. These are turned, often with milled flats or cross holes, so a mill-turn center or a lathe with live tooling saves a second setup and the position error that comes with it.

Fluid and gas control parts sit in the same machines but carry different risks. A valve body with a spool bore at Ø12 H7 and a Ra 0.4 μm finish will leak if the bore is round within 3 μm but tapers along its length. Roundness and straightness matter more than the diameter callout here.

Finally, there are structural and mounting parts: adapter plates, brackets, rails, and sensor mounts. These are usually the cheapest parts on the machine and the ones most often over-toleranced. A general tolerance block of ±0.1 mm is enough for most of them.

CNC machining is subtractive. A rotating cutter moves along programmed paths and removes material from a solid block. The finished geometry is whatever is left after the tool passes. That single fact explains most of the design rules that follow.

Every tool has a radius, so every internal corner has a radius. A Ø6 mm end mill leaves a 3 mm corner. If your drawing calls for a sharp internal corner, the shop either adds a relief, changes to a smaller tool and accepts a slower cut, or sends the feature to EDM. All three cost money.

Long tools deflect. A Ø3 mm cutter reaching 30 mm deep will push away from the wall under load, so the slot comes out tapered. The usual fix is a shorter tool with a step-down, or a rougher pass followed by a light finishing pass at 0.1–0.2 mm radial depth.

Heat is the other constraint. Aluminium 6061 and 7075 cut fast and carry heat away with the chip. Stainless 316 and titanium TC4 (Ti-6Al-4V) do not. They work-harden at the surface, so a cutter that rubs instead of shearing will dull in minutes and leave a hard skin that ruins the next pass.

• 1
  Aluminium 6061 / 7075Free-cutting, good for housings, brackets, and heat sinks.
• 2
  Stainless 303 / 304 / 316LUse sharp tools, generous feed, and no dwelling in the cut.
• 3
  Titanium TC4 and InconelSlow speeds, flood coolant, and rigid setups only.
• 4
  POM, PEEK, ABSWatch clamping pressure and chip evacuation; plastics spring back.

A three-axis machine moves the part in X, Y, and Z while the tool stays vertical. If every feature you need is reachable from one direction, or from two or three setups on a cube, 3-axis is the right answer. It is faster to program, faster to fixture, and cheaper per hour.

A five-axis machine tilts the tool or the table. That lets you cut undercuts, angled ports, and compound faces in one setup. The real saving is usually not the toolpath. It is the elimination of three or four re-fixturings, each of which adds position error and queue time.

So the test is simple. Count the setups. If a part needs four or more orientations, and the tightest tolerance crosses between them, five-axis is usually cheaper overall even though the hourly rate is higher. If the part is a flat plate with holes, it is not.

Four-axis work sits in between. A rotary table at Ø400 mm lets you index a part around one axis and mill flats, slots, and cross holes without re-clamping. Shafts with milled features, spools, and roller carriers are typical four-axis jobs.

A tolerance is a cost statement in disguise. Loosening a bore from Ø12 H7 to Ø12 +0.05/+0.10 can move a part from a jig-bored operation to a standard reamed hole. The function rarely changes, but the price does.

GreatLight holds ±0.005 mm (±0.0002 in) on critical features when the drawing requires it. That is achievable on a rigid machine with temperature control and a qualified probe, but it is not free. It also has to be measured, and measuring a 5 μm band on a production floor takes the right instrument.

Surface finish follows the same logic. As-machined finish on aluminium lands around Ra 1.6–3.2 μm. A fine finishing pass gets to Ra 0.8–1.6 μm. Below that, you are usually looking at Ra 0.2–0.8 μm, which means light depths of cut, sharp tooling, and often a lapping or polishing step.

Put the tight tolerance and the fine finish only where they touch a mating surface or seal. Everywhere else, use the general tolerance block. On a typical housing, that one decision can cut cycle time noticeably without touching function.

CNC is not the cheapest way to make every automatic component. If a part is a simple box with a few holes and the annual volume is 50,000 pieces, die casting or injection moulding will beat it on unit price once the tooling is amortized. Machining is the right call for low to mid volume, for prototypes, and for features a mould cannot form.

Very small holes are another boundary. Below roughly Ø0.5 mm, drill breakage and chip packing dominate, and the shop may push the feature to EDM or laser. The same applies to sharp internal corners, deep narrow slots, and any geometry where the tool must be much smaller than the feature.

Hardness is the third limit. Pre-hardened steel to 45 HRC can still be cut with the right carbide, but above roughly 55 HRC the process shifts to grinding or EDM. If the drawing calls for hardening after machining, expect distortion and plan a finishing pass for after heat treatment.

Finally, geometry that cannot be inspected is a problem even when it can be cut. An internal undercut with no line of sight to a probe is hard to verify in production. Design a witness feature or accept that the dimension is controlled by the process, not by measurement.

Start with the datum scheme. If the drawing has no datums, the shop will pick its own, and the inspection report will not match your assembly fixture. Define A, B, and C on real surfaces that a machine can touch.

Then check the callouts that create hidden cost: true position on a bolt circle, perpendicularity across a long bore, concentricity between a turned diameter and a milled bore. Each one adds fixturing or in-process probing. Each one is worth confirming that the assembly truly needs.

Note the material and finish together. Anodizing adds roughly 5–15 μm per surface and can close a tight hole. Hardcoat anodizing is thicker. If a Ø6 H7 bore is anodized after machining, the shop needs to pre-machine it undersize, and that has to be stated on the drawing.

Last, say how many parts you need and when. A one-off prototype and a 10,000-piece run are different processes even for the same geometry. GreatLight quotes both without a minimum order quantity and returns a quotation with free DFM analysis within 12 hours.
